StarTech.com 1 Port 2.5Gbps PoE Network Card, PCIe Ethernet Card w/RJ45, 30W 802.3at PoE NIC for Desktops/Servers, Network P
2.5G NETWORK CARD WITH POE: This PCI Express x1 Network Card enables 2.5Gbps network speeds and supplies (PSE) 30W PoE over a... moresingle CAT5e (or later) cable - Leverage existing copper cabling without the use of a Power over Ethernet (PoE) injector. POE+ COMPLIANT: Card provides up to 30W PSE and 25.5W PD at 48V DC to a connected device - Supports IEEE 802.3af (PoE) and 802.3at (PoE+) to power remote devices such as access points, RFID readers, and IP cameras. MULTI-GIGABIT CONNECTIVITY: The Network PoE Card features 2.5GBASE-T (802.3bz) and will auto negotiate to the connected device's highest possible speed - The PCIe Network Card supports Wake-on-LAN and RealWoW for remote wake up of the host computer. TECH SPECS: 2.5Gbps/1Gbps/100Mbps/10Mbps - NBASE-T - 1x RJ45 Port - Realtek RTL8125B - IEEE 802.3af/at - 802.3az EEE - PCIe 2.1 x1 - SATA & SP4 Power Connectors - Link/PoE LED Indicators - 16K Jumbo Frame - VLAN - PXE Boot - Full and Low-Profile Brackets. VERSATILE POE NETWORK CARD: The PCIe Ethernet Adapter supports Windows and Linux - Variable speed options and includes a low-profile bracket for Small Form Factor (SFF) systems ensures compatibility of the PoE NIC with current and legacy devices. IEEE 802.3af and IEEE 802.3at (PoE/PoE+) | 2.5GBASE-T. The Power over Ethernet PCIe network card enables multigigabit speeds of 2.5/1Gbps and 100/10Mbps. This PoE LAN adapter can provide up to 25.5 W of power to a connected device. It combines a network data connection and power over a single Cat5e (or better) Ethernet cable. This PoE NIC is the ideal solution to provide both power and network communication to a remote installation.. Versatile Network PoE Card. The PCIe Ethernet card supports the IEEE 802.3af and IEEE 802.3at (Type 1 and Type 2) standards for Power Sourcing Equipment (PSE) and can deliver up to 48 V DC and 25.5 W of power to compliant Powered Devices (PD). This flexibility eliminates the need for a separate power source for remote networked devices such as IP cameras, access control devices, remote kiosks, and wireless access points.. Enhance Existing Hardware. The network interface card connects to an available x1 PCIe 2.1 (or higher) expansion slot. The card is shipped with a standard-profile bracket. It includes a low-profile bracket for installation in various computer chassis. Access up to 2.5 Gbps (NBASE-T) speeds using Cat5e cabling to utilize existing networks and equipment.. Take advantage of advanced features such as Audio-Video Bridging (AVB) for transmitting real-time content over Ethernet, VLAN tagging, 16K jumbo frame, full-duplex, and PXE.. This product is backed for 2 years, including free lifetime 24/5 multi-lingual technical assistance.. Ports & interfaces. Connectivity technology. Wired. Host interface. PCI Express. Interface. Ethernet. Ethernet LAN (RJ-45) ports. 1. Power over Ethernet (PoE) ports quantity. 1. PCI version. 2.1. PCI Card form factor. Full-height (low-profile). Network. Maximum data transfer rate. 2500
StarTech.com Red Card PCI-E Expansion Card | 2.5G PoE Network AdapterElevate your desktop computer or server´s networking cap... moreabilities with the StarTech.com 2.5GbE PoE PCI-E Network Expansion Card. Designed for power users, IT professionals, and system builders who demand superior speed and functionality, this high-performance component provides a robust solution for enhancing your system´s connectivity. Add a versatile, high-bandwidth Power over Ethernet (PoE) port to your setup, eliminating network bottlenecks and simplifying your infrastructure. This is the ultimate upgrade for workstations dealing with large file transfers, high-resolution media streaming, and other data-intensive applications.This powerful network adapter is more than just a speed upgrade, it is a smart integration tool. The built-in PoE functionality allows this expansion card to deliver both data and power over a single Ethernet cable to a compatible device. This is perfect for powering IP security cameras, VoIP phones, or wireless access points in locations where a power outlet is not readily available, significantly reducing cable clutter and installation complexity. Built for reliability, it operates flawlessly across a wide temperature range, making it suitable for even demanding industrial environments.Key Benefits:* Next-Generation Network Speed: Break through the 1-gigabit barrier with 2.5GBASE-T technology. Experience data transfer rates up to 2.5 times faster than standard Gigabit Ethernet, ensuring smooth and efficient handling of high-bandwidth tasks.* Simplified Installation with Power over Ethernet (PoE): Consolidate your cabling by providing up to 30W of power and data through one RJ45 port. This feature is ideal for deploying network devices in remote or difficult-to-reach areas without needing a separate power source.* Broad System Compatibility: Engineered for seamless integration, this card offers native driver support for Linux and is compatible with a wide range of Windows and Windows Server operating systems, ensuring a hassle-free setup process.* Versatile Physical Installation: With both full-profile and low-profile mounting struts included, this network expansion card can be easily installed in a variety of computer chassis, from standard full-sized towers to compact, small form-factor (SFF) systems.---Features:* User-friendly installation with an included comprehensive installation guide.* Onboard LED indicators provide at-a-glance status updates for Link, Activity, and PoE operation, simplifying diagnostics and troubleshooting.* Utilizes a single PCI Express slot to add a powerful multi-gigabit Ethernet connection.Hardware & Performance:* Interface: PCI Express* PoE Standard: IEEE 802.3at/af compliant (PoE/PoE+)* PoE Power Budget: Up to 30 Watts* Voltage: 48 V DC output for PoE devicesConnectivity:* Technology: Wired Ethernet Network* Host Connector: PCI Express x1* 1 x RJ45 Port * 1 x Power over Ethernet (PoE) OutputCompatibility:* Operating
StarTech.com 1 Port 2.5Gbps PoE Network Card PCIe Ethernet Card w/RJ45 30W 802.3at PoE NIC for Desktops/Servers Network PoE
IEEE 802.3af and IEEE 802.3at (PoE/PoE+) | 2.5GBASE-T
The Power over Ethernet PCIe network card enables multigigabit speed... mores of 2.5/1Gbps and 100/10Mbps. This PoE LAN adapter can provide up to 25.5 W of power to a connected device. It combines a network data connection and power over a single Cat5e (or better) Ethernet cable. This PoE NIC is the ideal solution to provide both power and network communication to a remote installation.
