Compact UniFi Protect NVR Kit. includes (1) UniFi Protect NVR Instant with (4) G5 Turret Ultra cameras and (1) 1TB HDD. deliv... moreering an all-in-one solution for fast and effortless setup. Ubiquiti UNVR-Instant-Kit video surveillance kit Wired
Ubiquiti Network Video Recorder Instant Kit
Compact UniFi Protect NVR Kit includes (1) UniFi Protect NVR Instant with (4)... moreG5 Turret Ultra cameras and (1) 1TB HDD delivering an all-in-one solution for fast and effortless setup.
Network Video Recorder Instant
Dimensions
220 x 220 x 47 mm
(8.7 x 8.7 x 1.9")
UniFi Application Suite
Protect - Yes
Access - Yes
Managed Cameras
(15) HD
(8) 2K
(6) 4K
Storage Capacity
(1) 3.5" drive bay
Data Protection
Yes
Vantage Point
Yes
Networking Interface
(1) GbE RJ45 uplink port
(6) GbE PoE RJ45 downlink ports
(1) HDMI port (Viewport)
Form Factor
Compact Desktop
Mounting
Wall Din rail mount (Included)
Door Access Support
Yes
Hard Drive Capacity
(1) 3.5" HDD support
Max. Power Budget for Drives
11W
Max. Power Consumption
9W
Power Method
Universal AC input 100-240VAC 1.5A Max 50/60 Hz
Power Supply
AC/DC Internal 60W
PoE Budget
40W
Max. PoE Wattage per Port by PSE
PoE
15.4W
Voltage Range PoE Mode
44?57V
Processor
Quad-core ARM Cortex-A55 at 1.7 GHz
Memory
4 GB
Management
Ethernet
Bluetooth
Display
1.14" screen
Weight
1.04 kg (2.3 lb)
Enclosure Materials
Polycarbonate
Mount Material
Polycarbonate
LEDs
Ethernet - Yes
PoE - Yes
Ambient Operating Temperature
0 to 40 C (32 to 104 F)
Ambient Operating Humidity
5 to 95% noncondensing
NDAA Compliant
Yes
Certifications
FCC IC CE Electrical Safety UL
G5 Turret Ultra
Dimensions
90 x 71.2 mm
(3.5 x 2.8")
IR Night Vision
30 m (98 ft)
Smart Detections (People Vehicles Animals)
Yes
Resolution
2K
Field of View
H: 102.4 V: 54.9 D: 120.6
Audio/b>
Microphone
Weatherproofing
IP66
Tamper Resistance
IK04
Mounting
Wall ceiling mount (Included)
Junction box arm mount (Optional)
Networking Interface
10/100 MbE RJ45 port
Video
Image Settings
Color brightness sharpness contrast white balance exposure control 2DNR 3DNR NR by motion masking text overlay
Max. Frame Rate
30 FPS
Resolution
4MP 2688 x 1512 (16:9)
Optics
Sensor
1/2.4" CMOS
Lens
Fixed focal length
Night Mode
Built-in IR LED illumination and IR cut filter
Max. Power Consumption
4W
Supported Voltage Range
37?57V DC
Power Method
PoE
Processor
Dual-core Arm Cortex-A7 based chip
Weight
330 g (11.6 oz)
Enclosure Material
Aluminum alloy UV-stabilized polycarbonate
Mount Material
Polycarbonate
Button
(1) Factory-reset
Cable
Cable Connector Type
RJ45
Cable Diameter
5 mm (0.2")
Cable Length
30 cm (1 ft)
Jacket Material
Polycarbonate
Jacket Enclosure Dimensions
20 x 70.6 mm (0.8 x 2.8")
Jacket Enclosure Material
Thermoplastic elastomer polycarbonate silicone rubber
Ambient Operating Temperature
-30 to 50 C (-22 to 122 F)
Ambient Operating Humidity
0 to 90% noncondensing
NDAA Compliant
?
