Other Hand Tools KNIPEX

The TwinKey® Service Cabinet Key for the actuation of locking systems from the areas of facilities engineering (heating and sanitation, air conditioning, electro technology), gas and water supply and shut-off-systems. Consists of two 4-way spider keys connected using magnets providing space saving storage. It has the following functions: 4 x Square: 5, 6-7, 8-9 and 10-11mm.3 x Triangular: 7-8, 9-10 and 11-12mm.1 x Two-Way: 3-5mm.1 x Half-moon: 6mm.1 x Long Execution Conical Square: 6, 7, 8 and 9mm.1 x Double Ended Bit (Slotted 1.0x7mm and PH2). Features: 10 Functions: 4 x square, 3 x triangular, 2-way (3-5mm), half-moon and conical square Made from zinc die-cast metal Suitable for technical …

Professional Quality tested to 10 000V and insulated to 1000V AC and 1500V DC for live line working. Manufactured from special tool steel oil hardened and tempered. Smoothly ground chrome plated heads with cutting edges separately induction hardened to 64HRC for cutting hard and piano wire. Heavy two colour insulated handles with slip guards for extra comfort and safety.PTDDRPDIR49168

Professional Quality forged from chrome vanadium electric steel with inserted cold drawn highly condensed spring steel tips for exceptional longevity and precision. These pliers are internally sprung within the precision screw joint.PTDDRPDIR75088

78 03 125 SB Electronic Super Knips®Precision pliers for ultra fine cutting work, e. g. in electronics and fine mechanics. Ground, very sharp cutting edges without bevel. Precisely shaped tips cut wires close to a surface from Ø 0.2 mm. Shear cut with controlled micro cutting edge misalignment for the most precise cutting of even the thinnest of wires and for a long service life. Joint with stainless steel rivet. Extremely smooth movement for minimum operator fatigue. With opening spring and opening limiter. cutting edge hardness approx. 54 HRC. INOX tool steel. self-service card/blister. Cutting capacities medium hard wire (diameter): Ø 1.0 mmCutting capacities soft wire (diameter): Ø 0.2 – …

78 61 125 ESDSB Electronic Super Knips® ESDPrecision pliers for ultra fine cutting work, e. g. in electronics and fine mechanics. Electrically discharging handles - dissipative. Ground, very sharp cutting edges without bevel. Shear cut with controlled micro cutting edge misalignment for the most precise cutting of even the thinnest of wires and for a long service life. Precisely shaped tips cut wires close to a surface from Ø 0.2 mm. Joint with stainless steel rivet. Extremely smooth movement for minimum operator fatigue. With opening spring and opening limiter. cutting edges additionally induction-hardened, cutting edge hardness approx. 64 HRC. special tool steel, burnished. cutting edges ad…

78 61 140 ESDSB Electronic Super Knips® XL ESDAdditional 15 mm longer version: greater stability, greater cutting performance. Precision-ground cutting edges without bevel for precise and flush cutting of the finest wires, e.g. in electronics and fine mechanics. Precisely shaped tips cut wires close to a surface from Ø 0.2 mm. With opening spring and opening limiter for comfortable, ergonomic and fast working thanks to automatic opening and comfortable handle width. Extremely easy movement for fatigue-free work due to precise joint with stainless steel rivet. High load capacity, made of burnished special tool steel, cutting edges additionally induction-hardened to 64 HRC. self-service card/blister. C…

8 61 Series Electronic Super Knips® with 2 component, soft-grip handles for ultra fine cutting work, e. g. in electronics and fine mechanics. Also suitable for cutting fibre optic cable. Ground, very sharp cutting edges without bevel. The cutting edges have been additionally induction-hardened, approx. 62 HRC. Its precisely shaped tips cut wires close to a surface from Ø 0.2mm. Cutting Capacity (mm): Medium: 1.0, Soft: 0.2-1.6 Features: Smooth, play-free joint with a stainless steel rivet Precision-ground cutting edges, without bevel Low friction double spring for gentle closing and opening Suitable for cutting glass fibre cables (fibre optics) Specifications: Dimensions: H:1.7 x …

