TP-Link TL-SF1005LP 5-Port 10/100 Mbps Desktop Switch with TL-SF1005LP
The TP-Link TL-SF1005LP is a reliable 5-Port 10/100Mbps Desktop Switch designed to enhance your network connectivity. This... moreunmanaged switch features five RJ-45 Ethernet ports that support speeds of 10/100 Mbps, making it an ideal solution for small offices and home environments. With a robust MAC address table supporting up to 2000 entries and a switching capacity of 1 Gbit/s, it ensures efficient data handling and minimal traffic congestion, allowing for seamless communication between devices.
One of the standout features of the TP-Link TL-SF1005LP is its Power over Ethernet (PoE) capability on four of its ports. This functionality simplifies the deployment of network devices such as IP cameras, VoIP phones, and wireless access points by eliminating the need for separate power supplies. This is particularly advantageous in locations where power outlets are limited or unavailable, making installation straightforward and efficient.
Compliant with various networking standards including IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, and IEEE 802.3x, the TP-Link TL-SF1005LP ensures broad compatibility and reliable performance across different network environments. Its full duplex mode operation further enhances data flow, providing a significant advantage over competing models that may not offer such efficiency. This switch is an excellent choice for users looking to expand their network capabilities without compromising on performance.
...
TP-Link 5-Port 10/100Mbps Desktop Switch with 4-Port PoE TL-SF1005LP
5× 10/100 Mbps RJ45 ports. 4× PoE ports transfer data and power on individual cables. Works with IEEE 802.3af compliant PDs.... moreUp to 250 m data and power transmitting range under Extend Mode**. Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application. Supports PoE Power up to 41 W for all PoE ports*. Plug and play with no configuration required. Professional Fast Ethernet Switch with 4 PoE Ports. Plug and Play, with PoE Transmission for Surveillance up to 250 m. TL-SF1005LP. Dedicated 4-Port PoE Switch (41 W Budget) for Numerous Applications. Compliance with the 802.3af PoE standard supports up to 15.4 W on each PoE port. The total 41 W PoE power budget* for the 4× PoE ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.. Ideal for IP Surveillance. —Up to 250 m Transmissions. With extend mode, the PoE transmission distance reaches up to 250 m**—perfect for IP Camera deployment in large areas.. The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.. Priority Video. Quality Guaranteed. Quality of sensitive applications like video monitoring in critical business areas is guaranteed by offering higher priority options for ports 1–2 when one-touch Priority Mode is on.. Intelligent Power Management. When total power consumption exceeds 41 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.. Durable Metal Casing. The interior components of TL-SF1005LP are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SF1005LP delivers switching performance you can depend on.. Management features. Switch type. Unmanaged. Ports & interfaces. Basic switching RJ-45 Ethernet ports type. Fast Ethernet (10/100). Basic switching RJ-45 Ethernet ports quantity. 5. Network. MAC address auto-aging supported. Yes. Flow control support. Yes. Auto MDI/MDI-X. Yes. Auto-negotiation. Yes. Half duplex. Yes. Full duplex. Yes. Cable types supported. Cat3, Cat4, Cat5, Cat5e. Copper ethernet cabling technology. 10BASE-T, 100BASE-TX. 10G support. No. Networking standards. IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. Data transmission. Jumbo frames. 2000. Jumbo frames support. Yes. Store-and-forward. Yes. Forwarding rate. 0.744 Mpps. Switching capacity. 1 Gbit/s. MAC address table. 2000 entries. Design. LED indicators. Yes. Product colour. Black. Rack mounting. No. Performance. Fanless. Yes. Power. Power
The TP-LINK (TL-SF1005LP) 5-Port 10/100 Unmanaged Desktop Switch is ideal for applications requiring both data and power tran... moresmission, such as IP surveillance setups. Its intelligent power management and priority mode ensure reliable operation and quality service for critical applications. The Extend Mode extends PoE transmission distance up to 250 m, ideal for IP camera deployment in large areas.&.nbsp.&.nbsp. Rackmountable: No&.nbsp.&.nbsp. Managed: No&.nbsp.&.nbsp. Number of Ports: 5 (4 PoE ports)&.nbsp.&.nbsp. Max RJ45 Transfer Rate: 10/100 Mbps&.nbsp.&.nbsp. Interface(s): 5 x 10/100 Mbps RJ45 (Ports 1-4 support 802.3af PoE)&.nbsp.&.nbsp. Auto-Negotiation: Auto MDI/MDIX&.nbsp.&.nbsp. PoE Ports (RJ45): Standard: 802.3af compliant, Ports 1-4&.nbsp.&.nbsp. Power Supply: External Power Adapter (Output: 53.5 V DC / 0.81 A)&.nbsp.&.nbsp. Switching Capacity: 1 Gbps&.nbsp.&.nbsp. Power Consumption: 1.9 W (no PD connected), 47 W (w...
