NAD M33

Photos - Amplifier NAD M33
Videos 8Photos 5
Outdated Product
Device type: integrated amplifier; Element base: transistor; Number of channels: 2; Frequency range (Hz): 20 – 20000; Power per channel, 8 ohms (W): 200; Power per channel, 4 ohms (W): 380; Signal to noise ratio (dB): 98; Damping factor: 800; Harmonic distortion coefficient (%): 0.003
add to listmy lists
NAD M33
Type:integral
Number of channels:2
Power per channel (8 ohms):200 W
Coef. damping:800
To amplifier (Main):RCA/XLR
Inputs:optical
RCA inputs:6 steam(а)
Outputs:Pre-Amp
USB
All specifications
Specifications M33
Colour
Device typeintegrated amplifier
Element basetransistor
Toroidal transformer
Amplifier parameters
Number of channels2
Frequency range20 – 20000 Hz / +/- 0.03 дБ /
Power per channel (8Ω)200 W
Power per channel (4Ω)380 W
Signal to noise ratio98 dB
Damping factor800
Harmonic distortion0.003 %
Channel sensitivity / impedance
Balanced XLR input865 mV
47 kOhm
Line input865 mV
47 kOhm
Phono MM/MC1.2 / 0.1 mV
56 / 0.1 kOhm
Connectors
InputsPhono
coaxial S/P-DIF
optical
balanced digital (AES/EBU)
RS-232
control input (IR)
To amplifier (Main)RCA/XLR
RCA6 pairs
XLR (balanced)2 шт
Trigger1 шт
OutputsPre-Amp
control output (IR)
For acoustics4 шт
Trigger output1 шт
Front paneldisplay
Features
Adjustmentstreble adjustment
balance adjustment
level adjustment
More featuresBy-pass/Direct
auto power off
additional speaker connect
Bi-Wiring
external devices control
General
Remote control
PSUinternal
Power consumption40 W
Standby consumption0.5 W
Dimensions (WxDxH)435x396x133 mm
Weight10 kg
Added to E-Catalogaugust 2021
Information in model description is for reference purposes.
Before buying always check characteristics and configuration of product with online store manager
