TrippLite Eaton PDUMH32HVATNET 7.7kW Single-Phase Switched Automatic Transfer Switch PDU Two 200-240V IEC309 32A Blue Inputs 16-C13 2

The PDUMH32HVATNET 7.4kW Single-Phase 230V ATS/Switched PDU provides remote power monitoring and enables redundant power for network devices with non-redundant power supply configurations. Ideal for data centers and server rooms it mounts in 2U of space in EIA-standard racks and features 18 switched outlets (16 C13 and two C19) in two load banks each bank protected by a 20A circuit breaker.

Dual 3-meter input cords with IEC309 32A Blue (2P+E) plugs connect to separate primary and secondary single-phase 230V power sources. The PDU constantly evaluates the power quality of both input sources. Dynamic solid-state (TRIAC) automatic transfer switching allows the PDU to switch to the secondary source within 15 milliseconds should the primary source fail or become unstable to ensure your connected equipment operates without interruption.

Built-in Ethernet network interface allows remote access to the PDU for power monitoring configuration control and notifications via web browser SSH telnet or SNMP. Provides real-time load/current data with billing-grade accuracy (+/- 1 percent). Supports user-programmable startup of outlets in any order or interval to ensure network items are turned on in the proper sequence and reliably discovered. Digital LED display indicates power availability voltage source A/B input status output load and power factor as well as temperature and humidity with the optional temperature sensor (sold separately).

Primary and Secondary Inputs for Power Redundancy

Provides remote power monitoring and enables redundant power for network devices with non-redundant power supply configurations
Dual 3m input cords with IEC309 32A Blue (2P+E) plugs connect to separate primary and secondary single-phase power sources

Automatic Transfer Switching

Dynamic solid-state (TRIAC) automatic transfer switching
Switches to secondary power source if primary source fails or becomes unstable
15 ms transfer time ensures uninterrupted operation of connected equipment
Built-in processor monitors both sources and prevents switching if secondary source is unavailable or of lower quality than primary source

Multifunction Digital LED Display

Reports source A and source B input power status and other information including power availability line voltage frequency amps kilowatts and power factor

Advanced Network Monitoring

Built-in Ethernet network interface allows remote access for power monitoring configuration control and notification via web browser SSH telnet or SNMP
Real-time load/current data with billing-grade accuracy (+/- 1 percent)
Automated alerts help prevent accidental overloads power loss and downtime
Optional temperature sensor (sold separately) monitors temperature and humidity

Broad Communications Compatibility

Supports HTTP HTTPS PowerAlert SMTP SNMPv1 SNMPv2 SNMPv3 Telnet SSH FTP DHCP BOOTP and NTP

20A Circuit Breakers

Protect each of 2 single-phase output banks
Front-panel LED
