FSA's The Pig headset is suitable for BMX and Freeride disciplines. Gyro compatible, it uses Cromoly cups and crowns for huge strength.Fits 34mm ID headtubeSteerer Size: 1 1/8"Upper Stack Height: 16.4mmLower Stack Height: 13.6mmTotal Stack Height: 30mmWeight: 180gSpares: Upper Bearing: 160-6120 / Lower Bearing: 160-6725 / Crown Race: 160-5501

This FSA The Pig 1-1/8” Headset has a lower cup that has been constructed from CNC machined CrMo, one of the toughest materials on the market to ensure your steering is sturdy. The Pig is GYRO compatible so you can use it with your BMX and bar-spin with ease if you’re at a skate park. The headset weighs in at 193g and comes in black, a cool colour that will suit the paint job of any bike. Features of the FSA The Pig 1 1/8in Headset 1-1/8,For BMX / Freeride Caged ball bearings GYRO compatible 12mm "Deep Cup" design Specifications of the FSA The Pig 1 1/8in Headset Material: Forged and CNC machined CrMo lower cup Upper: Ø 5/32”x22 caged ball bearings

The FSA TH-857 1 1/8 Inch headset features 6061 T6 forged and CNC machined cups and alloy top cover and caged ball bearings for a smooth feel.Fits 34mm ID headtube1-1/8" caged ball bearings6061 T6 forged and CNC machined cupsAlloy top coverStack height: 14 + 11.8 = 25.8mmSpares:Top and Bottom bearings: MR013Crown race: H6010

The FSA SX Pro No.55 Semi Integrated Headset is for tapered 44/55mm ID head tubes head tube with forged alloy and CNC machined upper and lower cups.1.1/8" / 1.5", 36°×45° ACBFor tapered 44/55mm ID head tubesFor 1.1/8" to 1.5" tapered forkForged alloy upper cup with CNC machined alloy lower cupUpper: 36°×45° ACB (blue seal)Lower: 1.5" 36°×45° ACB (black seal)Stack height: 18.8+2.4=21.2mmWeight: 110.2gSparesTop Bearing: TH873E (160-0014000000)Bottom Bearing: TH073E (160-6761)Crown Race: H6078 (160-5537)

FSA Star Nut and Top Cap Assembly for use with 1.5" Steerer.

The FSA Pig DH Pro Headset is a threadless headset that has been constructed from a forged alloy upper cup and a CrMo lower cup. The headset also comes with an upper angular contact bearing and a lower sealed bearing. This FSA headset is also GYRO compatible, so you can use it with a BMX and be able to bar-spin with ease. The headset weighs in at 166g and comes in black, a colour that will suit the paint job of any bike. Features of the FSA Pig DH Pro Headset 1-1/8,36°/ 36° ACB-Upper Industrial bearings-Lower GYRO compatible Alloy top cover Specifications of the FSA Pig DH Pro Headset Material: Forged alloy upper cup and CrMo lower cup Upper: Angular Contact Bearings

The FSA Orbit Z Number 9 Semi Integrated Headset is ideal for use with headtubes that have an outer diameter of 50mm. This headset has two deep cups made from forged CrMo, a tough yet lightweight metal that you can rely on to deliver a great performance. The headset is a lightweight 114.1g and comes in black, a colour that will look good on any bike. Features of the Orbit Z Number 9 Semi Integrated Headset 1-1/8,36°/ 36° ACB, Deeper cups For 50mm OD headtube 1-1/8" steerer Alloy top cap Specifications of the Orbit Z Number 9 Semi Integrated Headset Material: Forged CrMo deeper cups Angular Contact Bearings (Black seal) Height: 15.8+2.1=17.9mm Colour: Black Size:

The FSA Orbit Z NO.9 1 1/8 Inch Threadless Headset is for 44mm ID head tubes and features an Alloy top cap, angular contact bearings and forged CrMo deeper cups.1.1/8”, 36°×36° ACB, Deeper cupsFor 44mm ID headtube1.1/8” steererAlloy top capForged CrMo deeper cupsAngular Contact Bearings (Black seal)Stack Height 15.8+2.1=17.9mmSpares:Top & Bottom bearings: TH872 (160-0016000000)Crown Race: H6119 (160-5558)

