AT-OME-RX11

• HDBaseTTM receiver for HDMI? Ethernet power and control
• 4K/UHD capability @ 60 Hz with 4:2:0 chroma subsampling
• HDCP 2.2 compliant
• Local AC powering – PoE (Power over Ethernet) source
• Audio de-embedding

The Atlona AT-OME-RX11 is an HDBaseT receiver for video up to 4K/60 4:2:0 plus embedded audio control and Ethernet over distances up to 330 feet (100 meters). Part of the Omega™ Series of integration products for modern AV communications and collaboration the OME-RX11 is HDCP 2.2 compliant and receives RS-232 and IP control signals. Additionally this receiver features two-channel audio de-embedding to a balanced analog audio output. The OME-RX11 is locally powered and can deliver Power over Ethernet (PoE) over HDBaseT to an Atlona Omega Series HDVS-200 Series or AT-UHD-EX-100CE-TX-PD transmitter.

The OME-RX11 incorporates many popular integration convenience features while delivering excellent performance and value for 4K presentation applications. The Ethernet port on the OME-RX11 is for IP pass-through with the transmitter.

Applications

• Complete system integration – The OME-RX11 and an Omega Series switcher together provide a comprehensive and cost-effective integration solution for meeting rooms and other AV presentation spaces.
• Video conferencing and interactive displays – The OME-RX11 offers a new option for legacy Atlona transmitters and switchers with HDBaseT outputs to provide audio de-embedding for feeding into an amplifier and speakers.

Technical Features

Video audio power and data over category cable utilizing HDBaseT technology

• Receives up to 330 feet (100 meters) @ 1080p with CAT5e/6 or 4K/UHD using CAT6a/7 cable
• Uses easy-to-integrate category cable for low-cost reliable system installation

4K/UHD capability @ 60 Hz with 4:2:0 chroma subsampling

• Compatible with sources up to 4K/60 4:2:0 and 4K/30 4:4:4
• Supports HDMI data rates up to 10 Gbps from PCs media players and Ultra HD Blu-ray players

HDCP 2.2 compliant

• Adheres to latest specification for High-bandwidth Digital Content Protection*
• Allows protected content stream to pass between authenticated devices
• * HDBaseT transmitter or switcher must also be HDCP 2.2 compliant.

Local AC powering – PoE (Power over Ethernet) source

• Supplies industry standard IEEE 802.3af PoE over HDBaseT to an Omega Series HDVS-200 Series or AT-UHD-EX-100CE-TX-PD transmitter
• Allows convenient transmitter installation at any remote location without the need for local AC power

Audio de-embedding

• De-embeds two channel PCM audio to a balanced analog audio output
• Deliver audio to an amplifier and speakers for sound reinforcement

Multi-channel audio compliant

• Passes through multi-channel audio formats
• Supports PCM Dolby? Digital Dolby Digital Plus™ Dolby TrueHD