78 Series XL Electronic Super Knips® with ground, very sharp cutting edges without bevel. Precision shaped tips cut wires resting on a board from Ø0.2mm. Shear cut with controlled micro cutting edge misalignment for the most precise cutting of even the thinnest of wires and for a long service life. The joint features a stainless steel rivet with extremely smooth movement for minimum operator fatigue. Fitted with multi-component grips, an opening spring and opening limiter. 78 03 140: INOX tool steel, Cutting Edge: approx. 54 HRC78 61 140: Special tool steel, oil hardened in multiple stages. Cutting Edge: approx. 64 HRC Features: Smooth, play-free joint with a stainless steel rivet …

90 20 Series cutter for cutting thin walled plastic pipes (e.g. aluminium armoured plastic pipes), flexible plastic and rubber hoses up to 25mm diameter. Made from tough fibreglass reinforced plastic. The blade is made of high-strength special grade steel, oil-hardened and tempered. Has an opening spring and locking lever. Exchangeable blade. Not suitable for cutting steel. Cutting Capacity: 25mm Features: For thin walled plastic pipes, flexible plastic and rubber hoses up to 25mm O.D Oil-hardened and tempered, special grade steel blade Opening spring and locking lever Lightweight, made from tough fibreglass reinforced plastic Specifications: Dimensions: H:2.5 x W:8.5 x D:25.0 cm Weight: 1.1 …

The BiX® Clever Pipe Cutter cuts pipes quickly, cleanly and without shavings. Fits comfortably in the hand with a locking mechanism for safe transport. Cuts high-temperature plastic drain pipes and electrical conduits in next to no time. Can be used to cut sealing sleeves during final assembly, close to the wall, standard-compliant. Fitted with a rotatable knife block for cutting plastic pipes (blade in the middle) and sealing sleeves (blade outside). Two spare blades integrated in the tool. Capacity: HT & Plastic Pipes: Ø 20-50mm, Sealing Sleeves: Ø 20-50mm Features: Cuts pipes quickly, cleanly and without shavings Fits comfortably in the hand Locking mechanism for safe transport …

90 22 10 E01 Spare blades for 90 22 10 BK

The DP50 Plastic Pipe Cutter will cut and chamfer all common domestic plastic drain pipes up to Ø 50mm, in a single operation. Its reversible high-quality ball-bearing steel blade, can be easily replaced without tools. Provides a clean cut, no readjusting or deburring required, reducing potential blockages or damages of the seals. The blade is spring loaded, no inconvenient readjusting while cutting. Its durable housing is made of glass fibre reinforced plastic. Supplied with an exchangeable blade, with two cutting edges, so it can be reversed when showing signs of wear. High Temperature & Plastic Pipes: Ø 32, 40 or 50mmMax. Wall Thicknesses: 2.4mmMin. Length of Pipe: 10mm Features: …

90 25 185 SB Pipe cutter for plastic composite pipesFor cutting composite pipes from Ø 12 - 25 mm. Clean, smooth and burr-free cut surfaces. easily exchangeable blade. With opening spring and locking device. Ergonomically shaped handles made of fibreglass-reinforced plastic. Not suitable for cutting cables. self-service card/blister. Cutting capacities (diameter): Ø 12 – 25 mm

This Pipe Cutter cuts aluminium composite and plastic conduit pipes more easily than conventional shears with a fixed blade. Also suitable for composite pipes with increased aluminium layer thickness (e.g. Geberit Mepla). Wide plastic supports allow perfect right-angled cuts. Up to 60% less effort required when cutting. The freely rotating cutting wheel allows the pipe to be rotated with minimal friction when cutting. Optimum cutting results. The rotation allows the cutting wheel to penetrate the pipe effortlessly with minimal deformation. Fitted with ergonomic, multi-component handles for added comfort. There is also a locking mechanism for safe transport. Cutting Capacity: Plastic & Composite …

90 31 02 SB KNIPEX TubiX® Pipe cutterQuickLock one-hand locking mechanism: independent holding and clamping on the tube. Easy one-handed pushing for quick adjustment to different tube sizes. Comfortable: easy cutting due to high-quality needle bearings in the cutting wheel and guide rolls. Cuts pipes from Ø 6 - 35 mm (1/4" - 1 3/8") with wall thickness up to 2 mm. Cutting wheel made of high-grade ball-bearing steel. Practical quick replace system for the cutting wheel – with spare wheel stored under the feeding barrel. With precision-ground deburring tool, easy to remove. For the electric trade: Also suitable to cut rigid steel conduits. self-service card/blister. Cutting capacities (diameter): Ø 6 …

90 39 02 V03 5 x Spare cutting wheel INOX Cu for KNIPEX TubiX® 90 31 02Spare part.

