Tp-link MC111CS
The MC111CS is a media converter designed to convert 100BASE-FX fiber to 10/100Base-TX copper media or vice versa.Adopting WD... moreM technology, MC111CS takes only one fiber cable to transmit and receive data, which will half cable cost for you.Designed with IEEE 802.3u 100Base-TX and 100Base-FX standards, the MC111CS is designed for use with single-mode fiber cable utilizing the SC-Type connector.The MC111CS supports longwave (LX) laser specification at a full wire speed forwarding rate.It works at 1550nm on transferring data and at 1310nm on receiving data.So the other end device to cooperate with the MC111CS should work at 1310nm on transferring data and at 1550nm on receiving data.Another TP-LINK´s media converter MC112CS is just one of the examples to cooperate with MC111CS.Auto MDI/MDI-X for TX port, Auto negotiation of duplex mode on TX port, and front panel status LEDs.The MC111CS will transmit at extended fiber optic distances utilizing single-mode fiber up to 20 kilometers(12.5 miles).TP-Link MC111CS.Maximum data transfer rate:100 Mbit/s, Networking standards:IEEE 802.3, IEEE 802.3u, Ethernet LAN data rates:10,100 Mbit/s.Maximum transfer distance:20000 m, Fiber mode structure:Single-mode.Product colour:Black.Fiber optic connector:SC, Connectivity technology:Wired.Power consumption (max):2.49 W.Complies with 802.3u 10/100Base-TX, 100Base-FX standards Auto-negotiation of Half-Duplex / Full-Duplex transfer mode Adopts WDM technology, transmitting and receiving data on one single fiber Work with MC112CS WDM single fiber media converter Extends fiber distance up to 20km (12.5 miles).
The TP-Link MC111CS is a high-performance fiber converter designed to seamlessly convert 10/100 Mbps Ethernet signals into... more100 Mbps single-mode fiber signals using an SC-type connector. This device supports a maximum data transfer rate of 100 Mbit/s and complies with the IEEE 802.3 and IEEE 802.3u networking standards, ensuring reliable and efficient data transmission. The MC111CS is capable of handling Ethernet LAN data rates of 10 and 100 Mbit/s, and it supports both full and half duplex communication modes, making it versatile for various networking needs.
Equipped to work with CAT3, CAT4, CAT5, and CAT5e network cables, the TP-Link MC111CS enhances compatibility with existing network infrastructures. This converter boasts an impressive maximum transfer distance of up to 20,000 meters, allowing for extended network reach without compromising signal quality. The compact black casing not only provides a sleek appearance but also houses a device with a maximum power consumption of just 2.49 watts, making it an energy-efficient choice for network expansion or bridging.
Ideal for use in telecommunications networks, data centers, and large-scale enterprise environments, the TP-Link MC111CS excels in scenarios where long-distance fiber optic transmission is essential. Its wired connectivity technology ensures stable and secure connections, providing a significant advantage over wireless alternatives. With its robust performance and energy efficiency, the MC111CS stands out as a reliable solution for enhancing network capabilities in demanding environments.
...
TP-Link MC111CS WDM Fast Ethernet Media Converter (SC, Single-mode)
The MC111CS is a media converter designed to convert 100BASE-FX fiber to 100Base-TX copper media or vice versa. Adopting WDM... moretechnology, MC111CS takes only one fiber cable to transmit and receive data, which will save half cabling cost for you. Designed under IEEE 802.3u 10/100Base-TX and 100Base-FX standards, the MC111CS is designed for use with single-mode fiber cable utilizing the SC-Type connector.
Complies with 802.3u 10/100Base-TX, 100Base-FX standards Link Fault Passthrough and Far End Fault minimize the loss caused by... morelink failure timely Adopts WDM technology, transmitting and receiving data on one single fiber What This Product Does: The MC111CS is a media converter designed to convert 100BASE-FX fiber to 100Base-TX copper media or vice versa. Adopting WDM technology, MC111CS takes only one fiber cable to transmit and receive data, which will save half cabling cost for you. Designed under IEEE 802.3u 10/100Base-TX and 100Base-FX standards, the MC111CS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MC111CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1550nm on transferring data and at 1310nm on receiving data. So the other end device to cooperate with the MC111CS should work at 1310nm on transferring data and at 1550nm on receiving data. Another TP-LINK`s media converter MC112CS is just one...
