SFP Transceivers Allied Telesis

Allied Telesis AT-SPSX SFP 1000SX Multimode TransceiverUpgrade and extend your network with the high-performance and reliable Allied Telesis AT-SPSX, a 1000SX SFP transceiver designed for demanding enterprise and data center environments. This compact, hot-pluggable module provides a seamless and cost-effective solution for establishing high-speed Gigabit Ethernet connections over multimode fiber optic cabling. Ideal for connecting switches, routers, and servers across different floors, buildings, or campus networks, the AT-SPSX breaks the distance barriers of traditional copper wiring, enabling robust connectivity up to 550 meters.Built on the legacy of Allied Telesis´s commitment to quality a…

The AT-SPEX offers a 2 km over multi-mode fiber (1310 nm) option to extend your network.The AT-SPEX is compatible with all the Allied Telesis range of products which have an SFP port. Allied Telesis AT-SPEX.Maximum data transfer rate:1250 Mbit/s, Maximum transfer distance:2000 m, Wavelength:1310 nm.

The Allied Telesis SP Series delivers flexible, full-duplex Ethernet connectivity. These hot-swappable fiber and copper interfaces simply plug into the SFP slot on all SFP-compatible devices. Configuration can be optimized to meet a wide variety of distance and service requirements.Specifications: Performance: - Sfp transceiver type: Fiber optic- Maximum data transfer rate: 1000 Mbit/s- Interface type: Sfp- Single-mode fiber (Smf) supported: Yes- Fiber optic connector: LC- Maximum transfer distance: 10000 m- Wavelength: 1310 nm- Tx power (min): -9 dBmw- Tx power (max): -3 dBmwFeatures: - Housing material: Metal- Plug and Play: Yes- Hot-swap: YesOperational conditions: - Operating temperature …

Gigabit Small Form-Factor Pluggable ModulesN/AThe Allied Telesis SP Series delivers flexible full-duplex Ethernet connectivity.N/AThese hot-swappable fiber and copper interfaces simply plug into the SFPN/Aslot on all SFP-compatible devices. Configuration can be optimized to meet aN/Awide variety of distance and service requirements.

Allied Telesis AT-SPTX-90.SFP transceiver type:Copper, Maximum data transfer rate:1000 Mbit/s, Interface type:SFP.Specifications:- SFP transceiver type:Copper.- Maximum data transfer rate:1000 Mbit/s.- Interface type:SFP.- Maximum transfer distance100 m.- Ethernet interface typeGigabit Ethernet.- Copper ethernet cabling technology1000BASE-T.- Plug and PlayYes.- Minimum operating temperature-40 °C.- Maximum operating temperature85 °C.

SFP+ Direct attach cable, Twinax, 1m (0 to 70°C).Specifications:Features:- Cable length:1 m.- Cable standard:Cat7.- Connector 1:SFP+.- Connector 2:SFP+.- Connector 1 gender:Male.- Connector 2 gender:Male.- Connector contacts plating:Copper.Features:- Data transfer rate:10 Mbit/s Operational conditions:- Operating temperature (T-T):0.- 70 °C.- Storage temperature (T-T):-40.- 85 °C.- Operating relative humidity (H-H):0.- 85% Other.Features:- Input impedance:100 Ω.

Allied Telesis AT-SPSX/I-90 Industrial SFP TransceiverUpgrade your network with the robust and high-performance Allied Telesis AT-SPSX/I-90, a Gigabit SFP transceiver engineered for exceptional reliability in the most demanding environments. This industrial-grade module is the perfect solution for extending your network connectivity over multi-mode fiber, providing a stable and high-speed 1000BASE-SX link for critical applications. Designed specifically to withstand extreme conditions, the AT-SPSX/I-90 is an essential component for industrial automation, intelligent transportation systems, outdoor surveillance, and any network deployment outside of a typical climate-controlled office.The standout …

Specifications:Performance:- SFP transceiver type:Fiber optic.- Maximum data transfer rate:10300 Mbit/s.- Interface type:SFP+.- Multi-mode fiber (MMF) supported:Yes.- Fiber optic connector:LC.- Maximum transfer distance:300 m.- Wavelength:850 nm.- Tx power (min):-5 dBmW.- Tx power (max):-1.8 dBmW.- Rx power (min):-30 dBmW.- Rx power (max):-11.1 dBmW Power:- Power consumption (typical):1 W Operational conditions:- Operating temperature (T-T):0.- 70 °C.- Storage temperature (T-T):-40.- 85 °C.- Operating relative humidity (H-H):0.- 85%.- Storage humidity:0.- 85% Technical details:- Sustainability certificates:RoHS.

The Allied Telesis SP10 Series offers a wide variety of 10 Gigabit Ethernet connectivity options for data center, enterprise and service provider transport applications.These industry-standard hot-swappable devices simply plug into the Ethernet SFP+ port on all SFP+-compatible devices.Configuration can be optimized to meet a wide variety of distance and service requirements.Features:Compatibility:- Allied Telesis SP10 Series 10 Gigabit SFP+ modules are supported on all Allied Telesis devices with SFP+ uplink connections.Options:- The SP10 Series offers short-haul and long-haul solutions.From the inexpensive Allied Telesis SP10SR to the far-reaching Allied Telesis SP10ZR80/I, the network can …

Allied Telesis SP10BD10/I-12 network transceiver module Fiber optic 10000 Mbit/s SFP+ 1330 nm
