Atlona Three-Input Switcher for HDMI and USB-C AT-OME-ST31A

AT-OME-ST31A

• 3?1 HDBaseTTM switcher with HDMI? and USB-C inputs
• Mirrored HDBaseT and HDMI outputs
• Designed for remote powering over HDBaseT
• Local powering available with optional AT-PS-245-D4 power supply
• 4K/UHD capability @ 60 Hz with 4:4:4 chroma sampling on local ports (HDMI and USB-C)
Selectable 4K to 1080p downscaling
• Automatic input selection and automatic display control
• Audio de-embedding

The Atlona AT-OME-ST31A is a 3?1 switcher and HDBaseT transmitter designed for remote powering with HDMI and USB-C inputs. The OME-ST31A features two-channel audio de-embedding to an analog balanced audio output. Part of the Omega™ Series of integration products for modern AV communications and collaboration the OME-ST31A features mirrored HDMI and HDBaseT outputs and is HDCP 2.2 compliant. The USB-C input is ideal for AV interfacing with newer Mac? Chromebook™ and Windows? PCs as well as smartphones and tablets. Video signals up to 4K/60 4:2:0 plus embedded audio control and Ethernet can be transmitted over HDBaseT up to 330 feet (100 meters). All inputs and the local HDMI output support 4K HDR and 4K/60 4:4:4 at HDMI data rates up to 18 Gbps. Additionally 4K downscaling to 1080p @ 60 30 or 24 Hz is available for the HDMI output when connected to an HD sink. The OME-ST31A is designed for use with Omega Series receivers and switchers select HDVS Series receivers such as the AT-HDVS-SC-RX scaler the AT-UHD-EX-100CE-RX receiver and other Atlona switchers with HDBaseT inputs.

All-in-One Switcher Controller and Extender

This switching transmitter can serve as an integral component of a fully automated AV system with the convenience of automatic input selection and display control. It can be remotely powered by Atlona HDBaseT-equipped devices. With the optional AT-PS-245-D4 power supply the OME-ST31A can provide powering to a compatible receiver and also charge laptops and mobile devices through the USB-C port. For additional integration convenience the OME-ST31A features TCP/IP and RS-232 control RS-232 insertion over HDBaseT and remote management with Atlona Management System (AMS).

Automatic Display Control

The OME-ST31A provides control to a display through TCP/IP RS-232 or CEC* without the need for a separate control system. This simplifies system design and integration while reducing costs. With automatic display control the OME-ST31A can trigger a display to power on automatically whenever a laptop or other device is connected. At the end of the presentation when the presenter disconnects the laptop the OME-ST31A forces the display to power off. Ease of presenter interaction with the system and the savings incurred by automatic display shutdown provide a significant return on investment. The OME-ST31A display control capability can also be triggered by an external control system.

* Consumer Electronics Control (CEC): Atlona does not guarantee the function of CEC
