Drills & Screwdrivers Rotabroach

The ‘Rhino E’ is Rotabroach’s Electric offering for rail drilling applications. With a powerful 1100 watt motor this gives the advantage of faster drilling and less wear to your cutters than other machines on the market. This machine is a 240v model for use with standard mains power sockets. Specifications • Model Number: CM/127/1 / CM/127/3 • Motor Specification: 110V 1100W / 230V 1100W • No Load RPM: 270 – 610 RPM • Max Hole Cutting Capacity: 40mm (diameter) • Height: 320mm • Width: 180mm (with Capstan) • Length: 640mm • Machine Weight: 16.2kg • Safety Features: Mechanical Clutch / Electronic Overload Features and Benefits • Designed specific…

The ‘Rhino E’ is Rotabroach’s Electric offering for rail drilling applications. With a powerful 1100 watt motor this gives the advantage of faster drilling and less wear to your cutters than other machines on the market. This machine is a 110v model. Specifications • Model Number: CM/127/1 / CM/127/3 • Motor Specification: 110V 1100W / 230V 1100W • No Load RPM: 270 – 610 RPM • Max Hole Cutting Capacity: 40mm (diameter) • Height: 320mm • Width: 180mm (with Capstan) • Length: 640mm • Machine Weight: 16.2kg • Safety Features: Mechanical Clutch / Electronic Overload Features and Benefits • Designed specifically for rail drilling applications • 1…

Rotabroach is the original name in annular cutting technology with over 40 years of experience providing solutions for your cutting needs. The Rhino 4 is the leading Rotabroach offering for rail drilling applications. It is powered by a 4 stroke petrol engine that gives the advantage of faster drilling and the mobility of cordless freedom. The Rhino 4 offers low noise, low hand/arm vibration and better fuel efficiency than competing models. Specifications • Model Number: RD074 • Motor Specification: Honda 4 stroke, 1400W • Displacement: 57.0 cm³ • No Load RPM: 320 RPM • Max Hole Cutting Capacity: ø40mm • Overall Dimensions: Height: 420mm / Width: 420mm with Capstan / …

Suitable for drilling holes up to 52mm diameter by 50mm depth, the Raven is a lightweight and highly portable magnetic drilling machine which which is designed for use on pnemuatic supplies in non corrosive attmospheres. Specifications • Model Number: CM/330/C • Motor Specification: 13 lts/sec – 28CFM @ 5.5 bar min – 6.9 bar max • No Load RPM: 270 RPM • Max Hole Cutting Capacity: ø52 x 50mm deep • Drill Chuck Capacity: ø16mm • Overall Dimensions: Height 525mm / Width 165mm / Length 315mm • Machine Weight: 16.3kg • Magnetic Adhesion: 7,000N • Magnet Size: 175mm x 75mm • Safety Features: Fixed Guard

Designed for heavy duty operations, the Element 75 is nonetheless a compact and portable machine when compared to other mag drills in its class. A dual motor protection helps to ensure a long operational life and protects against excessive wear, while the intuitive control panel means that even inexperienced mag drill operators will be able to maintain optimum working conditions while using the tool. The Element 75 has two gears and forward / reverse functionality, along with an integrated coolant supply system. Features & Benefits • Suitable for drilling up to 75mm diameter holes to a depth of 75mm • Left- or right-hand rotation • Smaller and more portable than other machines …

One of the most versatile Rotabroach mag drills available, the Element 50 is a compact machine which is available in either 110v or 240v. Suitable for drilling up to 50mm diameter by 50mm depth, the direction of the rotation can be reversed which also makes the Element 50 suitable for tapping applications. A dual motor protection system helps to prolong the lifetime of the tool, which also benefits from a mechanical clutch, two gears, an intuitive control panel and an integrated coolant supply system. Features & Benefits • One of the most versatile Rotabroach mag drills available • Left/right hand rotation - can be used for tapping • Powerful 1500W motor • Variable speed …

The Rotabroach Element 50 Low Profile Mag Drill has a reduced height and a powerful motor. With a 50mm cutting capacity, it is perfect for confined spaces and everyday drilling requirements. Features & Benefits • Largest capacity low profile magdrill on the market • Cutting diameter and depth of cut to 50mm • 1200W motor with variable, 6 speed setting • Cutsmart contorl pane • Countersink to 30mm (with RD32059 extension arbor) Specifications • Voltage: 110v • Model Number: Element 50 Low Profile 1 / Element 50 Low Profile 3 • Motor Specification: 110V/1200W / 230V/1200W • No Load RPM Range: 250-500RPM • Max Hole Cutting Capacity: ?50 x 50mm Deep …

Suitable for drilling holes up to 40mm in diameter by 50mm depth, the Element 40 has a powerful, two speed mechanical gearbox. It is small in size but suitable for use in the harshest of environments. Features & Benefits • Powerful 1200w motor • High performance two-speed gearbox • Quick release capstan arm • Includes 13mm drill chuck for use with standard drill bits • 10,000N High powered magnet • Mounted coolant bottle • Internal motor cable • Lightweight at 13.65kg • Ergonomic carry handle • User friendly controls Specifications • Voltage: 240v • Model Number: Element 40/1 / Element 40/3 • Motor Specification: 110v 1200w / 230v …

ALL-ROUND PERFORMANCE : 1200w Motor Power, 50mm cutter capacity, 12 speeds, a 50mm maximum depth of cut, 13mm twist drill capacity, Height 33cm and weighting at 11kg
ENHANCED SAFETY : The Element 50 low profile bench mag drill incorporate a dual motor protection system (prolonging the machine’s life and preventing unwanted wear) alongside an internal cooling system. It also features electronic overload protection, a fixed guard and mechanical clutch. The drill stand magnetic hole driller also utilises Rotabroach’s innovative CutSmart technology to minimalise wear on both the motor and cutter, prolonging overall tool life. Internal cabling removed the risk of damage and downtime for your magd…

One of the lightest mag drills on the market at just over 10kg, the Element 30 is a compact machine which comes packed with an accessory kit in a robust carry case for easy transport and storage. Suitable for hole cutting up to 32mm in diameter and 35mm in depth, the Element 30 can be used with both annular cutters and standard drill bits, thanks to the inclusion of a 13mm keyed chuck and adaptor. An intuitive Rotabroach CutSmart control panel ensures user friendly operation and alerts the operator if the load risks damaging the machine: an illuminated green, amber and red display acts as a guide while drilling, enabling even inexperienced users to easily maintain the correct pressure, helping …

One of the lightest mag drills on the market at just over 10kg, the Element 30 is a compact machine which comes packed with an accessory kit in a robust carry case for easy transport and storage. Suitable for hole cutting up to 32mm in diameter and 35mm in depth, the Element 30 can be used with both annular cutters and standard drill bits, thanks to the inclusion of a 13mm keyed chuck and adaptor. An intuitive Rotabroach CutSmart control panel ensures user friendly operation and alerts the operator if the load risks damaging the machine: an illuminated green, amber and red display acts as a guide while drilling, enabling even inexperienced users to easily maintain the correct pressure, helping …

Rotabroach's largest machine with large drilling diameter and cutting depths, the Element 100 is suitable for drilling up to 100mm diameter by 100mm depth and offers forward & reverse functionality for tapping. A dual motor protection system helps to ensure a long operational lifetime and protects the machine from excessive wear. Features & Benefits • Rotabroach’s largest machine • Suitable for drilling large diameter holes to deep depths • Forward & reverse functionality for drilling & tapping • Dual motor protection system for longer life • Four speed high performance gearbox • Powerful 2000W motor • Cutsmart - primary motor protection • Variable speed - …
