Hoists & Winches

• Machined from billet aluminium.• Designed specifically for use with synthetic winch rope.• Unlike conventional steel fairleads, an aluminium hawse will not fray or tangle synthetic winch rope.• Distance between mounting centres: 152mm.• Not for use with steel winch cables.Machined from billet aluminium. Designed specifically for use with synthetic winch rope. Unlike conventional steel fairleads, an aluminium hawse will not fray or tangle synthetic winch rope. Not for use with steel winch cables.• Machined from billet aluminium. • Designed specifically for use with synthetic winch rope. • Unlike conventional steel fairleads, an aluminium hawse will not fray or tangle synthetic winch rope. • Di…

PULLMASTER-II spur gear block and tackle, standard lifting height 3 m, max. load 2000 kg, 2+ items. Supplied = assembled. Max. load = 2000 kg. Lift = 3 m. Number of chain strands = 2 pcs. Housing material = sheet steel, powder coated. Scope of delivery = with load chain. Overall height = 470 mm. Hand chain tensile force at full load = 33 daN. Product type = block and tackles. Tempered safety hook with custom-fit hook lock. Robust, durable steel housing. Flexible use due to hook suspension. Very stable spur gear block and tackle with compact dimensions. The asbestos-free safety brake stops reliably and holds the weight in any position. The load hook made of hot formed tempering steel is electrolytically …

PULLMASTER-II spur gear block and tackle, standard lifting height 3 m, max. load 1000 kg, 2+ items. Supplied = assembled. Max. load = 1000 kg. Lift = 3 m. Number of chain strands = 1 pcs. Housing material = sheet steel, powder coated. Scope of delivery = with load chain. Overall height = 332 mm. Hand chain tensile force at full load = 32.4 daN. Product type = block and tackles. Tempered safety hook with custom-fit hook lock. Robust, durable steel housing. Flexible use due to hook suspension. Very stable spur gear block and tackle with compact dimensions. The asbestos-free safety brake stops reliably and holds the weight in any position. The load hook made of hot formed tempering steel is electrolytically …

PULLMASTER-II spur gear block and tackle, standard lifting height 3 m, max. load 500 kg, 2+ items. Supplied = assembled. Max. load = 500 kg. Lift = 3 m. Number of chain strands = 1 pcs. Housing material = sheet steel, powder coated. Scope of delivery = with load chain. Overall height = 285 mm. Hand chain tensile force at full load = 26.2 daN. Product type = block and tackles. Tempered safety hook with custom-fit hook lock. Robust, durable steel housing. Flexible use due to hook suspension. Very stable spur gear block and tackle with compact dimensions. The asbestos-free safety brake stops reliably and holds the weight in any position. The load hook made of hot formed tempering steel is electrolytically …

AH ratchet chain hoist, standard lifting height 1.5 m, max. load 1600 kg, 2+ items. Supplied = assembled. Max. load = 1600 kg. Lift = 1.5 m. Number of chain strands = 1 pcs. Overall height (between device hook / load hook inner edges) = 355 mm. Power required at full load = 25. Housing material = aluminium. Product type = ratchet chain hoists. Small lightweight design made of aluminium. Can be used at ambient temperatures from -20 °C to +60 °C. Robust chain end piece for reliable grip. Thanks to its AH aluminium ratchet chain hoist, the new aluminium ratchet chain hoist is an indispensable tool in industry and service. A closed die-cast housing protects the internal parts. Its two robust hook lo…

AH ratchet chain hoist, standard lifting height 1.5 m, max. load 800 kg, 2+ items. Supplied = assembled. Max. load = 800 kg. Lift = 1.5 m. Number of chain strands = 1 pcs. Overall height (between device hook / load hook inner edges) = 329 mm. Power required at full load = 22. Housing material = aluminium. Product type = ratchet chain hoists. Small lightweight design made of aluminium. Can be used at ambient temperatures from -20 °C to +60 °C. Robust chain end piece for reliable grip. Thanks to its AH aluminium ratchet chain hoist, the new aluminium ratchet chain hoist is an indispensable tool in industry and service. A closed die-cast housing protects the internal parts. Its two robust hook lo…

