C2G Cat6a SSTP 10m networking cable Black S/FTP 89932 (S-STP)
 |
 |
Close
Buy C2G Cat6a SSTP 10m networking cable Black S/FTP 89932 (S-STP)
When you make a purchase through links on our site, we may earn an affiliate commission.
C2G Cat6a SSTP 10m networking cable Black S/FTP (S-STP) 89932 | £27.16 |  | |||
| £30.17 |  | ||||
10m Cat6a Booted Shielded (STP) Network Patch Cable Black
Protect 10 Gigabit data transmissions from 10GBase-T ports and equipment in high noise environments.
• Product #: 89932
• Connector 1: (1) RJ-45 Male
• Connector 2: (1) RJ-45 Male
• Colour: Black
• Length: 10m
Product Description
This Booted Shielded Cat6a patch cable is ideal for use with 10GBase-T ports and equipment such as network adapters hubs switches routers DSL/cable modems and patch panels and will protect a high speed 10 Gigabit network connection from noise and electromagnetic interference. For voice/data/video distribution this cable will handle bandwidth-intensive applications and drastically reduces both impedance and structural return loss (SRL). Each patch cable is fully tested to meet ANSI/TIA 568 C.2 Cat6a component requirements.
Each of the individual pairs is bonded together to help maintain the twist-spacing throughout the line right up to the termination point. Constructed from high quality cable and plugs this design minimises Near-End Crosstalk (NEXT) levels. The moulded snagless boot prevents unwanted cable snags during installation and provides extra strain relief. Available in a variety of colours to easily color-coded a network installation. Each cable is individually labelled with the length for ease of use.
• ISO/IEC 11801: S/FTP (Shielded/ Foiled Twisted Pair); Overall braided Shielding over four Foil-shielded Twisted Pairs.
Product Features
• Snagless booted design protects clips when plugging and unplugging.
• Standard shielded RJ45 connectors and shielded twisted pair wires.
• Available in 4 colours to colour-code a network.
• Available in lengths up to 30m.
Product Specifications
• Colour: Black
• Length: 10.00 Meter
• Jacket Rating: Standard Non-Rated
• UPC: 757120899327
• Warranty: Lifetime
• Vendor: C2G
• Weight: 0.435 KG
Physical Characteristics
• Cable Type: Stranded SSTP
• Wiring scheme: 568B
• Temperature Rating: 75?C
• Testing: ANSI/TIA 568 C.2 Cat6a component tested
• ISO/IEC 11801: S/FTP (Shielded/ Foiled Twisted Pair)
Conductor (4 Pair)
• Conductor Type: 26AWG (7/0.16) (bare copper)
• Insulation: FM-PE
Overall Cable
• Foil Shield: Aluminium foil (100% coverage)
• Braided Shield: Copper braid (40% coverage)
• Jacket: PVC
Connector
• Connector Type: RJ-45 Male
• Shell: Nickel plated for shielding
• Housing: Polycarbonate UL94V-0
• Contacts: 50?m gold plated
• Hood: Moulded Snagless PVC UL94V-0
• Dimension (L x W x H): 38.2 x 11.6 x 15.1
- Features
- Product Type Cat6 Shielded/Cat6A & Cat7 Patch Cable
- Colour Black
- Length 10m
Protect 10 Gigabit data transmissions from 10GBase-T ports and equipment in high noise environments.
• Product #: 89932
• Connector 1: (1) RJ-45 Male
• Connector 2: (1) RJ-45 Male
• Colour: Black
• Length: 10m
Product Description
This Booted Shielded Cat6a patch cable is ideal for use with 10GBase-T ports and equipment such as network adapters hubs switches routers DSL/cable modems and patch panels and will protect a high speed 10 Gigabit network connection from noise and electromagnetic interference. For voice/data/video distribution this cable will handle bandwidth-intensive applications and drastically reduces both impedance and structural return loss (SRL). Each patch cable is fully tested to meet ANSI/TIA 568 C.2 Cat6a component requirements.
Each of the individual pairs is bonded together to help maintain the twist-spacing throughout the line right up to the termination point. Constructed from high quality cable and plugs this design minimises Near-End Crosstalk (NEXT) levels. The moulded snagless boot prevents unwanted cable snags during installation and provides extra strain relief. Available in a variety of colours to easily color-coded a network installation. Each cable is individually labelled with the length for ease of use.
• ISO/IEC 11801: S/FTP (Shielded/ Foiled Twisted Pair); Overall braided Shielding over four Foil-shielded Twisted Pairs.
Product Features
• Snagless booted design protects clips when plugging and unplugging.
• Standard shielded RJ45 connectors and shielded twisted pair wires.
• Available in 4 colours to colour-code a network.
• Available in lengths up to 30m.
Product Specifications
• Colour: Black
• Length: 10.00 Meter
• Jacket Rating: Standard Non-Rated
• UPC: 757120899327
• Warranty: Lifetime
• Vendor: C2G
• Weight: 0.435 KG
Physical Characteristics
• Cable Type: Stranded SSTP
• Wiring scheme: 568B
• Temperature Rating: 75?C
• Testing: ANSI/TIA 568 C.2 Cat6a component tested
• ISO/IEC 11801: S/FTP (Shielded/ Foiled Twisted Pair)
Conductor (4 Pair)
• Conductor Type: 26AWG (7/0.16) (bare copper)
• Insulation: FM-PE
Overall Cable
• Foil Shield: Aluminium foil (100% coverage)
• Braided Shield: Copper braid (40% coverage)
• Jacket: PVC
Connector
• Connector Type: RJ-45 Male
• Shell: Nickel plated for shielding
• Housing: Polycarbonate UL94V-0
• Contacts: 50?m gold plated
• Hood: Moulded Snagless PVC UL94V-0
• Dimension (L x W x H): 38.2 x 11.6 x 15.1
- Features
- Product Type Cat6 Shielded/Cat6A & Cat7 Patch Cable
- Colour Black
- Length 10m
