NK 3 plate clamp, gripping range 80 - 120 mm, max. load 4500 kg. Supplied = assembled. Max. load = 4500 kg. Gripping range = 80 - 120 mm. Weight = 27 kg. Product type = clamps. High max. load and secure grip. Easy handling and quick to lock in place. Automatic lock. These clamps are particularly suitable for lifting and turning metal plates, iron profiles, welded components and steel skeletons. They are characterised by their high max. load and a robust and simple design. The safety factor exceeds the requirements in the standard EN 13155. No wear occurs, nor any steel markings. These clamps lock when closed as well.

KS plate clamp, gripping range 0 - 30 mm, max. load 3000 kg. Supplied = assembled. Max. load = 3000 kg. Gripping range = 0 - 30 mm. Weight = 12.1 kg. Product type = clamps. Multifunctional clamp for straightforward and safe use. Lifting eye with large gripping range. Low weight. Plate clamp for daily requirements. They are suitable for both turning and lifting, and feature a lever with a safety catch. The pressure of the clamp is only applied to one side of the sheet steel, which protects the surface from damage.

PULLMASTER-II spur gear block and tackle, standard lifting height 3 m, max. load 2000 kg, 2+ items. Supplied = assembled. Max. load = 2000 kg. Lift = 3 m. Number of chain strands = 2 pcs. Housing material = sheet steel, powder coated. Scope of delivery = with load chain. Overall height = 470 mm. Hand chain tensile force at full load = 33 daN. Product type = block and tackles. Tempered safety hook with custom-fit hook lock. Robust, durable steel housing. Flexible use due to hook suspension. Very stable spur gear block and tackle with compact dimensions. The asbestos-free safety brake stops reliably and holds the weight in any position. The load hook made of hot formed tempering steel is electrolytically …

PULLMASTER-II spur gear block and tackle, standard lifting height 3 m, max. load 1000 kg, 2+ items. Supplied = assembled. Max. load = 1000 kg. Lift = 3 m. Number of chain strands = 1 pcs. Housing material = sheet steel, powder coated. Scope of delivery = with load chain. Overall height = 332 mm. Hand chain tensile force at full load = 32.4 daN. Product type = block and tackles. Tempered safety hook with custom-fit hook lock. Robust, durable steel housing. Flexible use due to hook suspension. Very stable spur gear block and tackle with compact dimensions. The asbestos-free safety brake stops reliably and holds the weight in any position. The load hook made of hot formed tempering steel is electrolytically …

PULLMASTER-II spur gear block and tackle, standard lifting height 3 m, max. load 500 kg, 2+ items. Supplied = assembled. Max. load = 500 kg. Lift = 3 m. Number of chain strands = 1 pcs. Housing material = sheet steel, powder coated. Scope of delivery = with load chain. Overall height = 285 mm. Hand chain tensile force at full load = 26.2 daN. Product type = block and tackles. Tempered safety hook with custom-fit hook lock. Robust, durable steel housing. Flexible use due to hook suspension. Very stable spur gear block and tackle with compact dimensions. The asbestos-free safety brake stops reliably and holds the weight in any position. The load hook made of hot formed tempering steel is electrolytically …

AH ratchet chain hoist, standard lifting height 1.5 m, max. load 1600 kg, 2+ items. Supplied = assembled. Max. load = 1600 kg. Lift = 1.5 m. Number of chain strands = 1 pcs. Overall height (between device hook / load hook inner edges) = 355 mm. Power required at full load = 25. Housing material = aluminium. Product type = ratchet chain hoists. Small lightweight design made of aluminium. Can be used at ambient temperatures from -20 °C to +60 °C. Robust chain end piece for reliable grip. Thanks to its AH aluminium ratchet chain hoist, the new aluminium ratchet chain hoist is an indispensable tool in industry and service. A closed die-cast housing protects the internal parts. Its two robust hook lo…

AH ratchet chain hoist, standard lifting height 1.5 m, max. load 800 kg, 2+ items. Supplied = assembled. Max. load = 800 kg. Lift = 1.5 m. Number of chain strands = 1 pcs. Overall height (between device hook / load hook inner edges) = 329 mm. Power required at full load = 22. Housing material = aluminium. Product type = ratchet chain hoists. Small lightweight design made of aluminium. Can be used at ambient temperatures from -20 °C to +60 °C. Robust chain end piece for reliable grip. Thanks to its AH aluminium ratchet chain hoist, the new aluminium ratchet chain hoist is an indispensable tool in industry and service. A closed die-cast housing protects the internal parts. Its two robust hook lo…