AH ratchet chain hoist, standard lifting height 1.5 m, max. load 250 kg. Supplied = assembled. Max. load = 250 kg. Lift = 1.5 m. Number of chain strands = 1 pcs. Overall height (between device hook / load hook inner edges) = 223 mm. Power required at full load = 17. Housing material = aluminium. Product type = ratchet chain hoists. Small lightweight design made of aluminium. Can be used at ambient temperatures from -20 °C to +60 °C. Robust chain end piece for reliable grip. Thanks to its AH aluminium ratchet chain hoist, the new aluminium ratchet chain hoist is an indispensable tool in industry and service. A closed die-cast housing protects the internal parts. Its two robust hook locks ensures th…

LB panel cable winch, stainless steel, max. lifting load 900 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 26 m. Wire rope diameter = 7 mm. Lifting capacity = 900 kg. Material = stainless steel V2A. Product type = cable winches. Lift drive = spur gear transmission. All parts as a high quality V2A stainless steel version. Easy and quick panel mounting. Built-on load pressure brake securely holds loads in any position. The LB cable winch, originally developed as a vehicle winch, is now used for lifting and hauling all sorts of different loads. Wire rope not included in the delivery.

LB panel cable winch, stainless steel, max. lifting load 650 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 20 m. Wire rope diameter = 6 mm. Lifting capacity = 650 kg. Material = stainless steel V2A. Product type = cable winches. Lift drive = spur gear transmission. All parts as a high quality V2A stainless steel version. Easy and quick panel mounting. Built-on load pressure brake securely holds loads in any position. The LB cable winch, originally developed as a vehicle winch, is now used for lifting and hauling all sorts of different loads. Wire rope not included in the delivery.

LB panel cable winch, stainless steel, max. lifting load 250 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 19.5 m. Wire rope diameter = 4 mm. Lifting capacity = 250 kg. Material = stainless steel V2A. Product type = cable winches. Lift drive = spur gear transmission. All parts as a high quality V2A stainless steel version. Easy and quick panel mounting. Built-on load pressure brake securely holds loads in any position. The LB cable winch, originally developed as a vehicle winch, is now used for lifting and hauling all sorts of different loads. Wire rope not included in the delivery.

LB panel cable winch, sheet steel, zinc plated, max. lifting load 1200 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 26 m. Wire rope diameter = 7 mm. Lifting capacity = 1200 kg. Material = sheet steel. Finish = zinc plated. Product type = cable winches. Lift drive = spur gear transmission. Robust sheet steel housing with a low weight. All parts zinc plated, wire rope drum additional coated for increased corrosion protection. Built-on load pressure brake securely holds loads in any position. The LB cable winch, originally developed as a vehicle winch, is now used for lifting and hauling all sorts of different loads. Wire rope not included in the delivery.

LB panel cable winch, sheet steel, zinc plated, max. lifting load 650 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 20 m. Wire rope diameter = 6 mm. Lifting capacity = 650 kg. Material = sheet steel. Finish = zinc plated. Product type = cable winches. Lift drive = spur gear transmission. Robust sheet steel housing with a low weight. All parts zinc plated, wire rope drum additional coated for increased corrosion protection. Built-on load pressure brake securely holds loads in any position. The LB cable winch, originally developed as a vehicle winch, is now used for lifting and hauling all sorts of different loads. Wire rope not included in the delivery.

LB panel cable winch, sheet steel, zinc plated, max. lifting load 350 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 20 m. Wire rope diameter = 4 mm. Lifting capacity = 350 kg. Material = sheet steel. Finish = zinc plated. Product type = cable winches. Lift drive = spur gear transmission. Robust sheet steel housing with a low weight. All parts zinc plated, wire rope drum additional coated for increased corrosion protection. Built-on load pressure brake securely holds loads in any position. The LB cable winch, originally developed as a vehicle winch, is now used for lifting and hauling all sorts of different loads. Wire rope not included in the delivery.

