Lindy 15m Cat.6 U/UTP Network Cable Blue 48023
 | Compare prices 3 → When you make a purchase through links on our site, we may receive a affiliate commission.
|
Buy Lindy 15m Cat.6 U/UTP Network Cable Blue 48023
When you make a purchase through links on our site, we may receive a affiliate commission.
Lindy 15m Cat.6 U/UTP Network Cable, Blue | £19.46 |  | |||
Lindy 15m Cat.6 U/UTP Network Cable. Blue | £25.60 |  | |||
Lindy 15m Cat.6 U/UTP Network Cable Blue 48023 | £28.67 |  | |||
15m Cat.6 U/UTP Network Cable Blue
Product Details
• Twisted Pair Patch Cable with RJ45 connectors.
• Cat.6 F/UTP PVC.
• Integrated snagless connector for latch protection.
• Gold plated pins for better conductivity and elimination of signal loss.
• 10 year warranty.
Cat.6 U/UTP LSZH network cable with support for bandwidth up to 250MHz and features a snagless design with gold plated contacts for ethernet standards up to 1GBase-T.
Cat.6 cable for operating frequencies up to 250MHz. The unshielded version (U/UTP) can be used for Gigabit Ethernet thanks to the special design of the electrophysical parameters (NExT FExT etc.) despite the lack of shielding. These cables are manufactured and tested according to the ISO/IEC 11801 specification. The cables are packaged individually in a polybag.
The gold-plated contacts ensure reliable corrosion-free connections over extensive periods of time. A robust snagless strain relief design prevents damage to the connector latch during installation and removal.
The halogen-free sheath material of the LSZH cable makes the product suitable for use in public spaces with its low smoke emission and elimination of toxic halogen emissions.
Technical Information
Connectors
• Connector A: RJ45 Male
• Connector B: RJ45 Male
• Housing Material: Polycarbonate
• Pin Construction: Copper Alloy
• Pin Plating: Gold plated
• Dimensions (approx.) WxDxH: 11.6x22.8x8.3mm (0.46x0.90x0.33in)
Cable Construction
• Length: 15m (49.21ft)
• Colour: Blue
• Type: Cat.6
• Jacket Diameter: 5.8mm (0.23in)
• Jacket Material: PVC
• Conductor Material: Copper
• Conductor Gauge: 24AWG
Specifications
• Supported Bandwidth: 250MHz
• Nominal Attenuation: 32.8dB/100m @250MHz
• Minimum Band Radius: 69mm (2.72in)
• Operating Temperature: -10?C - 60?C (14?F - 140?F)
• Storage Temperature: -20?C - 75?C (-4?F - 167?F)
Miscellaneous
• Packaging Type: Polybag
• Warranty (Years): 10
• Certificated: RoHS REACH UL California Proposition 65
Purchasing Information
• No.: 48023
• EAN: 4002888480239
- Features
- Product Type Cat6 UTP (Unshielded) Patch Cable
- Colour Blue
- Length 15.0m
Product Details
• Twisted Pair Patch Cable with RJ45 connectors.
• Cat.6 F/UTP PVC.
• Integrated snagless connector for latch protection.
• Gold plated pins for better conductivity and elimination of signal loss.
• 10 year warranty.
Cat.6 U/UTP LSZH network cable with support for bandwidth up to 250MHz and features a snagless design with gold plated contacts for ethernet standards up to 1GBase-T.
Cat.6 cable for operating frequencies up to 250MHz. The unshielded version (U/UTP) can be used for Gigabit Ethernet thanks to the special design of the electrophysical parameters (NExT FExT etc.) despite the lack of shielding. These cables are manufactured and tested according to the ISO/IEC 11801 specification. The cables are packaged individually in a polybag.
The gold-plated contacts ensure reliable corrosion-free connections over extensive periods of time. A robust snagless strain relief design prevents damage to the connector latch during installation and removal.
The halogen-free sheath material of the LSZH cable makes the product suitable for use in public spaces with its low smoke emission and elimination of toxic halogen emissions.
Technical Information
Connectors
• Connector A: RJ45 Male
• Connector B: RJ45 Male
• Housing Material: Polycarbonate
• Pin Construction: Copper Alloy
• Pin Plating: Gold plated
• Dimensions (approx.) WxDxH: 11.6x22.8x8.3mm (0.46x0.90x0.33in)
Cable Construction
• Length: 15m (49.21ft)
• Colour: Blue
• Type: Cat.6
• Jacket Diameter: 5.8mm (0.23in)
• Jacket Material: PVC
• Conductor Material: Copper
• Conductor Gauge: 24AWG
Specifications
• Supported Bandwidth: 250MHz
• Nominal Attenuation: 32.8dB/100m @250MHz
• Minimum Band Radius: 69mm (2.72in)
• Operating Temperature: -10?C - 60?C (14?F - 140?F)
• Storage Temperature: -20?C - 75?C (-4?F - 167?F)
Miscellaneous
• Packaging Type: Polybag
• Warranty (Years): 10
• Certificated: RoHS REACH UL California Proposition 65
Purchasing Information
• No.: 48023
• EAN: 4002888480239
- Features
- Product Type Cat6 UTP (Unshielded) Patch Cable
- Colour Blue
- Length 15.0m
