Ethernet Cables Ewent

Use the IM1206 Modular RJ-45 Plug for assembling your own UTP CAT6 Patch Cable. The connector is suited for round rigid cables AWG 23-26. With the IM1206 simplify and speed up terminations by placing and cutting all wires in one motion.Specifications:- For solid cable Cat.6 U/UTP (AWG23-26)- 15 µ gold-plated contacts- Performance: CAT 6, 1GBase-T- Norms: ISO/IEC 11801 3rd Ed., EN 50173-1, EIA/TIA 568-C- Material connector body: Polycarbonat, clear- Connector contact: Phosphor bronze, brass 0.15 μ gold-plated- Min. wire gauge: 26 AWG- Max. wire gauge: 23 AWG- Flammability: UL 94V-2- Rated current: 2 A- Rated voltage: 250 V

Specifications:- Type: Crimping tool- Network connector type: RJ-11, RJ-12, RJ-45- Material: Rubber, Stainless steel

Ewent Cat.6A U/UTP installation cable follows the construction of 4x2x AWG23/1 cable and reaches a transmission frequency of up to 500 MHz.The halogen-free cable jacket complies with IEC 60332-1, FRNC- B, LSZH-1 and CPR Euro class Eca.The cable is suitable for the construction of structured cabling in the secondary and tertiary area.Complies with the following standards ISO/IEC 11801, DIN EN 50173, DIN EN 50288-11-1.Specifications:-Quantity per package:1 piece(s).-Connector Gender 1:No.-Cable fire protection class:Eca.-Data transfer speed:10000 Mbit/s.-Product color:Blue.-Connector Gender 2:No.-Cable shape:Around.-Conductor type:Solid.-Jacket material:Halogen free (LSZH).-Conductor material:Copper.…

Features:- Shielding class: U-UTP- Type of cable: round cable AWG 23/1, solid- Inner conductor material: CCA copper-clad aluminium- CPR compliant Eca classSpecifications:- Cable length: 305 m- Cable standard: Cat6- Cable shielding: U/UTP (UTP)- Connector 1: No- Connector 2: No- Connector 1 gender: No- Connector 2 gender: No- Jacket materialPolyvinyl chloride (PVC)- Conductor typeSolid- Conductor materialCopper-Clad Aluminium (CCA)- AWG wire size23/1- Frequency250 MHz- CertificationCPR Eca class

Ewent IM1217.Cable length:305 m, Standard cable:Cat6, Cable shield:U/UTP (UTP), Data transfer speed:1000 Mbit/s.Specifications:-Quantity per package:1 piece(s).-Connector Gender 1:No.-Data transfer speed:1000 Mbit/s.-Product color:Gray.-Connector Gender 2:No.-Cable shape:Around.-Conductor type:Solid.-Jacket material:Halogen free (LSZH).-Conductor material:Copper clad aluminum (CCA).-AWG wire gauge:23/1.-Frequency:250 MHz.-Connector 2:No.-Cable length:305 m.-Standard cable:Cat6.-Cable shielding:U/UTP (UTP).-Connector 1:No.
