Other Components EKWB

The easiest way to stop the continuous buildup of dust, is by keeping the dust out in the first place and the easiest way of doing this is by fitting a dustfilter. Specification:-- Size: 120x240x1.5mm

The EK-HD PETG Inserts are EK's way of battling against potential hazards that the use of PETG tubes present. PETG tubes are extremely popular because of the ease of use and their flexibility. On the other hand, PETG tubing, especially the thin tube wall models (10/12) are prone to deformation when exposed to high temperatures (40°C and above). The deformation rate depends on the duration and maximum temperature reached. These temperatures can be reached with pump failures, water block clogging, etc. The EK-HD PETG Inserts provide a safety measure for 12mm OD / 10mm ID PETG tubes which prevents the tube wall from collapsing inside the compression fitting. The EK-HD PETG Insert is low …

The EK-HD PETG Inserts are EK's way of battling against potential hazards that the use of PETG tubes present. PETG tubes are extremely popular because of the ease of use and their flexibility. On the other hand, PETG tubing is prone to deformation when exposed to high temperatures (40°C and above). The deformation rate depends on the duration and maximum temperature reached. These temperatures can be reached with pump failures, water block clogging, etc. The EK-HD PETG Inserts provide a safety measure for 16mm OD / 12mm ID PETG tubes which prevents the tube wall from collapsing inside the compression fitting. The EK-HD PETG Insert is low profile and it is not visible when in use with …

EK-HD PETG Tube is solid type PETG tubing intended for use with EK-HD push-in adapters and EK-HDC series compression fittings. The tubing may be heat treated to achieve certain bends. For expert users only! It is mandatory to chamfer the edges of freshly cut tube in order to prevent gasket (O-ring) damage. EK recommends a 0,5mm x 45° chamfer. Specification: - Material: PETG - Inner diameter: 10 mm - Outer diameter: 12 mm - Length: 500 mm (19.5") - Clear The package contains 2 pieces of tube only. Please purchase EK-HD Adapter or EK-HDC compression fittings separately! For easier installation we recommend wetting the gasket (O-ring) using drops of water prior to installing solid tube.

EK-HD Tube D.I.Y. Kit 10&12mm is a Do-It-Yourself modification kit for solid acrylic tubing with Ø10- and Ø12mm in inner diameter (ID).Using heat gun and the enclosed silicone cord (rod) it is possible to make customized pieces of solid tubing. Use hacksaw to cut pieces to length and sandpaper to chamfer and smooth out the edges.Contents:- 1x hacksaw- 1x sandpaper (P220 grit, 230 mm x 280 mm)- 1x silicone cord Ø9.4mm (L=33cm)- 1x silicone cord Ø11.7mm (L=33cm)

EK-AF Extender M-M is a simple male-threaded extender interconnect for connecting two water cooling components with female G1/4 threads together.This is not a revolvable extender.Made from nickel-plated CNC machined brass. Sealed with quality orings.These Extenders can be either tightened by hand or by using Allen Key 9mm (not included, available for separate purchase).Technical data:- Threading: G 1/4"- Thread length: 4.0mm- Diameter: 18.8mm- Height: 12mm

EK-AF Extender 20mm M-M is a simple male-threaded extender interconnect for connecting two water cooling components with female G1/4 threads together.Made from nickel-plated CNC machined brass. Sealed with quality orings.Technical data:- Threading: 2 x G 1/4" (Male - Male)- Thread length: 4.0mm- Diameter: 18.8mm- Height: 20mm

EK-Cable Pump testing adapter is a simple adapter cable for connecting any liquid cooling pump (with 4-pin fan header) or computer cooling fan with SATA power cable. This adapter is recommended to be used only for testing purposes while leak-testing your loop and is intended to be connected directly to PSU, without the need for powering up the entire system. The cable is approximately 15cm long.Features: - 3-pin fan header to SATA power adapter- RoHS compliant

Specifications:-- Length: 100 mm- Color: black (sleeved)- Connectors: - 1x 4-pin PWM connector - 2x 4-pin PWM connector- Compatibility: - 4-pin PWM fan - 3-pin fan- EK Water Blocks EK-Cable Y Splitter 2-Fan PWM (10cm)

