4K/UHD 5-Input HDMI Switcher with Two HDBaseT Inputs and Mirrored HDMI / H

The Atlona AT-UHD-SW-5000ED is a 5 x 1 switcher with two HDBaseT inputs three HDMI inputs mirrored HDMI and HDBaseT outputs balanced audio outputs automatic input selection and automatic display control capability. The HDBaseT inputs match perfectly with the HDVS-200-TX modules to enable VGA and HDMI sources to be easily integrated into a system. The switcher supports 4K/UHD @ 60 Hz 4:2:0; (10.2 Gbps). It transmits AV signals along with Ethernet power and control over a single cable to displays up to 328 feet (100 meters) from the switcher. Control options include automatic input selection front-panel buttons and compatibility with IR RS-232 or TCP/IP-based control systems. Displays are automatically turned on and off using CEC IP or RS-232.

The AT-UHD-SW-5000ED enables two HDVS transmitters to be used in a single system. With Ethernet enabled HDBaseT transmission to the HDVS transmitters and the receiver control setup and maintenance is simplified. Automatic input selection and display control simplify the system reducing cost reducing setup time and resulting in a better end user experience.

Two Ethernet-enabled HDBaseT Inputs
• Supports two HDVS-150 or HDVS-200 Series transmitters for placement at remote sources near lecterns conference tables and instructor’s desks
• Simplifies integration of remote sources by eliminating power supplies when used with PoE-powered transmitters; single category cable carries AV signals control and power

Mirrored dual outputs on HDMI and HDBaseT
• Supports dual display environments with local and extended distance 328 foot (100 meter) displays
• Eliminates cost associated with extra extension components; simplifies installation. HDMI output can be used with additional HDBaseT transmitter

Automatic display control
• Automatically changes projector power state based on active or standby mode of switcher. Control signals transmitted via CEC IP or RS-232
• Eliminates need for complex control system in AV systems. Enables display and volume control directly. CEC enables control of low-cost consumer displays
• Any product that has mirrored output with HDMI and HDBaseT will have CEC functionality through the HDBaseT output

Automatic input selection using hot plug detect and video detection technology
• Selects active input when sources are connected or if there is a change in source power status
• Eliminates need for complex control system in AV systems

Ethernet-enabled HDBaseT
• Simplifies installation maintenance with IP controlled switcher transmitters and receivers using Atlona AMS
• Configure backup update maintain and monitor from a simple PC interface

IR RS-232 and Ethernet HDBaseT insertion
• Adds internally-generated or externally-generated display control signals to the HDBaseT transmission
• Simplifies display control from third-party control systems

EDID management and HDCP management
•