Anvil Shears with opening spring and locking device. For cutting soft materials without damage, e.g. rubber profiles, PVC, leather, wood, hoses etc. Blade Length: 40mmCutting Capacity:Round Material up to Ø 25mmFlat Material max. width of 40mm and height of 7.5mmOverall Length: 200mm Features: For cutting soft materials without damage, e.g. rubber profiles, PVC, leather, wood, hoses etc Opening spring and locking device PLastic coated handles Specifications: Dimensions: H:2.2 x W:7.5 x D:20.0 cm Weight: 0.3 kg Colour: Multi Guarantee:24 Month Material: Pvc; Steel Model Number: KPX9455200

95 05 140 Combination ShearsFor cutting cardboard, plastics, aluminium, brass and copper foils. Not suitable for steel wire or iron sheets. Precision-ground, hardened blades. With opening spring and locking device. Pinch guard prevents operators' fingers being pinched. Adjustable bolted joint.

95 05 190 SB Combination ShearsFor cutting cardboard, plastics, aluminium, brass and copper foils. Not suitable for steel wire or iron sheets. Precision-ground, hardened blades. With opening spring and locking device. Pinch guard prevents operators' fingers being pinched. Adjustable bolted joint.

These Electrician's Shears have precisely ground blades with fine serration for a clean, non-slip cut. The cutting edges are made from stainless steel, hardness of 56 HRC, and feature an integrated cable cutter. The handles are fitted with multi-component grips, which are fibreglass-reinforced. Supplied with a plastic belt case. Model 95 05 155 has a crimp area for end sleeves (ferrules) up to 6.0mm² Features: Cuts wire Cutting edges made from stainless steel, 56 HRC Multi-component grips, fibreglass-reinforced Integrated cable cutter Crimp area for end sleeves (ferrules) up to 6.0mm² Specifications: Dimensions: H:3.2 x W:13.0 x D:19.0 cm Weight: 0.1 kg Colour: Multi Guarantee:24 Month …

95 05 155 SB Electricians' Shearsprecisely ground blades with fine serration for a clean, non-slip cut. cutting edge with integrated cable cutter. with plastic belt pouch. Handles with multi-component grips, fibreglass-reinforced. Universal shears for electricians. Cutting edges made from stainless steel, hardness of cutting edges 56 HRC. self-service card/blister.

95 05 185 Combination ShearsFor cutting cardboard, plastics, aluminium, brass and copper foils. Not suitable for steel wire or iron sheets. Precision-ground, hardened blades. With opening spring and locking device. Pinch guard prevents operators' fingers being pinched. Adjustable bolted joint. angled shape - for easy execution of long cuttings. ergonomically shaped plastic handles.

95 62 160 SB Wire Rope CutterFor high-strength wire ropes up to Ø 4 mm and cables up to Ø 6 mm: noticeably light, high-precision cutting thanks to unique, patent-pending joint design. Compact size, low weight, high performance level. Made for intensive use: particularly durable and light at only 172 g. Compact, light and powerful. Up to 30 % less physical effort compared to wire rope cutters of the same length. Double-mounted box joint design for high level of stability. Cutting edges additionally induction-hardened, cutting edge hardness approx. 64 HRC. Convenient work thanks to opening spring. Secured by locking device during transport. For wire rope with Ø 4.00 / 1960 Nmm². self-service card…

99 01 220 SB Concreters' NipperTo twist and cut wire in one operation: fast, reliable and economical. Cutting edges additionally hardened; cutting edge hardness approx. 61 HRC. self-service card/blister. Cutting capacities medium hard wire (diameter): Ø 2.4 mmCutting capacities hard wire (diameter): Ø 1.6 mm