DetailsEK-Cable Y-Splitter 3-Fan PWM is a simple adapter used to hook three DC or PWM fans to one motherboard 4-pin FAN connector. Please note RPM sensing will only work for one fan when using this cable.Caution: Do not use high power fans with this adapter due to the possibility of overloading motherboard fan power regulator. The limit of a fan header on a typical motherboard is usually around ~10W.Features:- Connect three fans from one fan header- Compatible with 4-pin PWM fans and 3-pin DC fan connectors.- Fully sleeved cables (total length ~ 100mm)- RoHS compliant

EK Water Blocks 3831109845974 EK Water Blocks EK-CSQ Extender 8mm G1/4 - Black Nickel

EK-DDC Anti-Vibration Mounting is a simple, yet effective mounting upgrade kit for any EK-DDC type water pump. This vibration dampening rubber mounting system effectively de-couples the water pump from the rest of the computer chassis.Fits any EK-DDC X-RES as well as X-TOP product and can be easily used to fixate the pump assembly to any flat surface using 50x50mm square mounting hole pattern.Contents:- Mounting mechanism with vibration decouplers- Allen key 2mmPLEASE NOTE:- EK does not guarantee compatibility with other brands DDC water pumps or 3rd party pump tops (volutes). Only EK-DDC family products are supported!- Vibration damping mounting cannot be used with original Laing DDC pump top!Made …

EK-DDC Heatsink Housing is an heatsink upgrade kit for any Laing DDC type water pump which vastly improves the cooling performance and prolongs the lifespan of the water pump.EK-DDC Heatsink Housing is made from cast ZAMAK (zinc, aluminum, magnesium, copper) alloy and features glossy black paint finish.This product also features vibration dampening rubber mounting system which effectively de-couples the water pump from the rest of the computer chassis.Contents:- EK-DDC Heatsink Housing- Pre-cut thermal pad- Mounting mechanism with vibration dampers

The EK-D-RGB 6-Way Splitter Cable allows users to connect up to six digitally addressable RGB products to a single D-RGB (addressable) motherboard or controller header so that they can synchronize all their D-RGB products. It features standard 3-pin D-RGB headers and the male-male connector pins are also included in the packaging. The splitter cable can be used with any standard 3-pin 5V D-RGB controller or any of the popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header.Please refer to the motherboard manufacturer manual or RGB controller manufacturer manual …

EK-HD PETG Tube is solid type PETG tubing intended for use with EK-HD push-in adapters and EK-HDC series compression fittings. The tubing may be heat treated to achieve certain bends. For expert users only! It is mandatory to chamfer the edges of freshly cut tube in order to prevent gasket (O-ring) damage. Technical data: - Material: PETG - Inner diameter: 10 mm - Outer diameter: 12 mm - Length: 1000 mm (19.5") The package contains 2 pieces of tube only.

EK-HD PETG Tube is solid type PETG tubing intended for use with EK-HD push-in adapters and EK-HDC series compression fittings. The tubing may be heat treated to achieve certain bends. For expert users only! It is mandatory to chamfer the edges of freshly cut tube in order to prevent gasket (O-ring) damage. EK recommends a 0,5mm x 45° chamfer. Specification: - Material: PETG - Inner diameter: 12 mm - Outer diameter: 16 mm - Length: 1000 mm (19.5") The package contains 2 pieces of tube only. Please purchase EK-HD Adapter or EK-HDC compression fittings separately! For easier installation we recommend wetting the gasket (O-ring) using drops of water prior to installing solid tube.

EK-HD PETG Tube is solid type PETG tubing intended for use with EK-HD push-in adapters and EK-HDC series compression fittings. The tubing may be heat treated to achieve certain bends. For expert users only! It is mandatory to chamfer the edges of freshly cut tube in order to prevent gasket (O-ring) damage. EK recommends a 0,5mm x 45° chamfer. Specification: - Material: PETG - Inner diameter: 12 mm - Outer diameter: 16 mm - Length: 500 mm (19.5") The package contains 2 pieces of tube only. Please purchase EK-HD Adapter or EK-HDC compression fittings separately! For easier installation we recommend wetting the gasket (O-ring) using drops of water prior to installing solid tube.