ALPHA wall mounted cable winch, sheet steel, max. lifting load 500 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 20 m. Wire rope diameter = 6 mm. Lifting capacity = 500 kg. Material = sheet steel. Product type = cable winches. Lift drive = spur gear transmission. Robust sheet steel housing with a low weight and a slim design. Wire rope exit possible in all directions. All parts zinc plated, the wire rope drum is also CDP coated. The versatile ALPHA wall mounted cable winch for lifting loads. Wire rope not included in the delivery.

ALPHA wall mounted cable winch, sheet steel, max. lifting load 300 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 28 m. Wire rope diameter = 5 mm. Lifting capacity = 300 kg. Material = sheet steel. Product type = cable winches. Lift drive = spur gear transmission. Robust sheet steel housing with a low weight and a slim design. Wire rope exit possible in all directions. All parts zinc plated, the wire rope drum is also CDP coated. The versatile ALPHA wall mounted cable winch for lifting loads. Wire rope not included in the delivery.

ALPHA wall mounted cable winch, sheet steel, max. lifting load 1000 kg. Supplied = pre-assembled, final assembly by customer. Wire rope length = 26 m. Wire rope diameter = 7 mm. Lifting capacity = 1000 kg. Material = sheet steel. Product type = cable winches. Lift drive = spur gear transmission. Robust sheet steel housing with a low weight and a slim design. Wire rope exit possible in all directions. All parts zinc plated, the wire rope drum is also CDP coated. The versatile ALPHA wall mounted cable winch for lifting loads. Wire rope not included in the delivery.

Delivered in knock-down form for reduced freight cost. Heavy-duty front and rear castors are on extendable legs to give improved stability, particularly when operating at maximum jib extension of 1447mm. Side pump access with removable handle. Features & Benefits: • Economy model - requires self-assembly. • Heavy-duty castors on extendable legs for improved stability. • Lifts 1000kg at 937mm and 250kg at 1447mm jib extension. • Side pump access with removable handle. • This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery. • Model No. SC10LR Specifications: Model No SC10LR Brand: Sealey Height Jib Down: 1446mm Height of Frame: 180mm Length Legs …

• Super economy model delivered in knock-down form for reduced freight cost.• Fast folding model provides easy storage and transportation.• Heavy-duty castors.• Weighs only 75kg and is perfect for mobile or workshop use.• Side pump access with removable handle.Super economy model delivered in knock-down form for reduced freight cost. Fast folding model provides easy storage and transportation with heavy-duty castors. Weighs only 75kg and is perfect for mobile or workshop use. Side pump access with removable handle.• Lifts 1000kg at 830mm jib extension. • Fast folding design. • Heavy-duty castors. • Weighs only 75kg. • Side pump access with removable handle. • Delivered in knock-down form. • …

BETA SL electric cable winch, protection class IP55, max. load 2000 kg, 6.8 m/min. Supplied = pre-assembled, final assembly by customer. Max. load = 2000 kg. Wire rope length = 73.8 m. Wire rope speed = 6,8 m/min. Weight = 207 kg. Protection type = IP55. Product type = cable winches. Very quiet running due to helical gearing. Motor protection type IP55. Maintenance free worm gears or low maintenance spur gear transmission with milled and polished gear wheels - runs in a oil bath. Long periods of operation follow short delivery times: the standard version of the BETA SL electric cable winch operates reliably over the long term due to its closed worm gear or spur gear transmission with high quality …

BETA SL electric cable winch, protection class IP55, max. load 1250 kg, 6 m/min. Supplied = pre-assembled, final assembly by customer. Max. load = 1250 kg. Wire rope length = 77.5 m. Wire rope speed = 6 m/min. Weight = 119 kg. Protection type = IP55. Product type = cable winches. Very quiet running due to helical gearing. Motor protection type IP55. Maintenance free worm gears or low maintenance spur gear transmission with milled and polished gear wheels - runs in a oil bath. Long periods of operation follow short delivery times: the standard version of the BETA SL electric cable winch operates reliably over the long term due to its closed worm gear or spur gear transmission with high quality …
