SFP Transceivers

Fujitsu SFP+, MMF. SFP transceiver type: Fiber optic, Maximum data transfer rate: 10000 Mbit/s, Interface type: SFP+. Certification: MSA. Width: 13.4 mm, Depth: 56.5 mm, Height: 8.5 mm...

D-Link 1-port Mini-GBIC SFP to 1000BaseSX Industrial Transceiver

Specifications:Performance:- SFP transceiver type:Fiber optic.- Maximum data transfer rate:1000 Mbit/s.- Interface type:mini-GBIC.- Single-mode fiber (SMF) supported:Yes.- Fiber optic connector:SFP.- SFP transceiver standard:LX.- Maximum transfer distance:10000 m Operational conditions:- Operating temperature (T-T):-40.- 85 °C Packaging data:- Number of products included:1 pc(s).- Package width:74 mm.- Package depth:131 mm.- Package height:49 mm.- Package weight:64 g Logistics data:- Shipping (inner) case length:36 cm Logistics data:- Shipping (inner) case width:26 cm.- Shipping (inner) case height:31 cm.- Shipping (inner) case gross weight:4.2 kg.- Shipping (inner) case net weight:3.2 kg.- Q…

. HPE B-series 16Gb SFP+ Short Wave Transceiver

Designed to support distances up to 550 metres the DEM-431XT is a high performance 850nm Multi-Mode SFP+ transceiver. Supporting Full-duplex 10 Gigabit speeds on Multi-Mode fibre cables. The DEM-431XT is 802.3ae 10GBASE-SR compliant and supports Full-duplex 802.3x Flow control. The DEM-431XT provides the necessary signal amplification for data to be transmitted to the network cable from the port and vice versa.

D-Links 10G SFP+ Module series are hot-swappable SFP+ transceivers that plug into SFP+ slots on switches and support 10G Ethernet. The D-Link 10GBASE SFP+ Module Series transceivers offer customers a wide variety of 10G Ethernet connectivity options for data centers enterprise wiring …

The 10GBASE-T SFP+ transceiver module delivers the flexibility and port density well known to the SFP+ form-factor, utilising Cat 6a UTP structured cabling for network connectivity. It is a power-optimised solution for lengths up to 30m, engineered to deliver a minimum power saving of at least 0.5W per port compared to an equivalent embedded 10GBASE-T RJ45 for the same length (Cat 6a, up to 30m). These power savings can add-up in ToR, mid-row and end-of-row switch connectivity.It's the alternative compared with standard SFP+ SR/LR fibre optics, which uses standard-based technology with the familiar RJ45 connector and provides backward compatibility with legacy networks.Specifications:- Performance- …

TP-LINK´s TL-SM321B adopts the latest 1000Base-BX standard, transmission over a single strand of fiber, with a different wavelength in each direction.You can extend the network distance up to 10Km with TP-LINK routers, switches, media converters, to provide high speed and stability.Features:-WDM Bidirectional SFP Module.-Supports bidirectional WDM technology, using a single strand of fiber, saves costs.Specifications:-Input voltage:3.3 V.-Operating temperature range:0 -70 °C.-Relative operating humidity:10 -90%.-Storage temperature range:-40 -80 °C.-Storage relative humidity:5 -90%.-SFP transceiver type:Fiber optic.-Maximum data transfer rate:1250 Mbit/s.-Interface type:SFP.-Maximum transfer dis…

The SFP transceivers are high-performance cost-effective modules supporting a data rate of 1.25Gbps with a transmission distance of up to 10KM over 9/125m (singlemode) optical fibre.

The transceiver consists of three sections: a FP laser transmitter a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472.
For further information please refer to SFP MSA.

The SFP transceivers are high-performance cost-effective modules supporting a data-rate of 1.25Gbps with a transmission distance of up to 550m over 50/125m optical fibre (300m over 62.5/125m).

The transceiver consists of three sections: a VCSEL laser transmitter a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and a MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472.

For further information please refer to SFP MSA.

The SFP transceivers are high-performance cost-effective modules supporting a data-rate of 1.25Gbps with a transmission distance of up to 550m over 50/125m optical fibre (300m over 62.5/125m).

The transceiver consists of three sections: a VCSEL laser transmitter a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and a MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472.

For further information please refer to SFP MSA.

The SFP transceivers are high-performance cost-effective modules supporting a data rate of 1.25Gbps with a transmission distance of up to 10KM over 9/125m (singlemode) optical fibre.

