Cisco 5463168

The Cisco Catalyst 9300 Series is a best-in-class fixed switching platform switch for Cisco enterprise access.Perfect access switch for large enterprise branch and facility environments that need scalability and an extra degree of security, resiliency, and programmability.Specifications:General:- Type Of Device:Switch.- 24 Ports.- L3.- Managed.- Stackable.- Type Of Box:Rackmount.- Subtype:Gigabit Ethernet.- Ports:24 X 10/100/1000 (Poe+) + 4 X Gigabit Sfp (Uplink).- Power Over Ethernet (Poe):Poe+.- Poe Budget:505 W.-.Performance:Switching Capacity:128 Gbps.- Stackable Bandwidth:320 Gbps.- Stackable Switching Capacity:448 Gbps.- Transmission Rate:95.23 Mpps.- Stackable Transmission Rate:333.33 Mpps Ability:- Ipv4 Routes:32000.- Ipv6 Routes:16000.- Multicast Scale:8000.- Qos Scale Entries:5120.- Acl Scale Entries:5120.- Supported Vlans:4094.- Fnf Entries:64000.- Switched Virtual Interfaces (Svis):1000.- Packet Buffer Size:16 Mb.- Virtual Networks:64.- Mac Address Table Size:32000 Entries.- Supports Jumbo Case:9198 Bytes.- Standards Compliance:Ieee 802.3,Ieee 802.3u,Ieee 802.3z,Ieee 802.1d,Ieee 802.1q,Ieee 802.3ab,Ieee 802.1p,Ieee 802.3af,Ieee 802.3x,Ieee 802.3ad (Lacp),Ieee 802.1w,Ieee 802.1x,Ieee 802.1s,Ieee 802.1ae,Ieee 802.3at,Ieee 1588v2,Ieee 802.1ba,Wi-Fi Certified 6.- Ram Memory:8 Gb.- Flash Memory:16 Gb.- Embedded Devices:Rfid Tag.- Status Indicators:State Expansion / Connectivity:Interfaces:- 24 X 1000base-T Rj-45.- 4 X 10gbase-X Sfp+ Upstream.- 1 X Network Stacking Device.- 1 X Management (Lan) Rj-45.- 1 X Console.- 1 X Usb 2.0 Feeding:- Feeding Device:Power Supply.- Hot Plug.- Installed Quantity:1.- Maximum Amount Supported:2.- Power Redundancy:Optional.- Supplied Power:715 Watts.- Required Voltage:Ca 120/230 V (50.- 60 Hz) Different:- Mtbf (Mean Time Between Errors):340,710 Hours Dimensions And Weight:- Width:44.5 Cm.- Depth:4.4 Cm.- Height:48.8 Cm.- Weight:6.81 Kg Environment Parameters:- Minimum Operating Temperature:-5 °C.- Maximum Operating Temperature:45 °C.- Operating Humidity Range:5.- 90% (Non-Condensing).- Minimum Storage Temperature:-40 °C.- Storage Temperature:70 °C.- Storage Humidity Scope:5.- 90% (Non-Condensing).
