Atlona Display Controller Black AT-DISP-CTRL

Display Controller

• Simple automated display control via IP RS-232 IR or CEC
• Programmable display control modes
• 4K/UHD capability @ 60 Hz with 4:4:4 chroma sampling plus support for HDR formats
• Local or PoE (Power over Ethernet) powering
• Comprehensive display driver selection from the VelocityTM Control System database
• Dual Ethernet ports and integrated network switch

The Atlona AT-DISP-CTRL is a compact display controller designed for small meeting spaces and huddle rooms. The DISP-CTRL detects connection of a source device with an active signal and then automatically sends a control command to power up a display. Similarly when the device is disconnected the DISP-CTRL delivers a command to power down the display. The DISP-CTRL can be configured to deliver pre-stored or user-programmed display control commands through TCP/IP RS-232 IR or CEC. Additionally this controller includes EDID and HDCP management features and can be powered locally or through Power over Ethernet (PoE). The DISP-CTRL is HDCP 2.2 compliant and supports 4K/UHD video @ 60 Hz with 4:4:4 chroma sampling as well as HDMI data rates up to 18 Gbps.

The DISP-CTRL enables simple plug-and-play operation for a presenter – while eliminating the need to rely on a handheld remote control that is often misplaced or non-functional (dead batteries). The DISP-CTRL can be used on its own or in conjunction with an HDMI switcher such as the JunoX™ 451 (AT-JUNO-451). The AT-IR-CS-TX emitter cable is available for controlling a display through IR. For additional integration convenience the DISP-CTRL features adjustable standby and lamp cooldown timer modes TCP/IP and RS-232 control and remote management with Atlona Management System (AMS). A comprehensive selection of display drivers from the Velocity™ Control System driver database is available for setting IR RS-232 or IP control commands.

Applications

Huddle rooms and open meeting spaces – The DISP-CTRL provides a simple automation solution for BYOD connectivity in any gathering area with a display installed but no other AV equipment.
AV system upgrades/ – The DISP-CTRL is ideal as an easy problem-solver for legacy AV installations to provide automatic display control capabilities.
Control systems – Use the DISP-CTRL to easily add a new display to an existing control system while avoiding the need for extensive reprogramming.

FEATURES

• Simple automated display control

• Automatically changes display power state based on HDMI device connection or disconnection. Control signals to display are transmitted via IP RS-232 IR or CEC.
• Enables display volume control and input selection
• Avoids the need for a handheld remote control which may be misplaced or non-functional

HDCP management

• Automatically reports HDCP compliance status to the source based on the sink device
• HDCP compliance can also be
