C2G 3m Cat6 Booted Unshielded Network Patch Cable - White 83489 (UTP)

3m Cat6 UTP Snagless RJ45 Cable White
Product Description

For fast Ethernet and Gigabit computer networks that require bandwidth-intensive voice data or video distribution applications. Meets all Cat6 TIA/EIA standards and drastically reduces both impedance and structural return loss (SRL). Each of the individual pairs is bonded together to help maintain the twist-spacing throughout the line right up to the termination point. Constructed from high quality copper cable this design minimises Near-End Crosstalk (NEXT) levels. The moulded snagless boot prevents unwanted cable snags during installation and provides extra strain relief. Available in a variety of colours to easily colour-coded your network installation. Each cable is individually labelled with the length for ease of use.


Product Features

• Snagless booted design protects clips when plugging and unplugging
• Standard RJ45 connectors and unshielded twisted pair wires
• Available in 11 colours to colour-code a network
• Available in lengths up to 100m

Product Specifications

Colour :White
Length :3.00 Meter
Jacket Rating :Standard Non-Rated
UPC :757120834892
Warranty :Lifetime
Vendor :C2G
Weight :0.123 KG

• Download the technical specifications on this product from the Support tab

Electrical Characteristics

• Conductor DC Resistance - 9.38Ω 100m (maximum)
• Impedance - 100Ω
• Capacitance - 5600pf/100m
• Propagation Delay - 545ns/100m (maximum)
• Delay Skew - 45ns/100m (maximum)

Physical Characteristics

• Wiring Scheme - T568B
• Standard: Category 6 TIA/EIA-568-B-2.1 draft 9
• Connector: 50 micron gold-plated RJ45
• Temperature Rating – 60?C
• Voltage Rating - 30V
• Approvals - RoHS Compliant
• Warranty – Lifetime
• Package Type – Polybag

Conductor (Qty. 4 twisted pair)

• Conductor Type - 24AWG (7/0.20) Stranded Bare Copper
• Insulation - H-D PE
• Diameter - 0.98 ? 0.05mm
• Colours - Blue Blue-White Orange Orange-White Green Green-White Brown Brown-White

Connector Type (Qty. 2)

• Connector Type - 8P8C (RJ45)
• Gender – Male
• Connector Material – Polycarbonate
• Contact Material - Copper Alloy Gold Plating - 50?m
• Hood Material - Moulded PVC

Overall Cable

• Jacket – PVC
• Minimum Average Thickness - 0.60mm
• Outer Diameter - 6.20 ? 0.30mm

Product Uses

• Gigabit 1000 BASE-T; 100 BASE-T; 10 BASE-T (IEEE 802.3)
• 4/16 Mbps Token Ring (IEEE 802.5); 100 VG-AnyLAN
• 100 Mbps TP-PMD (ANSI X3T9.5); 55/155 Mbps ATM
• Voice; T1
- Features
- Product Type Cat6 UTP (Unshielded) Patch Cable
- Colour White
- Length 3.0m
