ATEN 2-Port USB DVI with Audio CS682-AT

Superior video quality - up to 1920 x 1200 @ 60 Hz. Computer selection via a remote port selector, hotkeys, and USB mouse. Independent switching of the KVM and Audio focus - one computer has the KVM focus and the other the Audio focus. Built-in all-in-one cables (2 x 1.2 m) and bus-powered design. The CS682 takes a giant step forward from prior models in the Petite series, by offering DVI functionality, USB 2.0 peripheral sharing, and a rich bass experience for 2.1 surround systems. Another new feature of the CS682 is the implementation of a remote port selector. This means that you can now control port switching from the desktop while the switch itself can be placed in a convenient, out of the way, location.. 1x CS682 2-Port USB 2.0 DVI KVM Switch. 1x Remote Port Selector. 1x User Instructions. Ports & interfaces. Number of microphone inputs. 3. Headphone outputs. 3. Audio connections. Yes. USB connector type. USB Type-A, USB Type-B. USB 2.0 Type-A hub ports quantity. 4. Console ports. 3.5mm headphone, 3.5mm mic, DVI-D, USB A. Console USB ports quantity. 2. DVI-D ports quantity. 2. Video port type. DVI-D. Mouse port type. USB. Keyboard port type. USB. Number of computers controlled. 2. Performance. Scan interval. 3,5,10,20 s. Video bandwidth. 60 Hz. Maximum resolution. 1920 x 1200 pixels. HD type. WUXGA. Design. LED indicators. Yes. Product colour. Black. Rack mounting. No. Display. Built-in display. No. Power. Power consumption (typical). 1.9 W. Input voltage. 5 V. Power source. DC. Operational conditions. Storage relative humidity (H-H). 0 - 80%. Operating relative humidity (H-H). 0 - 80%. Storage temperature (T-T). -20 - 60 °C. Operating temperature (T-T). 0 - 50 °C. Weight & dimensions. Weight. 460 g. Height. 24 mm. Depth. 78 mm. Width. 111.5 mm. Packaging data. Package weight. 590 g. Package height. 235 mm. Package depth. 163 mm. Package width. 70 mm. Packaging content. Quick installation guide. Yes. Manual. Yes. Logistics data. Products per master (outer) case. 10 pc(s). Master (outer) case gross weight. 6.61 kg. Master (outer) case height. 182 mm. Master (outer) case length. 405 mm. Master (outer) case width. 395 mm. Master (outer) case net weight. 4.6 kg. Harmonized System (HS) code. 85176200. leaflet. manual pdf. Quick Start Guides
