The MC112CS is a media converter designed to convert 100BASE-FX fiber to 100Base-TX copper media or vice versa. Adopting WDM... moretechnology, MC112CS takes only one fiber cable to transmit and receive data, which will save half cabling cost for you. Designed under IEEE 802.3u 10/100Base-TX and 100Base-FX standards, the MC112CS is designed for use with single-mode fiber cable utilizing the SC-Type connector. The MC112CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1310nm on transferring data and at 1550nm on receiving data. So the other end device to cooperate with the MC112CS should work at 1550nm on transferring data and at 1310nm on receiving data. Another TP-LINK's media converter MC111CS is just one of the examples to cooperate with MC112CS.Other features of this module include the ability to be used as a stand alone device (no chassis required), Auto MDI/MDI-X for TX port, Auto negotiation of duplex mode on TX port, and front panel status LEDs. The MC112CS will transmit at extended fiber optic distances utilizing single-mode fiber up to 20 kilometers.Specifications:Network:- Maximum data transfer rate: 1000 Mbit/s- Networking standards: IEEE 802.3,IEEE 802.3u,IEEE 802.3x- Ethernet interface type: Gigabit Ethernet- Ethernet LAN data rates: 1000 Mbit/s- Auto MDI/MDI-X: YesPorts & interfaces:- Connectivity technology: Wired- Ethernet LAN (RJ-45) ports: 1- Fiber ports quantity: 1- Fiber optic connector: SCPerformance:- Maximum transfer distance: 20000 m- Wavelength: 1550 nmDesign:- Internal: No- LED indicators: Power, Speed- Certification: FCC, CEPower:- Power consumption (max): 2.41 WWeight & dimensions:- Width: 94.5 mm- Depth: 73 mm- Height: 27 mmOperational conditions:- Operating temperature (T-T): 0 - 40 °C- Storage temperature (T-T): -40 - 70 °C- Operating relative humidity (H-H): 10 - 90%- Storage relative humidity (H-H): 5 - 90%Packaging data:- Package width: 204 mm- Package depth: 165 mm- Package height: 65 mm- Package weight: 360 gTechnical details:- Sustainability certificates: RoHS
TP-Link MC112CS network media converter 100 Mbit/s Single-mode Black
10/100Mbps Wdm Media Converter Mc112cs Complies With 802.3U 10/100Base-Tx 100Base-Fx Standards. Link Fault Passt... morehrough And Far End Fault Minimize The Loss Caused By Link Failure Timely Adopts Wdm Technology Transmitting And Receiving Data On One Single Fiber What This Product Does The Mc112cs Is A Media Converter Designed To Convert 100Base-Fx Fiber To 100Base-Tx Copper Media Or Vice Versa. Adopting Wdm Technology Mc112cs Takes Only One Fiber Cable To Transmit And Receive Data Which Will Save Half Cabling Cost For You. Designed Under Ieee 802.3U 10/100Base-Tx And 100Base-Fx Standards The Mc112cs Is Designed For Use With Single-Mode Fiber Cable Utilizing The Sc-Type Connector. The Mc112cs Supports Longwave (Lx) Laser Specification At A Full Wire Speed Forwarding Rate. It Works At 1310Nm On Transferring Data And At 1550Nm On Receiving Data. So The Other End Device To Cooperate With The Mc112cs Should Work At 1550Nm On Transferring Data And At 1310Nm On Receiving Data. Another Tp-Link’S Media Converter Mc111cs Is Just One Of The Examples To Cooperate With Mc112cs. Other Features Of This Module Include The Ability To Be Used As A Stand Alone Device (No Chassis Required) Auto Mdi/Mdi-X For Tx Port Auto Negotiation Of Duplex Mode On Tx Port And Front Panel Status Leds. The Mc112cs Will Transmit At Extended Fiber Optic Distances Utilizing Single-Mode Fiber Up To 20 Kilometers.
The MC112CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1310nm on transferring data and at 1550nm on receiving data. So the other end device to cooperate with the MC112CS should work at 1550nm on transferring data and at 1310nm on receiving data. Another TP-LINKs media converter MC111CS is just one of the examples to cooperate with MC112CS. Other features of this module include the ability to be used as a standalone device (no chassis required) Auto MDI/MDI-X for TX port Auto negotiation of duplex mode on TX port and front panel status LEDs. The MC112CS will transmit at extended fibre optic distances utilizing single-mode fibre up to 20 kilometres.
10/100Mbps Wdm Media Converter Mc112cs Complies With 802.3U 10/100Base-Tx 100Base-Fx Standards. Link Fault Passthrough And Far End Fault Minimize The Loss Caused By Link Failure Timely Adopts Wdm Technology Transmitting And Receiving Data On One Single Fiber What This Product Does The Mc112cs Is A Media Converter Designed To Convert 100Base-Fx Fiber To 100Base-Tx Copper Media Or Vice Versa. Adopting Wdm Technology Mc112cs Takes Only One Fiber Cable To Transmit And Receive Data Which Will Save Half Cabling Cost For You. Designed Under Ieee 802.3U 10/100Base-Tx And 100Base-Fx Standards The Mc112cs Is Designed For Use With Single-Mode Fiber Cable Utilizing The Sc-Type Connector. The Mc112cs Supports Longwave (Lx) Laser Specification At A Full Wire Speed Forwarding Rate. It Works At 1310Nm On Transferring Data And At 1550Nm On Receiving Data. So The Other End Device To Cooperate With The Mc112cs Should Work At 1550Nm On Transferring Data And At 1310Nm On Receiving Data. Another Tp-Link’S Media Converter Mc111cs Is Just One Of The Examples To Cooperate With Mc112cs. Other Features Of This Module Include The Ability To Be Used As A Stand Alone Device (No Chassis Required) Auto Mdi/Mdi-X For Tx Port Auto Negotiation Of Duplex Mode On Tx Port And Front Panel Status Leds. The Mc112cs Will Transmit At Extended Fiber Optic Distances Utilizing Single-Mode Fiber Up To 20 Kilometers.
The MC112CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1310nm on transferring data and at 1550nm on receiving data. So the other end device to cooperate with the MC112CS should work at 1550nm on transferring data and at 1310nm on receiving data. Another TP-LINKs media converter MC111CS is just one of the examples to cooperate with MC112CS. Other features of this module include the ability to be used as a standalone device (no chassis required) Auto MDI/MDI-X for TX port Auto negotiation of duplex mode on TX port and front panel status LEDs. The MC112CS will transmit at extended fibre optic distances utilizing single-mode fibre up to 20 kilometres.
