SurgeX SX-AEP-1011I

Surgex SX-AEP-1011I Axess ELITE+ IP Controlled Power ManagementThe SX-AEP-1011i shall be a one-rack-space unit in a magnetic shielding steel enclosure. It shall operate from 240 volts AC and have a 10-foot grounded 3-wire #14 detachable line cord. There shall be 10 grounded AC receptacles on the back panel and 1 grounded AC receptacles on the front panel with all total 11 switched. Overall dimensions shall be 1.75” H x 19” W x 12.25” D. Weight shall be 12 pounds. The unit shall have remote turn-on capabilities enabled by wired Ethernet serial and terminal block connections. Remote turn-on and turn-off shall be activated by contact closure or software. It shall have remote control sequencing scheduling measurement AutoPing and adjustable trigger functions and shall support wired RS-232 Ethernet HTTP HTTPS SNMPv1 SNMPv3 NTP mDNS 802.1x LDAP and SSH protocols. The unit shall measure voltage current (per outlet) power (per outlet) energy (per outlet) and temperature and shall record events in its internal memory. There shall be two relay outputs for control and cascading. The SX-AEP-1011i shall have a load rating of 10 amps at 240 volts a self-test circuit with visual indicator and provide EMI/ RFI filtering inrush current elimination and catastrophic over/under-voltage shutdown. It shall withstand at least 1000 occurrences of surge pulse voltages up to 6000 volts.FeaturesIP ControlYes Dimensions (D x W x H)300 x 442 x 44 mmWeight5.4 Kg
