Computer Cooling Koolance

Koolance (patent-pending) quick disconnect no-spill coupling with automatic shutoff. 10mm (3/8in) ID male panel-mounted hose barb with clamp for 13mm (1/2in) OD. It will only fit a Koolance QD3 female quick disconnect.After pulling the ring on the female QDC side, the quick-disconnect fittings will separate. Liquid on both sides will be automatically obstructed with approximately 0.2mL freed. Fittings are nickel-plated bras

Koolance (patent-pending) quick disconnect no-spill coupling with automatic shutoff. 10mm (3/8in). It will only fit a Koolance QD3 male shutoff valve.After pulling the ring on the female QDC side, the quick-disconnect fittings will separate. Liquid on both sides will be automatically obstructed with approximately 0.2mL freed. Fittings are nickel-plated brass. Maximum operating pressure is 2kgf/cm2 (28.5 psi) @ 25°C. Maximum operating temperature is 100°C (212°F).

Koolance's QD series of quick release closures make it easy and convenient to break the coolant circuit by simply depressing a metal ring. This is especially necessary where hoses or water cooling components often have to be disconnected from the rest of the water cooling system. The higher the designation of the QD connections, the more massive and larger they are designed and are accordingly suitable for larger hose diameters. Two QD3 nickel-plated brass quick-release couplings are connected or disconnected (once male, once female), with Koolance developing valves that, as the name no-spill suggests, are designed to provide a degree of leakage. It should be noted, however, that 100% immediate …

Koolance's QD series of quick release closures make it easy and convenient to break the coolant circuit by simply depressing a metal ring. This is especially necessary where hoses or water cooling components often have to be disconnected from the rest of the water cooling system. The higher the designation of the QD connections, the more massive and larger they are designed and are accordingly suitable for larger hose diameters. For example, consider an external radiator that you want to quickly and safely disconnect from during PC transport to transport it separately. Or a water cooling component that you change more frequently, be it out of experimentation (CPU, chipset cooler) or because …

Koolance (patent-pending) quick disconnect no-spill coupling with automatic shutoff. 10mm (3/8") ID male straight connection with compression fitting. It will only fit a Koolance QD3 female quick disconnect.After pulling the ring on the female QDC side, the quick-disconnect fittings will separate. Liquid on both sides will be automatically obstructed with approximately 0.2mL freed. Fittings are chrome-plated brass.Specification:- ID: 10mm (3/8")- OD: 13mm (1/2")- Wall: 1.5mm (1/16")

Koolance (patent-pending) quick disconnect no-spill coupling with automatic shutoff. G 1/4 BSPP threaded with panel-mount opposite a male "QD3" quick-disconnect. It will only fit a Koolance QD3 female quick disconnect.After pulling the ring on the female QDC side, the quick-disconnect fittings will separate. Liquid on both sides will be automatically obstructed with approximately 0.2mL freed. Fittings are chrome-plated brass, EPDM o-rings.Specification:- Size: 55 x 26 mm- Material: Brass, black- Maximum pressure during operation: 28.5 psi- Connections: - QD3: male - Connection: ¼ inch + Bulkhead

Koolance (patent-pending) quick disconnect no-spill coupling with automatic shutoff. 10mm (3/8") ID, 16mm (5/8") OD male straight connection with compression fitting. It will only fit a Koolance QD3 female quick disconnect.After pulling the ring on the female QDC side, the quick-disconnect fittings will separate. Liquid on both sides will be automatically obstructed with approximately 0.2mL freed. Fittings are chrome-plated brass.Intended Tubing Size:-- ID: 10mm (3/8")- OD: 16mm (5/8")- Wall: 3mm (1/8")

Koolance (patent-pending) quick disconnect no-spill coupling with automatic shutoff. 10mm (3/8") ID male straight connection with compression fitting. It will only fit a Koolance QD3 female shutoff valve.After pulling the ring on the female QDC side, the quick-disconnect fittings will separate. Liquid on both sides will be automatically obstructed with approximately 0.2mL freed. Fittings are nickel-plated brass. Maximum operating pressure is 2kgf/cm2 (28.5 psi) @ 25°C. Maximum operating temperature is 100°C (212°F).

Koolance patented quick disconnect no-spill coupling with automatic shutoff. Opposite is a panel mountable female G 1/4 BSPP thread for attaching a fitting or barb. The disconnect side will only fit a Koolance QD3 male quick disconnect.After pulling the ring on the female QDC side, the quick-disconnect fittings will separate. Liquid on both sides will be automatically obstructed with approximately 0.2ml freed. Coolant volume lost upon disconnection will rise with internal pressure higher than 0.5kgf/cm2 (7psi).Specification:- Weight: 0.17 lb (0.08 kg)- Fitting Thread: G 1/4 BSPP- Materials: Brass, Nickel Plating, Stainless Steel, EPDM- Max Pressure @ 25°C: 8kgf/cm2 (113.8psi)- Max Temperature: 1…

Koolance (patent-pending) quick disconnect no-spill coupling with automatic shutoff. G 1/4 BSPP threaded female fitting for screwing directly into a water block or other component. It will only fit a Koolance QD3 male quick disconnect.After pulling the ring on the female QDC side, the quick-disconnect fittings will separate. Liquid on both sides will be automatically obstructed with approximately 0.2mL freed. Fittings are chrome-plated brass. Maximum operating pressure is 2kgf/cm2 (28.5 psi) @ 25°C. Maximum operating temperature is 100°C (212°F).

Koolance (patent-pending) quick disconnect no-spill coupling with automatic shutoff. 10mm (3/8") ID, 16mm (5/8") OD female straight connection with compression fitting. It will only fit a Koolance QD3 male shutoff valve.After pulling the ring on the female QDC side, the quick-disconnect fittings will separate. Liquid on both sides will be automatically obstructed with approximately 0.2mL freed. Fittings are nickel-plated brass. Maximum operating pressure is 2kgf/cm2 (28.5 psi) @ 25°C. Maximum operating temperature is 100°C (212°F).Specification:- ID: 10mm (3/8")- OD: 16mm (5/8")- Wall: 3mm (1/8")

Koolance (patent-pending) quick disconnect no-spill coupling with automatic shutoff. 10mm (3/8") ID, 16mm (5/8") OD female straight connection with compression fitting. It will only fit a Koolance QD3 male shutoff valve.After pulling the ring on the female QDC side, the quick-disconnect fittings will separate. Liquid on both sides will be automatically obstructed with approximately 0.2mL freed. Fittings are nickel-plated brass. Maximum operating pressure is 2kgf/cm2 (28.5 psi) @ 25°C. Maximum operating temperature is 100°C (212°F).Specification:- ID: 10mm (3/8")- OD: 16mm (5/8")- Wall: 3mm (1/8")

Koolance (patent-pending) quick disconnect no-spill coupling with automatic shutoff. 10mm (3/8") ID female straight connection with compression fitting. It will only fit a Koolance QD3 male quick disconnect.After pulling the ring on the female QDC side, the quick-disconnect fittings will separate. Liquid on both sides will be automatically obstructed with approximately 0.2mL freed. Fittings are chrome-plated brass. Maximum operating pressure is 2kgf/cm2 (28.5 psi) @ 25°C. Maximum operating temperature is 100°C (212°F).Specification:- ID: 10mm (3/8")- OD: 13mm (1/2")- Wall: 1.5mm (1/16"
