Equip 90051070

The equip® Cat.6A S/FTP Patch Cord is composed of preeminent materials and fully-examined to conform with industrial standards. Offering higher bandwidth and better signal-to-noise margin, the Cat.6A cable is able to deliver ultrahigh and error-free performance in the most demanding network environments, specially for 10G application. Features:- 26AWG- Stranded bare copper conductor- S/FTP, Double Shielding- Gold Plated Connectors for high signal quality- Molded boot with Strain relief- Low Smoke Zero Halogen (LSZH/LSOH)- RoHS compliantSpecifications:- Cable length: 30 m- Cable standard: Cat6a- Cable shielding: S/FTP (S-STP)- Connector 1: RJ-45- Connector 2: RJ-45- Connector 1 gender: Male- Connector 2 gender: Male- Connector contacts plating: Gold- Jacket material: Low smoke zero halogen (LSZH)- Conductor type: Stranded- Conductor material: Copper- Cabling technology: 10GBase-T- Networking standards: IEEE 802.3,IEEE 802.5- AWG wire size: 26- Data transfer rate: 10000 Mbit/s- Frequency: 500 MHz- Molded cable boot: Yes- Plug and Play: YesWeight & dimensions: - Width: 8,34 mm- Depth: 11,7 mm- Height: 30000 mm- Weight: 935 gPackaging data: - Quantity per pack: 1 pc(s)- Package weight: 435 gTechnical details: - Sustainability certificates: RoHS- Doesn´t contain: Halogen- Insulation outer diameter: 1,05 mm
