Digitus PCIe card, USB Type-C™ + USB-A DS-30225

Expand your computer with two external USB 3.1 ports to connect various USB devices, such as docking stations, card readers or external boxes. The card has 2 external USB 3.1 ports: 1 USB-A port and 1 USB Type-C™ port that enables data transfer speeds of up to 10 Gbps. It is also possible to install the card in a small computer case using the low p... morerofile opening.Features:- Super high transfer speed USB 3.1 up to 10Gbps- 1 x 10Gbps Super High Speed USB Type-C™ port (USB 3.1 Gen 2)- 1 x 10Gbps Super High Speed USB A port (USB 3.1 Gen 2)- Supports data transmission speeds of 10G, 5G, 480Mbps, 12Mbps and 1.5Mbps- 5V/3A power USB Type-C™ port- USB Type-A port for 5V/900mA power- 15-pin SATA connector for additional power supply from the motherboard- Compatible with PCI Express 4 lane v 2.0- Compliant with the Extensible Host Controller Interface (xHCI) 1.1 specification- Supports multiple INs- Overvoltage protection- Supports remote wake-up function via keyboard or mouse- PCI Express USB 3.1 interface card with 2 external USB 3.1 ports: 1 USB-A and 1 USB Type-C™ for next-generation devicesSpecifications: System Requirements:- Supported Linux operating system: Yes- Supported Windows operating system: Windows 10, Windows 7, Windows 8, Windows 8.1Ports And Interfaces:- Number of Type A ports USB 3.2 Gen 2 (3.1 Gen 2): 1- Number of Type-C ports USB 3.2 Gen 2 (3.1 Gen 2): 1- Expansion card standard: PCIe 2.0- Expansion card form factor: Full-height / Low-profile- Host interface: PCIe- Output interface: USB 3.2 Gen 2 (3.1 Gen 2)- SATA power connector type: SATA 15 pinWeight And Measurements:- Height: 141mm- Broad: 153mm- Weight: 50g- Depth: 30mmPower Control:- Output current: 3A- Output voltage: 5VDesign:- Internal: YesCharacteristics:- Data transfer rate (max): 10 Gbit/s

Slot PCIe 2.0 x4 / External Ports 1 x USB 3.2 Gen2