The transceiver consists of three sections: a FP laser transmitter a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472.
For further information please refer to SFP MSA.

TP-LINK TL-FC111B-20.Maximum data transfer rate:100 Mbit/s, Network standards:IEEE 802.3, IEEE 802.3i, IEEE 802.3x, Copper Ethernet cabling.Technology:10BASE-T, 100BASE-T.Fiber optic connector:SC, Connectivity.Technology:Wired.Maximum transfer distance:20000 m, Fiber mode structure:Singlemode, Supported cable fiber diameters:9/125 µm.LED Indicators:Activity, Link, Power, Product Color:Black,.Certification:FCC, CE.Output voltage:5 V, Output current:0.6 A.Specifications:-Connectivity.Technology:Cable.-Fiber optic connector:SC.-Ethernet LAN ports (RJ-45):1.-Fiber Channel ports:1.-Width:94.5 mm.-Depth:73 mm.-Height:27 mm.-Output voltage:5 V.-Output current:0.6 A.-Storage relative humidity:5 -90%.-…

MikroTik S-85DLC05D 1.25G Multi-Mode SFP TransceiverElevate your network´s performance and reach with the MikroTik S-85DLC05D, a high-performance, cost-effective SFP (Small Form-factor Pluggable) transceiver. Designed for reliability and seamless integration, this module is the ideal solution for extending your network connectivity over short distances using multi-mode fiber optic cable. Whether you are upgrading an existing infrastructure or building a new high-speed network, the S-85DLC05D provides the stable, gigabit-speed connection required for modern data-intensive applications.The S-85DLC05D is engineered to deliver exceptional performance in a wide range of networking environments. I…

EU Plug.The Tenda PoE30G-AT is the IEEE802.3 AT Gigabit PoE injector, which fully conforms to the standard of wtih 802.3, transmitting power through Ethernet cable, the maximum transmission distance can reach 100 meters.The PoE injector has two Ethernet gigabit data ports and an output port combination of data and power.In addition, the device can be used for Ethernet device IEEE802.3af/ compatible PoE power applications such as wireless AP, VoIP phone and web CAM.The power supply of Ethernet cable not only provides system reliability, traditional power grid expansion, but also simplifies the deployment of power lines.Features:- PoE ports supports IEEE802.3at and IEEE802.3af standard.- Equipped …

This 850nm VCSEL 10Gigabit SFP+ transceiver is designed to transmit and receive optical data over 50/125m or 62.5/125m multimode optical fibre.

The SFP+ SR module electrical interface is compliant with SFI electrical specifications. The transmitter input and receiver output impedance is 100 Ohms differential.

Data lines are internally AC coupled. The module provides differential termination and reduces differential to common mode conversion for quality signal termination and low EMI.

SFI typically operates over 200mm of improved FR4 material or up to 150mm of standard FR4 with one connector.

DIGITUS 10G SFP+ Direct Attach Cable, 0.5m (DN-8122) | High-Speed Network ConnectivityElevate your network´s performance with the DIGITUS SFP+ Direct Attach Cable (DN-8122), a superior solution for establishing high-speed, short-distance connections within your data center, enterprise network, or server room. This 50 cm cable is expertly engineered to provide a reliable, cost-effective, and low-power alternative to traditional optical transceivers and fiber cables for interconnecting switches, routers, servers, and storage devices.Designed for maximum efficiency, this Direct Attach Cable (DAC) offers a seamless plug-and-play experience. The integrated design, featuring SFP+ connectors on both e…

TP-LINK TL-FC111A-20.Maximum data transfer rate:100 Mbit/s, Network standards:IEEE 802.3, IEEE 802.3i, IEEE 802.3u, Copper Ethernet cabling.Technology:10BASE-T, 100BASE-T.Fiber optic connector:SC, Connectivity.Technology:Wired.Maximum transfer distance:20000 m, Fiber mode structure:Singlemode, Supported cable fiber diameters:9/125 µm.LED Indicators:Activity, Link, Power, Product Color:Black,.Certification:FCC, CE.Output voltage:5 V, Output current:0.6 A.Specifications:-Connectivity.Technology:Cable.-Fiber optic connector:SC.-Ethernet LAN ports (RJ-45):1.-Fiber Channel ports:1.-Width:94.5 mm.-Depth:73 mm.-Height:27 mm.-Output voltage:5 V.-Output current:0.6 A.-Storage relative humidity:5 -90%.-…

The SFP transceivers are high-performance cost-effective modules supporting a data rate of 1.25Gbps with a transmission distance of up to 10KM over 9/125m (singlemode) optical fibre.

