Fans VENTS

Dimensions and technical data220-240 V ~ 50/60 HzHousing colour: blackHousing material: powder-coated steelSound and heat insulation due to 50 mm thick mineral wool layerNominal diameter: 100 mmPower: 24 / 26 WStrom absorption: 0.1 / 0.11 revolutions per minute: 2030 / 2630Air output: 170 / 240 m³/hSound pressure Lp-3m: 24 / 29 dB(A)Height: 237 mmWidth: 215 mmWidth mounting nozzle: 243 mmLength: 505 mmDiameter pipe connection: 98 mmmax. Temperature for continuous operation: 60°CType of protection: IPX4Weight: 4.6 kgbuilt-in tap changer: 2 speeds / ball bearing motorMounting: Installation in any positionMotor unit for cleaning and maintenance quick and easy removableUse: Ventilation systems re…

Dimensions and technical data220-240 V ~ 50 HzHousing color: whiteHousing material: UV-resistant plasticNominal diameter: 80 mmSpeed levels: 2Power: 15 / 25 WScurrent consumption: 0.12 / 0.14 ALuftflow rate: 35 / 63 m³/hSound pressure Lp-3m: 27 / 36 dB(A)Protection class: IP55Height: 244 mmWidth: 244 mmDepth: 137 mmDiameter pipe socket: 80 mmLength pipe socket: 203 mmWeight: 2.7 kgAdjustable timer: switch-on delay 0 - 150 sec., switch-off delay 2 - 30 min.integrated non-return valve prevents the influence of cold airMounting position: Surface-mountedMounting options: Wall-mounted interval ventilation or permanent ventilation of sanitary areas, shower rooms, kitchens and other living rooms

Dimensions and technical dataInstallation in window frames of different sizesfor continuous supply of fresh air in residential and commercial buildingsIndividual control of the supply air by adjustable NC positionConstruction:Outer piece: inconspicuous design with integrated grille to prevent water penetration or coarse insectsFilter: filtering dust and impurities in the supply air, retaining excess moistureInner grid: adjustable NC position for change the supply air volume and the flow direction

Dimensions and technical details 230 V ~ 50 Hz Housing colour: white Housing material: UV-resistant ABS Nominal size: 100 mm Wattage: 7 W Current consumption: 0.035 A Speed levels: 1 Max. airflow rate: 78 m³/h Sound pressure level Lp-3m: 26 dB(A) IP rating: IP34 Height: 120 mm Width: 150 mm Depth: 12 mm Total depth: 108 mm Weight: 0.5 kg Adjustable shut-off timer (2 - 30 min), humidity sensor (60 - 90%): fan turns off after expiration of the pre-set time once the humidity level falls below the pre-set value Thermal overload protection KO backdraught valve sold separately Mounting options: wall, ceiling Application: continuous or interval air extraction in bathrooms, WCs, laundry rooms etc. i…

Dimensions and technical details 230 V ~ 50 Hz Housing colour: white Housing material: UV-resistant ABS Nominal size: 100 mm Wattage: 7 W Current consumption: 0.035 A Speed levels: 1 Max. airflow rate: 78 m³/h Sound pressure level Lp-3m: 26 dB(A) IP rating: IP34 Height: 120 mm Width: 150 mm Depth: 12 mm Total depth: 108 mm Weight: 0.5 kg Thermal overload protection KO backdraught valve sold separately Mounting options: wall, ceiling Application: continuous or interval air extraction in bathrooms, WCs, laundry rooms etc. in residential and commercial buildings

Dimensions and technical details 220-240 V ~ 50/ Hz Housing colour: white Housing material: UV-resistant ABS Nominal size: 100 mm Wattage: 7 W Current consumption: 0.035 A Speed levels: 1 Max. airflow rate: 78 m³/h Sound pressure level Lp-3m: 26 dB(A) IP rating: IP34 Height: 135 mm Width: 159 mm Depth: 23 mm Total depth: 89 mm Weight: 0.5 kg Adjustable shut-off timer (2 - 30 min), humidity sensor (60 - 90%): fan turns off after expiration of the pre-set time once the humidity level falls below the pre-set value Thermal overload protection KO backdraught valve sold separately Mounting options: wall, ceiling Application: continuous or interval air extraction in bathrooms, WCs, laundry rooms etc. …
