TV Antennas

The Tango 52 is strong short antenna ideally suited to panel mounting or remotely from the device on a bracket to maximise signal strength. For its comparatively small size the antenna has a good peak gain of 2dBi and omni directional radiation. Robust panel mount design Mounting method: M12 14mm Stud Connector: SMA, RG174 Maximum recommended material thickness: 7mm

The Tango47 is an LTE and GPS combined antenna in a standard 75mm diameter panel mounting package. The GSM antenna covers all 4G/LTE GSM frequencies and in doing this covers 3G and 2G frequencies as well. The Tango47 is intended to be an external antenna Weatherproof with rubber edge seal Centre frequencies: 850/900/1800/1900/2100/2700MHz 2G, 3G and 4G frequencies for GSM 1575.42 MHz for GPS 28dBi typical GPS LNA gain 2dBi typical GSM antenna gain Cable: RG174 Lead length:2.5m Housing: black ABS plastic Bandwidth: +/- 5MHz

Through hole panel mount IP67 rated combined LTE and Wi-Fi antenna 0.5m RG174 cable with SMA male for LTE/SMA male RP for Wi-Fi Two separate antennas in one package

The Tango 42 is a very compact puck shaped antenna tuned to the 433MHz - ISM band. With a diameter of 46mm and height of 15mm it will fit comfortably on to most surfaces. This puck antenna is well suited to mounting securely for outside use in all weather Suitable for a wide range of IoT devices like vending machines, routers or IoT modems with sensors attached Secure bolt through mounting Cable Type: RG174 Connector Type: SMA Male Dimensions 46x15mm Cable length: 2.5m

The Tango 420 is a 2 port MIMO antenna intended for LTE routers with -Diversity- capability. The Tango 420 comes in a low profile panel mounting package with M12 brass stud for mounting. This provides the user with a neat and tidy solution where the inco Ideal for systems requiring multiple inputs/outputs 2 port MIMO 3G/4G antenna For use in IoT systems with sensors and controls that require remote monitoring and reporting Frequency range: Port 1 & 2 - 690 - 960 / 1710 - 2170 / 2500 - 2700MHz Operating Temperature: -40 to 75°C Storage Temperature: -45 to 75°C Cable: 2x RG174 Connector: 2x SMA Male Mounting: Ø 12mm screw Maximum Material Thickness: 10mm

Through hole panel mount IP65 rated 2G/3G/4G Wi-Fi antenna 1m RG58 coaxial cable with SMA male connector Omni-directional radiation Outdoor rugged antenna

The Tango 36 antenna is a 3 antenna MIMO WiFi antenna for both 2.4 and 5GHz bands. The three antennas operate in the three planes thereby maximising multipath signal reception and minimising signal fade due to multipath interference. The Tango 36 is house MiMo - 3 antennas covering all 3 planes IEEE 802.11ac ready Cable: 3x Low Loss PRO100 Connector: 3x SMA Male Reverse Polarity Material: ABS Dimensions (LxH): 90x40.5mm

The Tango 34 is a rugged all weather antenna covering quad band 2G/ GPRS mobile frequencies. Boasting a peak gain of 3dBi the Tango 34 is a high performance antenna suited for applications such as touch screen kiosks, next generation telephone boxes, pred Quad Band 2G/GPRS Through Hole High performance Frequency: 850 - 1900 & 900 - 1800MHz Connector: SMA Male Mounting Method: Screw (Thread diameter 14mm, thread length 9mm) Dimensions (HxØ): 59x29.5mm

Through hole panel mount IP67 rated 2.4GHz Wi-Fi/WLAN puck antenna 1m RG174 coaxial cable with SMA-RP male connector Omni-directional radiation Screw threaded base for secure mounting Compact puck design of Ø40mm x 15mm

Through hole panel mount IP66 rated GPS antenna 3m RG174 coaxial cable with SMA male connector Vandal resistant design Compact size

Through hole panel mount IP67 rated GPS and GLONASS puck antenna 3m RG174 coaxial cable with SMA male connector Vandal resistant design

Through hole panel mount IP67 rated GPS puck antenna 3m RG174 coaxial cable with SMA male connector Vandal resistant design Compact size

Through hole panel mount IP67 rated quad band GSM/GPRS and 3G puck antenna 1.5m RG174 coaxial cable with SMA male connector Low profile antenna can be mounted inside or outside giving widest flexibility Designed for use internally or externally Mounts on glass/metallic/plastic surfaces Meets all EU compliance criteria for electronic goods

RF ANTENNA, 50 OHM, LINEAR, SMD

The WSMA-881 Super Gainer is the one to choose for really long distance reception. High quality engineering and ergonomic design ensure that it is the natural replacement for those seeking to extend their receiver's range. SMA connector Receive frequency range: 25-1,900MHz Length: 400mm

The WSMA-801 antenna has been designed to provide a an improvement over the standard flexible whip normally provided with scanning handhelds. High quality engineering and ergonomic design make it a natural replacement. SMA connector Receive frequency range: 25-1,900MHz Length: 210mm

The W-881 Super Gainer antenna is ideal for really long distance reception. High quality engineering and an ergonomic design ensure that it is the natural scanner replacement antenna for those looking to extend their receiver-s range. Rx: 25-1900MHz Length: 410mm Connector: BNC

RF ANTENNA, PATCH, 1.615GHZ, ADHESIVE

PATCH ANTENNA, 1.602GHZ, 1.75DBI

RF ANTENNA, PATCH, 1.602GHZ, SMD

RF ANTENNA, PATCH, 1.602GHZ, SMD

UFL to SMA female connector antenna kit has undergone extensive testing and is fully certified for use with the Raspberry Pi Compute Module 4. Frequency Range: 2400-2500/5100-5800MHz Bandwidth: 100-700MHz Gain: 2dBi Impedance: 50ohm Maximum Power: 10W Vertical polarization Radiation: omnidirectional Antenna dimensions: 108x10mm Note: Compute Module shown for illustration purposes only, not included.

RF ANTENNA, 1.593 TO 1.61GHZ, 3.08DBI

RF ANTENNA, ROAD MARK, 926MHZ, ADHESIVE