AH ratchet chain hoist, standard lifting height 1.5 m, max. load 250 kg. Supplied = assembled. Max. load = 250 kg. Lift = 1.5 m. Number of chain strands = 1 pcs. Overall height (between device hook / load hook inner edges) = 223 mm. Power required at full load = 17. Housing material = aluminium. Product type = ratchet chain hoists. Small lightweight design made of aluminium. Can be used at ambient temperatures from -20 °C to +60 °C. Robust chain end piece for reliable grip. Thanks to its AH aluminium ratchet chain hoist, the new aluminium ratchet chain hoist is an indispensable tool in industry and service. A closed die-cast housing protects the internal parts. Its two robust hook locks ensures th…

LB panel cable winch, stainless steel, max. lifting load 900 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 26 m. Wire rope diameter = 7 mm. Lifting capacity = 900 kg. Material = stainless steel V2A. Lift drive = spur gear transmission. Product type = cable winches. All parts as a high quality V2A stainless steel version. Easy and quick panel mounting. Built-on load pressure brake securely holds loads in any position. The LB cable winch, originally developed as a vehicle winch, is now used for lifting and hauling all sorts of different loads. Wire rope not included in the delivery. Cables available upon request. Please specify the required length and the required …

LB panel cable winch, stainless steel, max. lifting load 250 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 19.5 m. Wire rope diameter = 4 mm. Lifting capacity = 250 kg. Material = stainless steel V2A. Lift drive = spur gear transmission. Product type = cable winches. All parts as a high quality V2A stainless steel version. Easy and quick panel mounting. Built-on load pressure brake securely holds loads in any position. The LB cable winch, originally developed as a vehicle winch, is now used for lifting and hauling all sorts of different loads. Wire rope not included in the delivery. Cables available upon request. Please specify the required length and the required …

LB panel cable winch, sheet steel, zinc plated, max. lifting load 650 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 20 m. Wire rope diameter = 6 mm. Lifting capacity = 650 kg. Material = sheet steel. Finish = zinc plated. Lift drive = spur gear transmission. Product type = cable winches. Robust sheet steel housing with a low weight. All parts zinc plated, wire rope drum additional coated for increased corrosion protection. Built-on load pressure brake securely holds loads in any position. The LB cable winch, originally developed as a vehicle winch, is now used for lifting and hauling all sorts of different loads. Wire rope not included in the delivery. Cables available …

LB panel cable winch, sheet steel, zinc plated, max. lifting load 350 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 20 m. Wire rope diameter = 4 mm. Lifting capacity = 350 kg. Material = sheet steel. Finish = zinc plated. Lift drive = spur gear transmission. Product type = cable winches. Robust sheet steel housing with a low weight. All parts zinc plated, wire rope drum additional coated for increased corrosion protection. Built-on load pressure brake securely holds loads in any position. The LB cable winch, originally developed as a vehicle winch, is now used for lifting and hauling all sorts of different loads. Wire rope not included in the delivery. Cables available …

ALPHA wall mounted cable winch, sheet steel, max. lifting load 500 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 20 m. Wire rope diameter = 6 mm. Lifting capacity = 500 kg. Material = sheet steel. Lift drive = spur gear transmission. Product type = cable winches. Robust sheet steel housing with a low weight and a slim design. Wire rope exit possible in all directions. All parts zinc plated, the wire rope drum is also CDP coated. The versatile ALPHA wall mounted cable winch for lifting loads. Wire rope not included in the delivery. Cables available upon request. Please specify the required length and the required accessories (cable eye/hook).

ALPHA wall mounted cable winch, sheet steel, max. lifting load 300 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 28 m. Wire rope diameter = 5 mm. Lifting capacity = 300 kg. Material = sheet steel. Lift drive = spur gear transmission. Product type = cable winches. Robust sheet steel housing with a low weight and a slim design. Wire rope exit possible in all directions. All parts zinc plated, the wire rope drum is also CDP coated. The versatile ALPHA wall mounted cable winch for lifting loads. Wire rope not included in the delivery. Cables available upon request. Please specify the required length and the required accessories (cable eye/hook).

ALPHA wall mounted cable winch, sheet steel, max. lifting load 1000 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 26 m. Wire rope diameter = 7 mm. Lifting capacity = 1000 kg. Material = sheet steel. Lift drive = spur gear transmission. Product type = cable winches. Robust sheet steel housing with a low weight and a slim design. Wire rope exit possible in all directions. All parts zinc plated, the wire rope drum is also CDP coated. The versatile ALPHA wall mounted cable winch for lifting loads. Wire rope not included in the delivery. Cables available upon request. Please specify the required length and the required accessories (cable eye/hook).