The FSA Orbit XL21 1/8" Headset is something of a classic in the FSA line-up, the Orbit XL II has forged and machined alloy cups top and bottom, giving low weight and a high degree of accuracy. A split crown race simplifies fitting, and a pair of angular contact cartridge bearing promise long-lasting performance. FSA Orbit XL2 1 1/8" Headset Features 1.1/8” 36° x 36° ACB upper bearing; Oversized, industrial lower bearing Forged chromoly lower cup 6061T6 upper cup Industrial cartridge sealed lower bearings Forged chromoly crown race Gyro compatible Stack height: 15.4 + 16 = 31.4mm

The FSA Orbit UF Headset 1 1/8” is a threadless headset that comes equipped with an upper cup that has caged ball bearings and a lower cups that has angular contact bearings. The headset also has upper and lower water seals to ensure no water can leak in through the headset and damage your bike. This FSA Headset has a really light weight of 101g and is available in black, a colour that will suit any bikes paint job. Features of the Orbit UF Headset 1 1/8in 1-1/8", caged ball bearings-Upper 36°/36° ACB-Lower Split aluminium crown race Alloy top cover Upper and lower water seals Specifications of the Orbit UF Headset 1 1/8in Upper: Ø5/32"x22 caged ball bearings

This FSA Orbit Equipe headset is a threadless style headset for MTB's equipped with 1 1/8" steerers. The Headset comes with a forged alloy upper cup and steel lower cup and angular contact bearings, whilst the patented alignment tip gives increased durability and performance.Fits 34mm ID headtubeSteerer Size: 1 1/8"Upper Stack Height: 15.5mmLower Stack Height: 12.6mmTotal Stack Height: 28.1mmWeight: 138gSpares: Top Bearing And Bottom Bearings: 160-6485

The FSA Orbit Equipe Black 1 1/8" Headset is constructed using hard wearing and durable aluminium for maximum strength. Forged and CNC machined top cups, a 7075T6 aluminium crown race and a patented alignment tip all combine to increase durability and performance. The Orbit Equipe is attractive and functional in design with a great price tag that represents excellent value. FSA Orbit EquipeHeadsetFeatures Forged and CNC machined 6061T6 aluminium top cups Forged 1.2mm thin steel lower cup TH brand 36° micro angular contact bearings Patented alignment tip for increased durability and performance Laser etched top cap 7075T6 aluminium crown race Colour: Black Size: 11/8"

The FSA Orbit CE Headset is an integrated headset, meaning that the bearings rest inside the frame and there’s no need for headset cups. This integrated headset comes with Campagnolo compatible bearings and Campagnolo angular contact bearings and is suitable for steerer tubes with a diameter of 1 1/8”. This FSA headset comes in black to suit the paintjob of any bike and weighs a really light 74g. Features of the FSA Orbit CE Headset 1-1/8", 45° x 45° serviceable ACB (campagnolo) For 46mm OD headtube 1-1/8" steerer Alloy top cover Campagnolo compatible bearings (Yellow Seal) 7075T6 crown race Campagnolo Angular Contact Bearings (Black seal) Specifications of

The FSA Orbit CE Headset is an integrated headset, meaning that the bearings rest inside the frame and there’s no need for headset cups. This integrated headset comes with Campagnolo compatible bearings and Campagnolo angular contact bearings and is suitable for steerer tubes with a diameter of 1 1/8”. This FSA headset comes in black to suit the paintjob of any bike and weighs a really light 74g. Features of the FSA Orbit CE Headset 1-1/8", 45° x 45° serviceable ACB (campagnolo) For 46mm OD headtube 1-1/8" steerer Alloy top cover Campagnolo compatible bearings (Yellow Seal) 7075T6 crown race Campagnolo Angular Contact Bearings (Black seal) Specifications of

FSA Orbit 1.5E ZS Tapered Headset 1.1/8", 36°×45°; ACB For tapered 50mm/62mm OD Head Tube 1.1/8" to 1.5" steerer Alloy top cover Upper: Forged alloy cup with ACB (blue seal) Lower: 1.5" CNC machined alloy cup with ACB (blue seal) Stack height: 16.9 + 2.9 = 19.8mm Weight: 129.6g