The transceiver consists of three sections: a FP laser transmitter a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472.
For further information please refer to SFP MSA.

The plug and play fiber connection- The Plug & Play fiber optic link enables quick installation- Sends data in high quality and additionally provides excellent reliability- Distance up to 0.55km at a maximum data rate of 1.25Gbps- Operating temperature: 0 °C ~ 70 °CThe DIGITUS® mini GBIC (SFP) transceiver modules offer highest quality and reliability. Wether from switch to switch. converter to switch. converter to converter or any else application: The wide product range of DIGITUS® modules makes possible a flexible usage of the fiber technology. The conformity to the MSA (Multi Source Agreement) standard ensures a compatibility to third party manufacturers. Digitus mini GBIC (SFP) Module. 1.2…

1.25 Gbps SFP Module, Multimode, Cisco-compatible LC Duplex Connector, 850nm, up to 550m, Cisco. The DIGITUS® mini GBIC (SFP) transceiver modules offer highest quality and reliability. Wether from switch to switch, converter to switch, converter to converter or any else application: The wide product range of DIGITUS® modules makes possible a flexible usage of the fiber technology. The conformity to the MSA (Multi Source Agreement) standard ensures a compatibility to third party manufacturers. Compatible with the following manufacturers: Allied Telesis, Allnet, Avaya, CISCO, D-Link, Edimax, FINISAR, FORCE 10, Gigamon Intellinet, KTI Networks, Level One, PLANET, Tenda, TP-Link, TRENDnet, Mikrotik , …

Ubiquiti UACC-OM-MM-1G-D-2 | 1G Multi-Mode SFP Transceiver (2-Pack)Expand your network´s reach and unlock high-speed fiber optic performance with the Ubiquiti UACC-OM-MM-1G-D-2. This convenient two-pack of SFP (Small Form-factor Pluggable) transceivers is expertly engineered to provide reliable, 1 Gbps connectivity for your short-to-medium range network links. Designed for seamless integration into the Ubiquiti ecosystem, these modules are the perfect solution for connecting switches, routers, and other fiber-enabled devices across a building or campus environment, far beyond the distance limitations of traditional copper Ethernet cabling.These modules are built to deliver consistent throughput a…

This Fortinet® FN-TRAN-SX compatible SFP transceiver provides 1000Base-SX throughput up to 550m over multi-mode fiber (MMF) using a wavelength of 850nm via an LC connector. It is guaranteed to be 100% compatible with the equivalent Fortinet® transceiver. This easy to install. hot swappable transceiver has been programmed. uniquely serialized and data-traffic and application tested to ensure that it will initialize and perform identically. It is built to meet or exceed the specifications of Fortinet®. as well as to comply with MSA (Multi-Source Agreement) standards to ensure seamless network integration. This transceiver is Trade Agreements Act (TAA) compliant. AddOn Networks FN-TRAN-SX-AO net…

This Dell® SFP-1G-SX compatible SFP transceiver provides 1000Base-SX throughput up to 550m over multi-mode fiber (MMF) using a wavelength of 850nm via an LC connector. It is guaranteed to be 100% compatible with the equivalent Dell® transceiver. This easy to install. hot swappable transceiver has been programmed. uniquely serialized and data-traffic and application tested to ensure that it will initialize and perform identically. It is built to meet or exceed the specifications of Dell®. as well as to comply with MSA (Multi-Source Agreement) standards to ensure seamless network integration. This transceiver is Trade Agreements Act (TAA) compliant. We stand behind the quality of our products and…

Palo Alto Networks® PAN-SFP-PLUS-CU-1M compatible 10GBase-CU SFP+ transceiver (twinax DAC. 1m. passive). A 100% Palo Alto Networks® compatible 10GBase-CU SFP+ to SFP+ twinax direct attached cable that opperates over passive copper. with a maximum reach of 1.00m (3.28ft). This Palo Alto Networks® twinax cable is 100% compliant with its designed networking application. and is factory programed with Palo Alto Networks® specific configuration data required for seamless networking integration. This passive twinax cable will initialize and perform identically to Palo Alto Networks' cable and is built to meet or exceed Palo Alto Networks' specifications. and comply with MSA (Multi-Source Agreement) stan…