Hand operated puller, ideal for lifting and moving vehicles, logs, machines and other heavy objects. Features two levers for extra control when pulling or releasing load. Additional quick release lever saves time when adjusting rope length. Supplied with removable lever handle and 20m wire rope with heavy-duty hook. Features & Benefits: • Ideal for lifting and moving vehicles, logs, machines and other heavy objects. • Two levers for extra control when pulling or releasing load. • Quick release lever saves time when adjusting rope length. • Supplied with removable lever handle and 20m wire rope with heavy-duty hook. • Model No. WRP3200 Specifications: Model No WRP3200 Brand: Sealey Breaking S…

Hand operated puller, ideal for lifting and moving vehicles, logs, machines and other heavy objects. Features two levers for extra control when pulling or releasing load. Additional quick release lever saves time when adjusting rope length. Supplied with removable lever handle and 20m wire rope with heavy-duty hook. Features & Benefits: • Ideal for lifting and moving vehicles, logs, machines and other heavy objects. • Two levers for extra control when pulling or releasing load. • Quick release lever saves time when adjusting rope length. • Supplied with removable lever handle and 20m wire rope with heavy-duty hook. • Model No. WRP1600 Specifications: Model No WRP1600 Brand: Sealey Breaking S…

All winches are supplied as standard with wire rope. As this is a consumable part replacement ropes are available (N.B. Hook not included). See winch specification chart for correct model number to suit your winch. Features & Benefits: • Wire rope for Model No's SRW4300 and SRW5450 self recovery winches. • Rope Ø x Length: 9.2mm x 26m. • Model No. SRW5450.WR Specifications: Model No SRW5450.WR Application(s): SRW4300, SRW5450 Brand: Sealey Diameter: 9.2mm Length: 26m Nett Weight: 9.25kg

1350kg Breaking strength suitable for use with winches up to 908kg/2000lb. Ideal for use with ATV and quad bike winches. Zinc Coating to protect from the elements and corrosion. 45 Grade steel cable is carbon structured steel with a tensile strength around 610Mpa and widely used in manufacturing machinery. 10m Long cable, more than enough for loading ATV’s and recovery of small vehicles. Features & Benefits: • 1350kg Breaking strength suitable for use with winches up to 908kg/2000lb. • Ideal for use with ATV and quad bike winches. • Zinc Coating to protect from the elements and corrosion. • 45 Grade steel cable is carbon structured steel with a tensile strength around 610Mpa and widely used in ma…

810kg breaking strength suitable for use with winches up to 540kg/1200lb. Ideal for use with ATV and quad bike winches. Zinc Coating to protect from the elements and corrosion. 45 grade steel cable is carbon structured steel with a tensile strength of around 610Mpa and widely used in manufacturing machinery. 10m long cable, more than enough for loading ATV’s and recovered of small vehicles. Features & Benefits: • 810kg Breaking strength suitable for use with winches up to 540kg/1200lb. • Ideal for use with ATV and quad bike winches. • Zinc Coating to protect from the elements and corrosion. • 45 Grade steel cable is carbon structured steel with a tensile strength of around 610Mpa and widely…

Universal wireless remote control kit has a 4-pin plug-and-play receiver. With a range of up to 30m (dependant on environment), a wireless remote control is an essential accessory. Weatherproof receiver and handset making it ideal for off-roaders and recovery trucks, enabling the operator to stand well clear or sit in the cab (provided there are no restrictions). Features & Benefits: • Universal wireless remote control has a 4-pin plug-and-play receiver. • With a range of up to 30m (dependant on the environment), a wireless remote control is an essential accessory. • Weatherproof receiver and handset making them ideal for off-roaders and recovery trucks, enabling the operator to stand well c…

This industrial recovery winch is designed and built for breakdown recovery and off-road use. Features 12V DC heavy-duty motor with 4-stage planetary gears, using oversized components for greater torque, plus an automatic 'in drum' brake. Winch has weather sealed solenoids and ergonomic 'lift & turn' free spool clutch. Supplied with wire rope, latched hook, 4-way roller fairlead for smooth and even distribution of cable onto drum and plug-in handheld controller as standard. Ideal for flatbed pick-up or other recovery trucks. Features & Benefits: Package Includes: • Model No. - Description • RW8180 - 12V Industrial Recovery Winch 8180kg(18000lb) Line Pull • UWRC01 - 4-Pin Universal Winch Remote…
