Kingston Technology ValueRAM memory module 8 GB 1 x 8 GB DDR4 288-pin DIMM ValueRAM's KVR32N22S8/8 is a 1G x 64-bit (8GB) DDR... more4-3200 CL22 SDRAM (Synchronous DRAM). 1Rx8. memory module. based on eight 1G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers.
Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals. Low-power auto self refresh (LPASR). Data bu... mores inversion (DBI) for data bus. On-die VREFDQ generation and calibration. Single-rank. On-board I2 serial presence-detect (SPD) EEPROM. 16 internal banks; 4 groups of 4 banks each. Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS). Selectable BC4 or BL8 on-the-fly (OTF). Fly-by topology. Terminated control command and address bus. RoHS Compliant and Halogen-Free. ValueRAM's KVR32N22S8/8 is a 1G x 64-bit (8GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM), 1Rx8, memory module, based on eight 1G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers.. Features. JEDEC standard. Yes. Programming power voltage (VPP). 2.5 V. Row active time. 32 ns. Refresh row cycle time. 350 ns. Row cycle time. 45.75 ns. Module configuration. 1024M x 64. Memory voltage. 1.2 V. Memory ranking. 1. CAS latency. 22. ECC. No. Memory form factor. 288-pin DIMM. Component for. PC/Server. Internal memory type. DDR4. Memory layout (modules x size). 1 x 8 GB. Internal memory. 8 GB. Buffered memory type. Unregistered (unbuffered). Operational conditions. Storage temperature (T-T). -55 - 100 °C. Operating temperature (T-T). 0 - 85 °C. General. Product family. ValueRAM. Technical details. Compliance certificates. RoHS. Sustainability. Doesn't contain. Halogen. Weight & dimensions. Height. 31.2 mm. Width. 133.3 mm. Logistics data. Harmonized System (HS) code. 84733020. leaflet
ValueRAM's KVR32N22S8/8 is a 1G x 64-bit (8GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM). 1Rx8. memory module. based on eight 1... moreG x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers. Kingston Technology ValueRAM memory module 8 GB 1 x 8 GB DDR4 288-pin DIMM
8GB 3200MT/s DDR4 Non-ECC CL22 DIMM 1Rx8 - Bulk OEM
ValueRAM's KVR32N22S8/8 is a 1G x 64-bit (8GB) D... moreDR4-3200 CL22 SDRAM (Synchronous DRAM) 1Rx8 memory module based on eight 1G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers.
- Power Supply: VDD = 1.2V Typical
- VDDQ = 1.2V Typical
- VPP = 2.5V Typical
- VDDSPD = 2.2V to 3.6V
- Nominal and dynamic on-die termination (ODT) for data strobe and mask signals
- Low-power auto self refresh (LPASR)
- Data bus inversion (DBI) for data bus
- On-die VREFDQ generation and calibration
- Single-rank
- On-board I2 serial presence-detect (SPD) EEPROM
- 16 internal banks; 4 groups of 4 banks each
- Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS)
- Selectable BC4 or BL8 on-the-fly (OTF)
- Fly-by topology
- Terminated control command and address bus
- PCB: Height 1.23” (31.25mm)
- RoHS Compliant and Halogen-Free
8GB 3200MT/s DDR4 Non-ECC CL22 DIMM 1Rx8 - Bulk OEM
ValueRAM's KVR32N22S8/8 is a 1G x 64-bit (8GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM) 1Rx8 memory module based on eight 1G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers.
- Power Supply: VDD = 1.2V Typical
- VDDQ = 1.2V Typical
- VPP = 2.5V Typical
- VDDSPD = 2.2V to 3.6V
- Nominal and dynamic on-die termination (ODT) for data strobe and mask signals
- Low-power auto self refresh (LPASR)
- Data bus inversion (DBI) for data bus
- On-die VREFDQ generation and calibration
- Single-rank
- On-board I2 serial presence-detect (SPD) EEPROM
- 16 internal banks; 4 groups of 4 banks each
- Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS)
- Selectable BC4 or BL8 on-the-fly (OTF)
- Fly-by topology
- Terminated control command and address bus
- PCB: Height 1.23” (31.25mm)
- RoHS Compliant and Halogen-Free