TP-Link Omada MC111CS network media converter 100 Mbit/s Single-mode Black
Complies with 802.3u 10/100Base-TX, 100Base-FX standards. Auto-negotiation of Half-Duplex / Full-Duplex transfer mode. Adopts... moreWDM technology, transmitting and receiving data on one single fiber. Work with MC112CS WDM single fiber media converter. Extends fiber distance up to 20km (12.5 miles). The MC111CS is a media converter designed to convert 100BASE-FX fiber to 10/100Base-TX copper media or vice versa. Adopting WDM technology, MC111CS takes only one fiber cable to transmit and receive data, which will half cable cost for you. Designed with IEEE 802.3u 100Base-TX and 100Base-FX standards, the MC111CS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MC111CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1550nm on transferring data and at 1310nm on receiving data. So the other end device to cooperate with the MC111CS should work at 1310nm on transferring data and at 1550nm on receiving data. Another TP-LINK´s media converter MC112CS is just one of the examples to cooperate with MC111CS. Auto MDI/MDI-X for TX port, Auto negotiation of duplex mode on TX port, and front panel status LEDs. The MC111CS will transmit at extended fiber optic distances utilizing single-mode fiber up to 20 kilometers(12.5 miles).. Network. Maximum data transfer rate. 100 Mbit/s. Networking standards. IEEE 802.3, IEEE 802.3u. Ethernet LAN data rates. 10,100 Mbit/s. Auto MDI/MDI-X. Yes. Duplex system. Full, Half. Cable types supported. Cat3, Cat4, Cat5, Cat5e. Performance. Maximum transfer distance. 20000 m. Wavelength-division multiplexing (WDM). Yes. Fiber mode structure. Single-mode. Features. Internal. No. Product colour. Black. LED indicators. Yes. Ports & interfaces. Connectivity technology. Wired. Ethernet LAN (RJ-45) ports. 1. Fiber ports quantity. 1. Fiber optic connector. SC. Power. Power consumption (max). 2.49 W. Weight & dimensions. Width. 95 mm. Depth. 73 mm. Height. 27 mm. Operational conditions. Operating temperature (T-T). 0 - 40 °C. Storage temperature (T-T). -40 - 70 °C. Operating relative humidity (H-H). 10 - 90%. Storage relative humidity (H-H). 5 - 90%. Packaging content. Manual. Yes. General. Product family. Omada. Certificates. Compliance certificates. RoHS. Logistics data. Harmonized System (HS) code. 85176990. leaflet. manual pdf
The MC111CS is a media converter designed to convert 100BASE-FX fiber to 10/100Base-TX copper media or vice versa. Adopting W... moreDM technology. MC111CS takes only one fiber cable to transmit and receive data. which will half cable cost for you. Designed with IEEE 802.3u 100Base-TX and 100Base-FX standards. the MC111CS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MC111CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1550nm on transferring data and at 1310nm on receiving data. So the other end device to cooperate with the MC111CS should work at 1310nm on transferring data and at 1550nm on receiving data. Another TP-LINK´s media converter MC112CS is just one of the examples to cooperate with MC111CS. Auto MDI/MDI-X for TX port. Auto negotiation of duplex mode on TX port. and front panel status LEDs. The MC111CS will transmit at extended fiber optic distances utilizing single-mode fiber up to 20 kilometers(12.5 miles). TP-Link Omada MC111CS network media converter 100 Mbit/s Single-mode Black
The MC111CS is a media converter designed to convert 100BASE-FX fiber to 10/100Base-TX copper media or vice versa.Adopting WDM technology, MC111CS takes only one fiber cable to transmit and receive data, which will half cable cost for you.Designed with IEEE 802.3u 100Base-TX and 100Base-FX standards, the MC111CS is designed for use with single-mode fiber cable utilizing the SC-Type connector.The MC111CS supports longwave (LX) laser specification at a full wire speed forwarding rate.It works at 1550nm on transferring data and at 1310nm on receiving data.So the other end device to cooperate with the MC111CS should work at 1310nm on transferring data and at 1550nm on receiving data.Another TP-LINK´s media converter MC112CS is just one of the examples to cooperate with MC111CS.Auto MDI/MDI-X for TX port, Auto negotiation of duplex mode on TX port, and front panel status LEDs.The MC111CS will transmit at extended fiber optic distances utilizing single-mode fiber up to 20 kilometers(12.5 miles).TP-Link MC111CS.Maximum data transfer rate:100 Mbit/s, Networking standards:IEEE 802.3, IEEE 802.3u, Ethernet LAN data rates:10,100 Mbit/s.Maximum transfer distance:20000 m, Fiber mode structure:Single-mode.Product colour:Black.Fiber optic connector:SC, Connectivity technology:Wired.Power consumption (max):2.49 W.Complies with 802.3u 10/100Base-TX, 100Base-FX standards Auto-negotiation of Half-Duplex / Full-Duplex transfer mode Adopts WDM technology, transmitting and receiving data on one single fiber Work with MC112CS WDM single fiber media converter Extends fiber distance up to 20km (12.5 miles).
