D-Link DMS-106XT

Specification Details Interfaces 5 × 10/100/1000/2500 Mbps ports 1 × 10/100/1000/2500/5000/10000 Mbps port Standards IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T IEEE 802.3x Flow Cont... morerol IEEE 802.1p QoS IEEE 802.3az Energy-Efficient Ethernet (EEE) IEEE 802.3bz 2.5G/5G Base-T IEEE 802.3an 10G Base-T Media Interface Exchange Auto or configurable MDI/MDIX LED Indicators Per port: Link/Activity Per device: Power Switching Capacity 45 Gbps switching fabric Transmission Method Store-and-Forward MAC Address Table 4K entries Power Input DC 12V / 1.5A (100–240 V) Maximum Power Consumption 10.6 W Heat Dissipation 36.17 BTU/h MTBF 489,941 hours Operating Temperature 0°C to 40°C Storage Temperature -10°C to 70°C Operating Humidity 10% to 95% RH Storage Humidity 5% to 95% RH Dimensions (L × W × H) 217 × 163 × 33 mm Weight 680 g EMI Certifications CE, FCC, RCM, BSMI, VCCI, RoHS Turbo Mode Optimizes online gaming and 4K video streaming with low latency, multicast functionality, and port-based QoS.

EU Plug.Ultra-Fast 10-Gigabit Connection for Home or Office Applications:- The DMS-106XT multi-gig switch features a 10-Gigabit port for high-bandwidth network uplink or access to a Network-Attached Storage (NAS) device, it´s perfect for the multimedia design workplace or advanced home networking setup.2.5-Gigabit Ports Ready for Wi-Fi 6 Connectivi... morety:- With five 2.5-Gigabit ports to connect all your high-speed devices, such as Wi-Fi 6 routers and access points, the DMS-106XT delivers unrestricted multi-Gigabit network access for your home or small business.Turbocharge Your Network for Optimized Performance:- When you´re ready for a turbo-charged network experience, simply activate Turbo Mode to keep your online gaming and 4K streaming running at maximum network speeds.Perfect for uninterrupted online entertainment every time.Designed for Advanced Home or Small Office Networks:- Fast enough to handle your large multimedia file transfers to and from the storage server with the 10-Gigabit port, and versatile enough to keep your Wi-Fi 6 router and AP communications unrestricted with 5 multi-Gigabit (2.5 Gbps) ports.What´s more.- the sleek aluminum alloy design and multi-colored LED light bar make the DMS-106XT a great addition to any modern home or workplace.Why You Want It:- Turbo Mode:Activate Turbo Mode whenever you´re ready for optimized performance.- Plug and Play:Ready to perform right out of the box with no configuration required.- Multicolored LED:Multi-Colored LED light conveniently indicates Turbo Mode status.- Silent Operation:Fanless design enhances reliability and is suitable for noise-free working environments.- Metal Casing:Rugged aluminum alloy matte gray casing.- Multi-Gigabit:Multi-Gigabit ports for high data rate transmission.- Power Efficiency:Designed for low power consumption.- Quality of Service:Quality of Service for uninterrupted connections.Features:- 5 x 2.5 Gbps Ethernet Ports for unrestricted Wi-Fi 6 router or AP connections.- 1 x 10 Gbps Ethernet port for uplink or NAS server connection.- Smart Turbo Mode delivers Quality of Service (QoS) and port-based priority for uninterrupted online gaming and 4K streaming.- Power efficiency design for low power consumption.- LED conveniently indicates port speed status.- Durable matte gray aluminum alloy casing.- Fanless operation for enhanced reliability and soundless performance.Specifications:- Interfaces:5 x 10/100/1000/2500Mbps ports, 1 x 10/100/1000/2500/5000/10000Mbps port.- Standards:IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T, IEEE 802.3x Flow Control, IEEE 802.1p QoS, IEEE 802.3az Energy-Efficient Ethernet (EEE), IEEE 802.3bz 2.5G/5G Base-T, IEEE 802.3an 10G Base-T.- LED:Per port:Link/Activity, Per device:Power.- Switching Capacity:45 Gbps.- Transmission Method:Store-and-Forward.- MAC Address Table:4K.- Power Input:DC 12V / 1.5A (100-240 V).- Maximum Power Consumption:10.6 W.- Operating Temperature:0.- 40 °C (32.- 104 °F).- Storage
