DeWALT D26203
Diamond Core Bits & Milling Cutters616
 |
TCT for abrasive materials such as chipboard, MDF, plywood, hardwoods and hard plastics. Two flutes give a clean finish to cut edges. Specifications • Shank Diameter: 1/4 • Dia Metric: 4 more→• Dia Imperial: 5/32 • Cut Length Metric: 15.9 • Overall Length Metric: 56
 |
Eccentric single flute cutters. Cutters are chosen for fast free cutting, when cutting speed takes preference over finish. Cutters with prefix S are Solid Carbide. Cutters of 2.0mm diameter and more→below should have a maximum of 1.0mm depth of cut per pass. Small diameter tools must be handled with care to avoid breakage. Single flute cutters should not be used in eccentric chucks. Specifications • Shank Diameter: 1/4 • Dia Metric: 1 • Cut Length Metric: 3 • Overall Length Metric: 49 • Type or Grade: Solid Carbide Insert
 |
Heavy-Duty Countersink Manufactured From Alloy Steel With Five Flutes And A 90° Head. For Countersinking Screw Holes For Flush Fitting Of Screwheads In Soft Metals Hardwood Soft Wood And Plastics. F more→itted With Quick Change 1/4 Hex. Shank. Compatible With Drills With A Standard 10/13Mm Chuck.PTDDRPDIR
 |
HSS Three Flute 90° Countersink. Specifications • Nominal Diameter: 19.0mm • Shank Diameter: 10mm • Overall Length: 63mm • Capacity: 3.5mm - 19.0mm Features and Benefits &bull more→; Produces countersinks for cap screws • Self centering and chatter free • Can be used for chamferring • DIN 335C
 |
The Trend Two Flute Straight Cutters produce a cleaner finish than the single flute cutters. Suitable for grooving rebating morticing drilling and shallow lateral routing cuts such as recessing hin more→ges. Corners will require a final trimming square with a hand chisel or a corner chisel. Suitable for abrasive materials such as chipboard MDF plywood hardwoods and hard plastics.This Trend 3/20 x 1/4 TCT Two Flute Cutter has the following specification: D: 6.3mm (1/4in)C: 16mmOL: 47mmShank Diameter: 1/4inPTDTRE3201
 |
Single fluted Tungsten Carbide straight cutter for fast free cutting. Single flutes should be chosen where speed and clearance rates are more important than the finish. Depth of cut should not exc more→eed cutter diameter. Specifications • Shank Diameter: 1/4 • Dia Metric: 4 • Dia Imperial: 5/32 • Cut Length Metric: 11.1 • Cut Length Imperial: 7/16 • Overall Length Metric: 60.5
 |
Straight two flute for drilling and slotting, cutting aluminium anodised duralium and uPVC plastic. Cutters are designed to plunge and machine or mill lateral slots. All aluminium tooling should b more→e used with a coolant, wax stick or lubricant. Ideal for recessing and slotting extrusions. HSSE is a special grade for machining the most abrasive anodised finishes. For grooving and profiling of aluminium and plastics. Specifications • Shank Diameter: 1/4 • Dia Metric: 6.3 • Dia Imperial: 1/4 • Cut Length Metric: 12.7 • Cut Length Imperial: 1/2 • Overall Length Metric: 65
 |
The quick-release drill system for drilling countersinking and screwing designed for use with Power Drills and Screwdrivers and is compatible with direct-drive 1/4in Hex Shank Power Bits.Drill Size. more→2.8 mm (7/64in)Counter
Important!
Compatibility with specific models Routers & Trimmers should be confirmed with the online store manager directly before purchase.
Compatibility with specific models Routers & Trimmers should be confirmed with the online store manager directly before purchase.