Tp-link 5 Port Fast Ethernet Desktop Switch with PoE TL-SF1005LP
Simple unmanaged five port switch that features PoE support, ideally suited for expanding a home or office network. Features... morededicated Extend Mode, Priority function and 41W power budget for Powered Devices. 4 LAN ports support 802.3af PoE with a power budget of 41W (15.4W per port) 250m Power/data range with Extend Mode at 10Mb/s per port, ideal for IP camera deployment Priority Mode ensures service quality for business critical connected devices on ports 1 & 2 1Gb/s Switching capacity and 2K MAC address table Plug and play setup, no configuration required Durable metal casing with fanless design Dimensions (HxWxD): 25x100x98mm UK mains plug (type G), as used in the UK, IRL, Cyprus, Saudi Arabia, Malta and many others.
Professional Fast Ethernet Switch with 4 PoE PortsPlug and Play. with PoE Transmission for Surveillance up to 250 mTL-SF1005L... morePDedicated 4-Port PoE Switch (41 W Budget) for Numerous ApplicationsCompliance with the 802.3af PoE standard supports up to 15.4 W on each PoE port. The total 41 W PoE power budget* for the 4× PoE ports opens up a wide range of applications. such as surveillance for offices. dormitories. and small businesses. It is fully compatible with IP cameras. access points. IP phones. computers. printers. and more.Ideal for IP Surveillance—Up to 250 m TransmissionsWith extend mode. the PoE transmission distance reaches up to 250 m**—perfect for IP Camera deployment in large areas.The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.Priority VideoQuality GuaranteedQuality of sensitive applications like video monitoring in critical business areas is guaranteed by offering higher priority options for ports 1–2 when one-touch Priority Mode is on.Intelligent Power ManagementWhen total power consumption exceeds 41 W. the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.Durable Metal CasingThe interior components of TL-SF1005LP are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests. TL-SF1005LP delivers switching performance you can depend on. TP-Link 5-Port 10/100Mbps Desktop Switch with 4-Port PoE
Professional Fast Ethernet Switch with 4 PoE Ports
Plug and Play with PoE Transmission for Surveillance up to 250 m
TL-SF... more1005LP
Dedicated 4-Port PoE Switch (41 W Budget) for Numerous Applications
Compliance with the 802.3af PoE standard supports up to 15.4 W on each PoE port. The total 41 W PoE power budget* for the 4 PoE ports opens up a wide range of applications such as surveillance for offices dormitories and small businesses. It is fully compatible with IP cameras access points IP phones computers printers and more.
Ideal for IP Surveillance
Up to 250 m Transmissions
With extend mode the PoE transmission distance reaches up to 250 m**perfect for IP Camera deployment in large areas.
The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.
Priority Video
Quality Guaranteed
Quality of sensitive applications like video monitoring in critical business areas is guaranteed by offering higher priority options for ports 12 when one-touch Priority Mode is on.
Intelligent Power Management
When total power consumption exceeds 41 W the intelligent power management will cut the lower priority port power. This ensures the high priority ports power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.
Durable Metal Casing
The interior components of TL-SF1005LP are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests TL-SF1005LP delivers switching performance you can depend on.
