Other for Construction Draper

Extruded from 30mm wide anodized aluminium. Clearly graduated both sides mm/cm, inches, 1/8" and metric/imperial equivalents of length, area, volume and weight. Display packed.

Matt black metal stock with machined faces and spirit level. Polished steel blade is graduated mm and 1/16" on both sides. Display packed.

Matt black metal stock with polished faces, brass adjusting screw, spirit level and scriber. Aluminium blade graduated (on both sides of the blade) metric on one edge and imperial on the other. Display packed.

Tough impact resistant ABS case with soft grip, blade locking button and belt clip. Hold and measure button allows user to lock tape for accurate measurements with button on base to control speed of return blade into tape. Power return nylon coated blade has clear black and red graduations, metres into cm/mm and feet into inches, 1/8" and 1/16". Yellow wear resistant coating. Stud centre markings every 16". Self-aligning end hook for very accurate internal/external measurements. Display packed.

Tough impact resistant ABS case with soft grip, blade locking button and belt clip. Hold and measure button allows user to lock tape for accurate measurements with button on base to control speed of return blade into tape. Power return nylon coated blade has clear black and red graduations, metres into cm/mm and feet into inches, 1/8" and 1/16". Yellow wear resistant coating. Stud centre markings every 16". Self-aligning end hook for very accurate internal/external measurements. Display packed.

Plastic tape cases with locking button and belt clip. Power return blade has clear graduations, metres into cm/mm and feet into inches, 1/8", 1/16" and 1/32". Yellow wear resistant coating. Stud centre markings every 16". Self-aligning end hook for accurate internal/external measurements.

Tough impact resistant ABS case with soft grip, blade locking button and belt clip. Hold and measure button allows user to lock tape for accurate measurements with button on base to control speed of return blade into tape. Power return nylon coated blade has clear black and red graduations, metres into cm/mm and feet into inches, 1/8" and 1/16". Yellow wear resistant coating. Stud centre markings every 16". Self-aligning end hook for very accurate internal/external measurements. Display packed.

Expert Quality, made with solid steel stock with a hardened, tempered and finely polished blade. The squareness of the blade edges and the stock working face falls within ±0.016mm/0.0064" tolerance. Display packed.

Fibreglass tapes graduated metres into cm/mm and feet into inches and 1/8" on reverse. ABS plastic case with a plated, flush winding handle and stainless steel holding claw on end of tape. Display packed.

Expert Quality, steel tape 13mm wide, graduated metres into cm/mm and feet into inches and 1/8". ABS plastic case with a plated, flush winding handle and stainless steel holding claw on end of tape. Display packed.

Fibreglass tapes graduated metres into cm/mm and feet into inches and 1/8" on reverse. ABS plastic case with a plated, flush winding handle and stainless steel holding claw on end of tape. Display packed.

Expert Quality, manufactured from hardened stainless steel. Reading 0.02mm/1/1000". Four way measurement: internal, external, depth and step. Satin scales with fine adjustment. Fine screw adjustment. Display packed in plastic storage case.

Expert Quality, manufactured from hardened stainless steel. Reading 0.02mm and 1/1000". Four way measurement: internal, external, depth and step. Satin chrome plated beam with raised edges and thumb lock. Display packed in plastic storage case.

Expert Quality, manufactured from hardened stainless steel. Reading 0.02mm/1/1000". Four way measurement: internal, external, depth and step. Satin scales with fine adjustment. Fine screw adjustment. Display packed in plastic storage case.

100mm long taper blades. Each blade is marked with its size and folds into a plated steel case with thumbscrew. Display packed.

Combination gauge for the setting of valve tappets on motorcycles, mowers, cars, vans, etc. The dual marked blades are 95mm long and offset to give improved access to the engine and are hardened and polished for long accurate life. Each blade is marked with its size and folds into a polished steel case with thumbscrew. Display packed.

Folding leaves, individually stamped with accurately formed thread profiles. American National Thread UNC - UNF, in the range 4 - 62TPI. Sold loose.

Box section levels made from high quality Aluminium with three permanently fixed shock resistant acrylic UV resistant vials, 300mm - one horizontal and one vertical vials, 600mm,900mm and 1200mm - one horizontal and two vertical vials, precision milled bottom. V - Groove for levelling pipework. All the levels are electrostatically epoxy powder coated and baked for maximum protection. Fitted with shock absorbing end caps. Accuracy of 0.5mm per 1M = 0.029° in standard position.

Expert Quality, Aluminium box section levels with side view feature, comprising three highly visible solid acrylic and UV resistant vials, one magnified horizontal vial and two vertical vials, one with side view vial feature, milled base up to 1200mm. The 1.8M is fitted with one horizontal magnified vial and has an unmilled base. All the levels are electrostatically epoxy powder coated and baked for maximum protection. Fitted with shock absorbing end caps. The base has a finely milled surface (1.8M unground). Accuracy 0.5mm per 1M = 0.029° (1800mm 1mm per 1M = 0.057°) in standard position.

Expert Quality, Aluminium box section levels with side view feature, comprising three highly visible solid acrylic and UV resistant vials, one magnified horizontal vial and two vertical vials, one with side view vial feature, milled base up to 1200mm. The 1.8M is fitted with one horizontal magnified vial and has an unmilled base. All the levels are electrostatically epoxy powder coated and baked for maximum protection. Fitted with shock absorbing end caps. The base has a finely milled surface (1.8M unground). Accuracy 0.5mm per 1M = 0.029° (1800mm 1mm per 1M = 0.057°) in standard position.

General purpose calipers with thumb wheel fine adjustment. Can be used for internal, external and depth measurements. Graduations shown in metric (cm/mm) and imperial inch marks. Display packed.

100mm long taper blades. Each blade is marked with its size and folds into a plated steel case with thumbscrew. Display packed.

100mm long taper blades, hardened and polished for long accurate life. Each blade is marked with its size and folds into a polished steel case with thumbscrew. Display packed.

Folding leaves, individually stamped with accurately formed thread profiles. 20 blades ranging from 0.4, 0.45, 0.5, 0.6, 0.7, 0.75, 0.8, 1.0, 1.25, 1.5, 1.75, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0mm. Sold loose.