The EK-HD Tube Reamer is an external and internal tube reamer. The tool is used to remove the remains of freshly cut Acrylic, PETG, copper, aluminum, brass, carbon fiber, etc. tubing. Suitable for tubes with a minimum inner diameter of 5mm and maximum outer diameter of 30mm.Technical specification:- Plastic body- Steel blades- Minimum tubing ID: 5mm- Maximum tubing OD: 30mm

EK-Loop Angled Bracket is a steel mounting bracket that enables the user to mount the FLT style combo units or reservoirs perpendicular to any 120mm (105mm hole spacing) fan mounting holes. This will allow more airflow to freely pass through the case, or just to offer new mounting options which are not supported by the case itself. Additionally, you can use the long or the short side of your FLT product for additional mounting options.This bracket also allows offsetting the product by about 50mm in each direction with the rail system it uses, because the screws are not in a fixed location. This bracket is not limited to FLT series products, even though it was engineered for it. With a bit of …

EK-Loop Bending Cord for 10mm ID Hard Tube - 0.33m is a silicone cord for bending acrylic and PETG tubing. It features high heat and abrasion resistance, helping the tube not to deform while subjected to the high temperatures of a heat gun during the bending process. Using a heat gun and the enclosed silicone bending cord (insert), it is possible to make customized pieces of solid tubing. Use the hacksaw to cut pieces to length and sandpaper to chamfer and smooth out the edges. For a perfect chamfer, EK recommends the use of the EK-HD Tube Reamer tool. EK-Loop Bending Cord is 0.33m long. It is made of flexible silicone with high elasticity, allowing it to be inserted and pulled out of a bent …

EK-Loop Connect Level Sensor TBE 60 is a coolant level sensor provides a warning when the reservoir reaches a point where it would be prudent to top it off. Due to the coolant evaporation through the tubing, it makes sure the pump never runs dry. Also, in case of a leak, it warns you of the coolant level being below its optimal value.It attaches to the tube of the EK tubular-style reservoirs with 60mm diameter and connects via a dedicated cable to the EK-Loop Connect control unit.Technical Specifications:- Connectors: 4-pin- Length: 50cm

EK-Loop D5 MX PWM Motor is a low-power version of the full D5 water pump with PWM speed control via the motherboard or a dedicated fan/pump controller. Compared to the full-power D5 G3, it has a 20% lower flow rate and a weaker head pressure. It uses less power, with only a 15W power draw. Also, power is drawn via Molex connector compared to the SATA on the G3. EK-Loop D5 MX PWM is an original Xylem D5 PWM pump, with a reduced power draw. PWM control allows for automatic pump speed regulation depending on your CPU temperature. Full performance on demand or whisper-quiet operation in idle mode! This pump is ideal for PC and other electronics water cooling. The D5 pump is equipped with an electronically …

EK-Loop D5 Pump Mounting Kit is a mounting kit for D5 pumps that enables users to convert their DDC-powered FLT series combo unit or EK-Mana G2 PC-O11D EVO distribution plate to a D5 variant. It contains a bracket that holds the pump, an o-ring for the pump, and four screws to fasten the bracket to the reservoir. This kit does NOT contain a D5 pump. EK suggests the EK-Loop D5 G3 PWM Motor, which is the most modern version of the D5 pump with a SATA power connector. Compatibility: - 3831109905630 EK-Mana G2 PC-O11D EVO DDC D-RGB Distribution Plate - 3831109851159 EK-Quantum Kinetic FLT 80 DDC PWM D-RGB - Plexi - 3831109819753 EK-Quantum Kinetic FLT 120 DDC PWM D-RGB - Plexi - 3831109819760 …

EK-Loop DDC 4.1 PWM Motor is a custom loop water pump with power management control (via PWM - pulse width modulation) of rotation speed through motherboard BIOS or a dedicated fan controller. This is a low-power version of the full DDC pump carrying both power and PWM control through the fan 4-pin header. It features the exact same physical characteristics on the outside as the EK-Loop DDC 4.2 PWM Motor, which is the high-power version. This pump is compatible with any EK-Quantum Kinetic TBE DDC and FLT DDC pump-res combo units. Using an optional Convection heatsink can even further prolong the lifespan of the pump. Despite a remarkably small footprint of 2.4" square, EK-Loop DDC 4.1 PWM …