Certifications
CE FCC IC
HDD
Dimensions
147 x 101.6 x 26.1 mm (5.75 x 4 x 1")
pa_mpn: 906, pa_sku: 2028, pa_ean-gtin: 2029, pa_brand: 1878 An all-in-one, compact surveillance solution by Ubiquiti that in... morecludes the UNVR-Instant video recorder, four G5 Turret Ultra cameras, and a 1TB hard drive. It provides a simple setup by bundling all components for immediate deployment, designed to deliver enterprise-class security performance for homes, small businesses, and builders without complex configuration or licensing fees. Key features All-in-one kit: Includes the UNVR-Instant recorder, four G5 Turret Ultra cameras, and a 1TB hard drive for immediate, out-of-box operation. Compact and silent: The fanless design makes it suitable for small deployments. Simplified setup: Features a one-click setup with UniFi Protect and PoE support to power and connect cameras directly to the NVR's integrated switch. Local and remote access: Manages and views recordings through the UniFi Protect app or web interface, with secure local storage. Local monitoring: Includes an HDMI ViewPort for on-site monitoring on a TV or monitor without needing an external PC. Scalable storage: The 1TB drive is expandable via a USB-C port and has a 3.5" bay for a larger drive. High-performance: Equipped with a quad-core processor and 4GB of memory, the system can handle up to six 4K cameras or fifteen Full HD cameras. Compliance: NDAA compliant and certified by FCC, IC, and CE Network Video Recorder InstantDimensions 220 x 220 x 47 mm (8.7 x 8.7 x 1.9")UniFi Application Suite Protect - Yes / Access - YesManaged Cameras (15) HD / (8) 2K / (6) 4KStorage Capacity (1) 3.5" drive bayData Protection YesVantage Point YesNetworking Interface (1) GbE RJ45 uplink port / (6) GbE PoE RJ45 downlink ports / (1) HDMI port (Viewport)Form Factor Compact DesktopMounting Wall, Din rail mount (Included)Door Access Support YesHard Drive Capacity (1) 3.5" HDD supportMax. Power Budget for Drives 11WMax. Power Consumption 9WPower Method Universal AC input, 100-240VAC, 1.5A Max, 50/60 HzPower Supply AC/DC, Internal, 60WPoE Budget 40WMax. PoE Wattage per Port by PSE PoE 15.4WVoltage Range PoE Mode 44–57VProcessor Quad-core ARM Cortex-A55 at 1.7 GHzMemory 4 GBManagement Ethernet / BluetoothDisplay 1.14" screenWeight 1.04 kg (2.3 lb)Enclosure Materials Polycarbonate Mount Material PolycarbonateLEDs Ethernet - Yes / PoE - YesAmbient Operating Temperature 0 to 40° C (32 to 104° F)Ambient Operating Humidity 5 to 95% noncondensingNDAA Compliant YesCertifications FCC, IC, CE, Electrical Safety, ULG5 Turret UltraDimensions 90 x 71.2 mm / (3.5 x 2.8")IR Night Vision 30 m (98 ft)Smart Detections (People, Vehicles, Animals) YesResolution 2KField of View H: 102.4°, V: 54.9°, D: 120.6°Audio MicrophoneWeatherproofing IP66Tamper Resistance IK04Mounting Wall, ceiling mount (Included) / Junction box, arm mount (Optional)Networking Interface 10/100 MbE RJ45 portVideoMax. Frame Rate 30 FPSResolution 4MP 2688 x 1512 (16:9)Image SettingsColor, brightness,
Ubiquiti UNVR-Instant-Kit Network Video Recorder UNVR-Instant-Kit
The Ubiquiti UNVR-Instant-Kit is a compact and efficient Network Video Recorder designed to enhance your security system. W... moreith dimensions of 220 x 220 x 47 mm and a weight of just 1.04 kg, this device provides a space-saving solution for your surveillance needs. It supports up to 15 managed cameras (with 8 HD, 6 2K, and 4K capabilities) and offers robust data protection features, ensuring your footage remains secure. Additionally, the built-in storage capacity of 1x 3.5" drive bay allows for easy expansion and maintenance.
Equipped with a quad-core ARM Cortex-A55 processor and 4 GB of memory, the UNVR-Instant-Kit ensures smooth operation and quick management capabilities via its Ethernet and Bluetooth interfaces. Its 40W PoE budget and energy-efficient design (max power consumption of 9W) make it a cost-effective choice for reliable surveillance needs. The 1.14" built-in display provides immediate access to system status and settings, while the versatile mounting options (wall or din rail) enhance installation flexibility.
Complemented by the G5 Turret Ultra camera, this kit offers exceptional performance with features such as 2K resolution, IR night vision capabilities, and various smart detection features. Certified by NDAA and other rigorous standards, the entire system is built for durability and compliance, ensuring it meets your security demands in various environments. Whether for commercial or residential use, the Ubiquiti UNVR-Instant-Kit stands out as a top-tier solution in modern surveillance technology.
...
