Ubiquiti airMAX High Performance NanoBeam NBE-M5-16 16Dbi 5GHz

Incorporating innovative industrial design with advanced technology. the NanoBeam M is the latest generation of Ubiquiti Netw... moreorks airMAX CPE for customer locations.Plug and Play InstallationThe NanoBeam mounts to a variety of surfaces including poles or walls. and offers the freedom of three-axis alignment. No screws are required for pole-mounting. and only a single wall screw (not included) is required for wall-mounting.Incredible Antenna “Beam” PerformanceThe form factor of the NanoBeam features the highest gain for its size. The NanoBeam’s excellent beam directivity provides the best performance in high-noise environments.Advanced Software TechnologyUbiquiti’s airMAX technology is proven in millions of deployments worldwide. exhibiting outstanding performance in outdoor environments. The TDMA airMAX protocol enables unprecedented scalability. high throughput and low latency in unlicensed. multipoint networks. Ubiquiti NanoBeam M5 network antenna 16 dBi

The Ubiquiti NanoBeam M5 16 builds on the platform laid by the Ubiquiti NanoStation. Offering double the antenna performance... moreand housed in a 4 part screwless design the NanoBeam is set to reinvent CPE. The Ubiquiti NanoBeam M5 is both pole and wall mountable featuring a revolutionary ball and socket mechanism. - Frequency - 5 GHz - Throughput - 150 Mbps - Range - 10 km - Pole/Wall Mountable - Weatherproof performance - Double antenna performance over NanoStation - Ball and socket for directional control TX Power Regulation: Yes Comformity: FCC IC CE Default IP: 192.168.1.20 Default Name: ubnt Default Password: ubnt DHCP: Yes Dimension: 140 x 140 x 154 mm Encryption: WPA WPA2 Frequence: 5.170 - 5.875 GHz Channel Sizes: 5/8/10/20/30/40 MHz Gain: 16 dBi Chipset: Atheros Interface: LAN WiFI IPv6 Support: Transparent (Bridge mode) LAN Port: 1x RJ45 10/100 Mbps Max. Output Power: 26 dBm Modulation: OFDM NAND: 8 MB Operation Mode: AP Client WDS Operational Temperature: -40 ~ 70 C OS: AirOS V Polarization: H/V Power Supply: 24 V 0.5 A Processor: MIPS 74Kc 560 MHz RAM: 64 MB Sensitivity: -94 dBm Standards: 802.11a/n Transmission Speed: 150 Mbps Weight: 0.5 kg
