MUNK type 2, type 2, without safety cage

Tank truck ladder, type 2, without safety cage. Supplied = assembled. Platform depth = 1080 mm. Platform width = 850 mm. Platform height = 4300 mm. Access type = rungs. Steps incl. platform = 19 pcs. Weight = 390 kg. Frame material = aluminium. Max. load = 150 kg. Height = 5400 mm. Width = 2040 mm. Depth = 3160 mm. Access = single sided. Working height = 6300 mm. Customs tariff number = 76169990. Country of origin = DEU. Gross weight = 393 kg. Weight = 390 kg. With 2 swivel castors Ø 150 mm (access), 2 castors Ø 280 mm (support section). Sturdy, rectangular tubular rails. Platform with grate cover R13. Rectangular rungs 30 x 30 mm textured on both sides. Rung-rail connection with 4-fold beading. Guide and connecting parts in stainless steel. The 2 section aluminium tank truck ladder with platform and safety cage (mandatory element, must be ordered separately) allows easy height adjustment from rung to rung thanks to a cable winch and locking mechanism. The platform end offers a 2 part safety door and a protective cage (different options available, must be ordered separately). Note: the tank truck ladder is used exclusively as access for operating or inspection work during loading and unloading.