UBIQUITI UNVR-KIT: Professional-Grade, All-in-One Video Surveillance SystemSecure your property with the UBIQUITI UNVR-KIT, a... morecomprehensive and scalable video surveillance solution designed for discerning homeowners and businesses. This powerful kit combines a high-performance network video recorder (NVR) with advanced IP cameras, all managed through the intuitive UniFi Protect ecosystem. Experience unparalleled security without the burden of monthly subscription fees. Your data remains private and secure on your local hardware, giving you complete control and peace of mind. The system is engineered for plug-and-play simplicity, allowing for rapid deployment and effortless expansion as your security needs grow. From crystal-clear daytime recording to exceptional night vision, the UNVR-KIT delivers robust, reliable, and professional-grade surveillance 24/7.Key Benefits:* Subscription-Free Security: Enjoy all the premium features of the UniFi Protect platform, including remote access and intelligent alerts, with zero monthly fees or licensing costs.* Complete Data Privacy: All video footage is stored locally on the NVR´s hard drives. Your data never leaves your premises for a third-party cloud, ensuring maximum privacy and security.* Unmatched Scalability: The system is built to grow with you. Start with the included cameras and easily add dozens more from the extensive UniFi Protect camera portfolio to cover every angle of your property.* Superior Data Protection: The UNVR features four hard drive bays with support for RAID 1 or RAID 5 configurations, providing automated data redundancy to protect your valuable recordings against hard drive failure.* Intuitive Centralized Management: Effortlessly view live feeds, review recordings, and configure your entire system from anywhere in the world using the powerful and user-friendly UniFi Protect web interface or mobile app .* High-Performance Connectivity: Equipped with a 1 GbE RJ45 port for standard network connections and a 10G SFP+ port, the UNVR is ready for high-throughput environments and seamless integration with high-speed network backbones.Main Features* (1) UniFi Network Video Recorder (UNVR)* UniFi Protect G4 or G5 Series Cameras (quantity varies by kit)* Plug-and-Play Installation* Automated RAID 1 or RAID 5 Volume Configuration* UniFi Protect Software with No Licensing Fees* Centralized, Secure Management via Web and Mobile App* High-Resolution Video Recording (2K or 4K, depending on camera models)* Advanced Motion Detection and Smart Detections * Powerful Infrared (IR) Night Vision* Weather-Resistant Camera Construction for Indoor/Outdoor Use* Power over Ethernet (PoE) for Single-Cable Camera InstallationAttributeTechnical SpecificationsUniFi Network Video Recorder (UNVR):* Processor: Quad-Core ARM Cortex-A57 at 1.7 GHz* System Memory: 4 GB DDR4* Storage: (4) 2.5/3.5 HDD Bays (HDDs not included)* Networking Interfaces: (1) 1 GbE RJ45 Port, (1) 10G SFP+ Port* Power Supply: Internal 100W
pa_mpn: 906, pa_sku: 2028, pa_ean-gtin: 2029, pa_brand: 1878 An all-in-one, compact surveillance solution by Ubiquiti that includes the UNVR-Instant video recorder, four G5 Turret Ultra cameras, and a 1TB hard drive. It provides a simple setup by bundling all components for immediate deployment, designed to deliver enterprise-class security performance for homes, small businesses, and builders without complex configuration or licensing fees. Key features All-in-one kit: Includes the UNVR-Instant recorder, four G5 Turret Ultra cameras, and a 1TB hard drive for immediate, out-of-box operation. Compact and silent: The fanless design makes it suitable for small deployments. Simplified setup: Features a one-click setup with UniFi Protect and PoE support to power and connect cameras directly to the NVR's integrated switch. Local and remote access: Manages and views recordings through the UniFi Protect app or web interface, with secure local storage. Local monitoring: Includes an HDMI ViewPort for on-site monitoring on a TV or monitor without needing an external PC. Scalable storage: The 1TB drive is expandable via a USB-C port and has a 3.5" bay for a larger drive. High-performance: Equipped with a quad-core processor and 4GB of memory, the system can handle up to six 4K cameras or fifteen Full HD cameras. Compliance: NDAA compliant and certified by FCC, IC, and CE Network Video Recorder InstantDimensions 220 x 220 x 47 mm (8.7 x 8.7 x 1.9")UniFi Application Suite Protect - Yes / Access - YesManaged Cameras (15) HD / (8) 2K / (6) 4KStorage Capacity (1) 3.5" drive bayData Protection YesVantage Point YesNetworking Interface (1) GbE RJ45 uplink port / (6) GbE PoE RJ45 downlink ports / (1) HDMI port (Viewport)Form Factor Compact DesktopMounting Wall, Din rail mount (Included)Door Access Support YesHard Drive Capacity (1) 3.5" HDD supportMax. Power Budget for Drives 11WMax. Power Consumption 9WPower Method Universal AC input, 100-240VAC, 1.5A Max, 50/60 HzPower Supply AC/DC, Internal, 60WPoE Budget 40WMax. PoE Wattage per Port by PSE PoE 15.4WVoltage Range PoE Mode 44–57VProcessor Quad-core ARM Cortex-A55 at 1.7 GHzMemory 4 GBManagement Ethernet / BluetoothDisplay 1.14" screenWeight 1.04 kg (2.3 lb)Enclosure Materials Polycarbonate Mount Material PolycarbonateLEDs Ethernet - Yes / PoE - YesAmbient Operating Temperature 0 to 40° C (32 to 104° F)Ambient Operating Humidity 5 to 95% noncondensingNDAA Compliant YesCertifications FCC, IC, CE, Electrical Safety, ULG5 Turret UltraDimensions 90 x 71.2 mm / (3.5 x 2.8")IR Night Vision 30 m (98 ft)Smart Detections (People, Vehicles, Animals) YesResolution 2KField of View H: 102.4°, V: 54.9°, D: 120.6°Audio MicrophoneWeatherproofing IP66Tamper Resistance IK04Mounting Wall, ceiling mount (Included) / Junction box, arm mount (Optional)Networking Interface 10/100 MbE RJ45 portVideoMax. Frame Rate 30 FPSResolution 4MP 2688 x 1512 (16:9)Image SettingsColor, brightness,
