ATEN CS1768 Blue

Features

- One USB console controls eight Single Link DVI or VGA computers and two additional USB 2.0 devices
- Supports both digital (DVI) and analog (VGA) video mixed operation Possible
- Cascadable to three levels control up to 512 computers
- Multiview mode stack up to four CS1768 units and display video from up to four monitors (dual view / triple view / quad view)
- Computer selection via front panel pushbuttons hotkeys and multilingual on-screen display (OSD)
- OSD Backup/Restore function enables the administrator to back up the switchs configuration and user profile information
- 2-port USB 2.0 hub built in
- Fully compliant with the USB 2.0 specification
- Two-level (Administrator/User) password authorization for enhanced security protection
- Multilingual OSD supports English German Japanese Traditional Chinese Simplified Chinese Spanish Russian and French
- Audio enabled full bass response provides a rich experience for 2.1 channel surround sound systems
- Console audio ports on front panel for easy access
- Multiplatform support Windows Linux Mac Sun
- Supports widescreen resolutions
- Superior video quality 1920 x 1200 (Single Link DVI); 2048 x 1536 (VGA); DDC2B
- Independent switching of KVM and USB focus
- DVI digital and analog monitor support fully compliant with the DVI specifications
- HDCP compatible
- Video DynaSync exclusive ATEN technology eliminates boot-up display problems and optimizes resolution when switching between ports
- Console mouse port emulation/bypass feature supports most mouse drivers and multifunction mice Chinese and Spanish
- Complete keyboard emulation for error-free booting
- Mac/Sun keyboard support and emulation*
- Multilingual keyboard mapping supports English (US) English (UK) French German Japanese Korean Traditional
- Auto Scan Mode for monitoring all computers
- Broadcast mode allows you to send commands from the console to all computers to perform operations simultaneously.
- Firmware upgradable

Note: PC keyboard combinations emulate Mac/Sun keyboards; Mac/Sun keyboard work only with their own computers

Package Contents

- 1x CS1768 8-Port USB DVI KVM Switch with Rack Mounting Kit
- 2x 2L-7D02U USB DVI-D KVM Cable Sets
- 1x Firmware Upgrade Cable
- 1x 0AD6-1605-24EG Power Adapter
- 1x Foot Pad Set (4 pcs)
- 1x User Instructions