Versatile Network PoE Card
The PCIe Ethernet card supports the IEEE 802.3af and IEEE 802.3at (Type 1 and Type 2) standards for Power Sourcing Equipment (PSE) and can deliver up to 48 V DC and 25.5 W of power to compliant Powered Devices (PD). This flexibility eliminates the need for a separate power source for remote networked devices such as IP cameras access control devices remote kiosks and wireless access points.
Enhance Existing Hardware
The network interface card connects to an available x1 PCIe 2.1 (or higher) expansion slot. The card is shipped with a standard-profile bracket. It includes a low-profile bracket for installation in various computer chassis. Access up to 2.5 Gbps (NBASE-T) speeds using Cat5e cabling to utilize existing networks and equipment.
Take advantage of advanced features such as Audio-Video Bridging (AVB) for transmitting real-time content over Ethernet VLAN tagging 16K jumbo frame full-duplex and PXE.
This product is backed for 2 years including free lifetime 24/5 multi-lingual technical assistance.
The StarTech.com Advantage
StarTech.com 1 Port 2.5Gbps PoE Network Card PCIe Ethernet Card w/RJ45 30W 802.3at PoE NIC for Desktops/Servers Network PoE L... moreAN Adapter w/Low-Profile Bracket NBaseT Windows/Linux (ST1000PEXPSE)DESCRIPTION DU PRODUIT La carte réseau Power over Ethernet PCIe permet des vitesses multigigabit de 25/1Gbps et 100/10Mbps. Cet adaptateur LAN PoE peut fournir jusqu'à 255 W d'alimentation à un périphérique connecté. Il combine une connexion de données réseau et une alimentation sur un seul câble Ethernet Cat5e (ou supérieur). Cette carte réseau PoE est la solution idéale pour fournir à la fois l'alimentation et la communication réseau à une installation distante. Carte PoE réseau polyvalente La carte Ethernet PCIe prend en charge les normes IEEE 802.3af et IEEE 802.3at (type 1 et type 2) pour les équipements d'alimentation (PSE) et peut fournir jusqu'à 48 V CC et 255 W d'alimentation aux dispositifs alimentés (PD) conformes. Cette flexibilité élimine le besoin d'une source d'alimentation séparée pour les appareils en réseau distants tels que les caméras IP les dispositifs de contrôle d'accès les kiosques à distance et les points d'accès sans fil. Améliorer le matériel existant La carte d'interface réseau se connecte à un emplacement d'extension PCIe 2.1 x1 (ou supérieur) disponible. La carte est livrée avec un support à profil standard. Elle comprend un support à profil bas pour une installation dans divers châssis d'ordinateur. Accédez à des vitesses allant jusqu'à 25 Gbps (NBASE-T) en utilisant le câblage Cat5e pour utiliser les réseaux et les équipements existants. Profitez de fonctionnalités avancées telles que le pontage audio-vidéo (AVB) pour la transmission de contenu en temps réel sur Ethernet le balisage VLAN la trame jumbo 16K le duplex intégral et PXE. Ce produit est soutenu pendant 2 ans et bénéficie une assistance technique multilingue gratuite à vie 24/5.
IEEE 802.3af and IEEE 802.3at (PoE/PoE+) | 2.5GBASE-T
The Power over Ethernet PCIe network card enables multigigabit speeds of 2.5/1Gbps and 100/10Mbps. This PoE LAN adapter can provide up to 25.5 W of power to a connected device. It combines a network data connection and power over a single Cat5e (or better) Ethernet cable. This PoE NIC is the ideal solution to provide both power and network communication to a remote installation.
Versatile Network PoE Card
The PCIe Ethernet card supports the IEEE 802.3af and IEEE 802.3at (Type 1 and Type 2) standards for Power Sourcing Equipment (PSE) and can deliver up to 48 V DC and 25.5 W of power to compliant Powered Devices (PD). This flexibility eliminates the need for a separate power source for remote networked devices such as IP cameras access control devices remote kiosks and wireless access points.
Enhance Existing Hardware
The network interface card connects to an available x1 PCIe 2.1 (or higher) expansion slot. The card is shipped with a standard-profile bracket. It includes a low-profile bracket for installation in various computer chassis. Access up to 2.5 Gbps (NBASE-T) speeds using Cat5e cabling to utilize existing networks and equipment.
Take advantage of advanced features such as Audio-Video Bridging (AVB) for transmitting real-time content over Ethernet VLAN tagging 16K jumbo frame full-duplex and PXE.
This product is backed for 2 years including free lifetime 24/5 multi-lingual technical assistance.
The StarTech.com Advantage
