| Key Features.1280 x 1024 resolution with 12 μm, 50 Hz thermal detector.High-sensitivity thermal module NETD < 15 mK (at 25 °C, F = 1.0).60 mm, F1.0 lens with thermal detection range up to 3100 m.Ultra-high-resolution 3840 x 2160 4K digital camera, 60 mm, F2.2.0.49-inch OLED display with 1920 x 1080 resolution.Replaceable 850 nm IR emitter and 1000 m laser rangefinder.Over 5.5 hours of continuous operation with replaceable battery.Lightweight at 1050 g, with a compact and ergonomic design.Technical Specifications.Thermal Module.Image Sensor:Focal Plane Array VOx No Cooled.Maximum Resolution:1280 x 1024.Frame Rate:25 Hz.Pixel Spacing:12 μm.Response Waveband:8 μm to 14 μm.NETD:< 15 mK (25°C), F=1.0.Lens (Focal Length):60 mm, F1.0.Focus Mode:Focus Ring.Detection Range:3100 meters.Minimum Focusing Distance:3 meters.Magnification:2.6x - 20.0x (7.7x).Field of View (H x V), Degrees:14.6° x 8.8° / Meters:100 m:25.6 m x 15.4 m.Optical Module.Image Sensor:1.88? Progressive Scan CMOS.Resolution Maximum resolution:3840 x 2160.Lens (focal length):60 mm, F2.2.Focus mode:Focus ring.Magnification:5.5x - 22.0x (4x).Field of view (H x V), Degrees:7.3° x 4.1° / Meters:100 m:12.6 m x 7.2 m.Smart IR:Yes.IR Illuminator wavelength:850 nm.Night vision range:400 meters.Replaceable IR Illuminator:Yes.Image display.Screen:0.49-inch, OLED, 1920 x 1080.Palettes:THERMAL:Hot Black, Hot White, Hot Red, Fusion, Green | OPTICAL:Day, Night, Auto.FFC (Flat Field Correction) Mode:Auto, Manual, External Correction.Exit Pupil:8 mm.Eye Relief:15 mm.Diopters (Range):-5D ~ +3D.Brightness Adjustment:Yes.Tone Adjustment:Cool, Warm.Contrast Adjustment:Yes.Zoom Pro:Yes.Picture Pro 2.0:Yes.System.Record Video:Yes.Capture Snapshots:Yes.Record Audio:Yes.Standby Mode:Yes.Storage:Built-in eMMC (64 GB).PIP:Yes.Hotspot:Yes.Hot Track:Yes.Digital Magnetic Compass:Yes.GPS:Yes.Local Album:Yes.Power Supply.Battery Type:Replaceable and Rechargeable Li-ion Battery Pack.Battery Operating Time:?5.5h (35°C, with Hot Track disabled, LRF and Imaging Pro 2.0 enabled).Type C power supply:5V DC, 2A or 9V DC, 3A.Supports external power supply.… | |