The FSA Orbit 1.5E ZS 1 1/8 Inch Threadless Headset is for tapered 44/56mm ID head tube and comes with an alloy top cover, forged alloy and CNC machined alloy cups.1.1/8", 36°×45° ACBFor tapered 44/56mm ID Head Tube1.1/8" steererAlloy top coverUpper: Forged alloy cup with ACB (blue seal)Lower: 1.5" CNC machined alloy cup with ACB (blue seal)Stack height: 16.9 + 2.9 = 19.8mmWeight: 129.6gSpares:Upper Bearing: TH873 (160-1648)Lower Bearing: TH073 (160-6761)Crown Race: 1.1/8” (H6089, 160-5540)

The FSA Orbit 1.5E ZS 1 1/8-1.5 Inch Threadless Headset is for tapered 44/56mm ID head tube and comes with an alloy top cover, forged alloy and CNC machined alloy cups.1.1/8", 36°×45° ACBFor tapered 44/56mm ID Head Tube1.1/8" to 1.5" steererAlloy top coverUpper: Forged alloy cup with ACB (blue seal)Lower: 1.5" CNC machined alloy cup with ACB (blue seal)Stack height: 16.9 + 2.9 = 19.8mmWeight: 129.6gSpares:Upper Bearing: TH873 (160-1648)Lower Bearing: TH073 (160-6761)Crown Race: 1.1/8-1.5” (H6088, 160-5551)

FSA is the world leading headset manufacturer and the core of their product line. With many years of experience they understand that multiple dimensions and exacting requirements are a must when it comes to headsets.The No.11N headset features deep cups made from forged alloy for strength and low weight resulting in an overall weight of only 124.3g. Inside you'll find integrated semi-cartridge bearings to accommodate a 1-1/8in steerer tube.Steerer Size: 1 1/8"Upper Stack Height: 18.7mmLower Stack Height: 3mmTotal Stack Height: 21.7mmWeight: 124.3gSpares: Top And Bottom Bearings: MR083 / Crown Race: 160-55491.1/8” semi-cartridge type headsetFor 49mm OD headtube / 44mm ID Headtube1.1/8”

The FSA NO.10 Threadless Headset is for 44mm ID head tubes and comes with an alloy custom top cover and 5/32"×20 retainer bearings.For 44mm ID head tube1.1/8" steererAlloy custom top cover5/32"×20 retainer bearings

TheFSA Impact BMX Gyro Compatible Headsetis a must have for all bmxers who have a gyro set-up, its sturdy build provides long lasting precise control, enabling you to spin the bars over and over without worrying about any damage being caused! With a 9.4mm stack height the Headset sits relatively low on the front of the frame, providing you with a comfortable ride that provides immense control at all times. As with all FSA headsets the Impact Gyro Headset is capable of taking a heavy beating and will still turn out a smooth run at all times. FSA Impact BMX Gyro Compatible Headset Features 1-1/8", 45 x 45 ACB Gyro Compatible For 44mm OD headtube 1-1/8" Steerer Campy Compatible

The FSA Big Fat Pig Reducer Headset incorporates a reduction design, 1.5" sized headtube to 1 1/8" steerer. This threadless headset with forged chromoly cups benefits from, 21mm headtube insertion, super oversized " lower ball bearings, chromoly crown race and aluminium top cap. FSA Big Fat Pig Headset Features Reduction design, 1.5" sized headtube to 11/8" steerer. Threadless headset with forged chromoly cups 21mm headtube insertion, super oversized Lower ball bearings Chromoly crown race and aluminium top cap. Replacement bearings 160-6730 x 2. Upper Stack height: 17mm Lower stack height:11.7mm Total stack hieght:28.7mm

HEADSET BEARING ACB TH-870S 1.1/8" 41.8MM 45°×45°; Brands FSA Contact Angle 45°×45°; Height 8.0mm ID 30.5mm OD 41.8mm Product Category Headset Spares / Bearings Type ACB Type Cartridge Type MR042S
