APC RACK PDU BASIC 1 U 16A 230V Basic 0U/1U Single-phase Horizontal/Vertical Black 12 AC outlet(s) AP9559
 | Compare prices 3 → When you make a purchase through links on our site, we may receive a affiliate commission.
|
Buy APC RACK PDU BASIC 1 U 16A 230V Basic 0U/1U Single-phase Horizontal/Vertical Black 12 AC outlet(s) AP9559
When you make a purchase through links on our site, we may receive a affiliate commission.
APC RACK PDU BASIC 1 U 16A 230V power distribution unit (PDU) 12 AC ou | £337.28 |  | |||
APC RACK PDU BASIC 1 U 16A 230V power distribution unit (PDU) 12 AC ou AP9559 | £337.28 |  | |||
APC RACK PDU BASIC 1 U 16A 230V Basic 0U/1U Single-phase Horizontal/Vertical Black 12 AC outlet(s) AP9559 | £348.98 |  | |||
Description:
APC Basic Rack PDU Input : 120 208 230V Input Connection Type : IEC-320 C20 Cord Length : 8.2 feet ( 2.5 meters ) Output : 120 208 230V Output Connections : (10)IEC 320 C13 (2)IEC 320 C19
Features: 19 inch Rack-Mountable Low Cost Power Distribution Vertical Mounting Capabilities
Includes: Cord Retention Clips Rack Mounting Brackets User Manual
Output Voltage(s) (main only) - 120 208 230 V
Maximum Total Current Draw per Phase - 16 A
Output Connections - (10)IEC 320 C13; (2)IEC 320 C19
Always on Outlets - 12
Overload Protection
Input:
Nominal input voltage - 120 208 230
Input frequency (Hz) - 50/60 Hz
Input Connection Type - IEC-320 C20
Cord Length 8.2 feet ( 2.5 meters )
Acceptable Input Voltage - 90-250 VAC
Maximum Line Current per phase - 16.0 A
Maximum Input Current per phase - 16.0 A
Load Capacity - 3680
APC Basic Rack PDU Input : 120 208 230V Input Connection Type : IEC-320 C20 Cord Length : 8.2 feet ( 2.5 meters ) Output : 120 208 230V Output Connections : (10)IEC 320 C13 (2)IEC 320 C19
Features: 19 inch Rack-Mountable Low Cost Power Distribution Vertical Mounting Capabilities
Includes: Cord Retention Clips Rack Mounting Brackets User Manual
Output Voltage(s) (main only) - 120 208 230 V
Maximum Total Current Draw per Phase - 16 A
Output Connections - (10)IEC 320 C13; (2)IEC 320 C19
Always on Outlets - 12
Overload Protection
Input:
Nominal input voltage - 120 208 230
Input frequency (Hz) - 50/60 Hz
Input Connection Type - IEC-320 C20
Cord Length 8.2 feet ( 2.5 meters )
Acceptable Input Voltage - 90-250 VAC
Maximum Line Current per phase - 16.0 A
Maximum Input Current per phase - 16.0 A
Load Capacity - 3680
The product description is generated based on data from online stores. Before purchasing be sure to verify all information directly with the seller.
