Buy TP-LINK Omada Media conv. 1000BASE-SX/LX/LH MC220L
When you make a purchase through links on our site, we may receive a affiliate commission.
TP-Link Omada Media conv. 1000BASE-SX/LX/LH MC220L
- Complies with IEEE 802.3ab and IEEE 802.3z
- FX port supports hot-swappable
- Extends fiber distance up to 0.55km for mul... moreti-mode fiber and 10km for single-mode fiber
The MC220L is a media converter designed to convert 1000BASE-SX/LX/LH fiber to 1000Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-SX/LX/LH standards the MC220L is designed for use with multi-mode/single-mode fiber cable utilizing the SC-Type connector. The MC220L supports shortwave (SX) laser specification at a full wire speed forwarding rate. It works at 850nm on both transmitting and receiving data when adopting multi-mode fiber and 1310nm on both transmitting and receiving data when adopting single-mode.
Other features of this module include the ability to be used as a stand alone device (no chassis required) or with TP-LINKs 19system chassis Auto MDI/MDI-X for TX port and front panel status LEDs. The MC220L will transmit at extended fiber optic distances utilizing multi-mode fiber up to 0.55 kilometers and 10 kilometers when utilizing single-mode fiber.
TP-LINK MC220L - Fibre media converter
TP-LINK MC220L
The MC220L... moreis a media converter designed to convert 1000Base-SX/LX/LH fiber to 1000Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-SX/LX/LH standards, the MC220L is designed for use with multi-mode/single-mode fiber cable utilizing the SC/LC-Type connector. It works at 850nm on both transmitting and receiving data when adopting multi-mode fiber and 1310nm on both transmitting and receiving data when adopting single-mode.
Other features of this module include the ability to be used as a standalone device (no chassis required) or with TP-Link's 19"system chassis, Auto MDI/MDI-X for TX port, and front panel status LEDs. The MC220L will transmit at extended fiber optic distances utilizing multi-mode fiber up to 0.55 kilometers and 10 kilometers when utilizing single-mode fiber.
Additional Product Notes
- Works at 1000Mbps in full-duplex mode for both TX port and FX port
- Supports auto MID/MID-X for TX port
- Link fault pass through and far end fault minimize the loss caused by link failure timely
- Provides switch configuration of force /auto transfer mode for FX port
- FX port support hot-swappable
- Extends fiber distance up to 0.55km for multi-mode fiber and 10km for single-mode fiber
- Easy-to-view LED indicators provide status to monitor network activity easily
- External power supply
- Complies with IEEE 802.3ab and IEEE 802.3z ...
The MC220L serves as a media converter with the purpose of converting fiber connections (1000BASE-SX/LX) to copper media (10/... more100/1000Base-T) and vice versa. It adheres to the IEEE802.3ab 1000 Base-T standards, enabling seamless communication with any TP-Link standard gigabit SFP fiber module*.
TP-Link MC220L Gigabit Ethernet Media Converter LC Multi/Single-mode
TP-Link MC220L Gigabit SFP Media Converter The MC220L is a media converter designed to convert 1000BASE-SX/LX/LH fiber to 10... more00Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-SX/LX/LH standards the MC220L is designed for use with multi-mode/single-mode fiber cable utilizing the SC/LC-Type connector. It works at 850nm on both transmitting and receiving data when adopting multi-mode fiber and 1310nm on both transmitting and receiving data when adopting single-mode.Other features of this module include the ability to be used as a stand alone device (no chassis required) or with TP-LINK´s 19´´;system chassis Auto MDI/MDI-X for TX port and front panel status LEDs. The MC220L will transmit at extended fiber optic distances utilizing multi-mode fiber up to 0.55 kilometers and 10 kilometers when utilizing single-mode fiber. Features . Works at 1000Mbps in Full-Duplex mode for both TX port and FX port Supports auto MDI/MDIX for TX port Provides switch configuration of Force /Auto transfer mode for FX port FX port support hot-swappable Extends fiber distance up to 0.55km for multi-mode fiber and 10km for single-mode fiber Easy-to-view LED indicators provide status to monitor network activity easily External power supply. .
TP-Link MC220L Gigabit Ethernet Media Converter LC Multi/Single-mode Black MC220L
TP-Link MC220L Gigabit SFP Media Converter The MC220L is a media converter designed to convert 1000BASE-SX/LX/LH fiber to 10... more00Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-SX/LX/LH standards the MC220L is designed for use with multi-mode/single-mode fiber cable utilizing the SC/LC-Type connector. It works at 850nm on both transmitting and receiving data when adopting multi-mode fiber and 1310nm on both transmitting and receiving data when adopting single-mode.Other features of this module include the ability to be used as a stand alone device (no chassis required) or with TP-LINK´s 19´´;system chassis Auto MDI/MDI-X for TX port and front panel status LEDs. The MC220L will transmit at extended fiber optic distances utilizing multi-mode fiber up to 0.55 kilometers and 10 kilometers when utilizing single-mode fiber. Features . Works at 1000Mbps in Full-Duplex mode for both TX port and FX port Supports auto MDI/MDIX for TX port Provides switch configuration of Force /Auto transfer mode for FX port FX port support hot-swappable Extends fiber distance up to 0.55km for multi-mode fiber and 10km for single-mode fiber Easy-to-view LED indicators provide status to monitor network activity easily External power supply. .
TP-Link Gigabit SFP Media Converter Complies with IEEE 802.3ab and IEEE 802.3z FX Port Supports Hot-Swappable (MC220L) Full-
TP-Link Gigabit SFP Media Converter Complies with IEEE 802.3ab and IEEE 802.3z FX Port Supports Hot-Swappable (MC220L) Full-D... moreuplex modeDESCRIPCIÓN DEL PRODUCTO El conversor TP-Link 1000 Mbit/s es de alta calidad que garantiza una transmisión de datos rápida y fiable. Este dispositivo cumple con los estándares IEEE802.3ab e IEEE802.3z lo que significa que es compatible con una amplia gama de dispositivos de red. Además el puerto FX admite Hot-Swap lo que lo hace fácil de instalar y usar. La distancia de transmisión de fibra óptica puede alcanzar hasta 055 km para fibra multimodo y 10 km para fibra única lo que lo hace ideal para su uso en entornos comerciales e industriales. El producto está disponible en negro y tiene dimensiones de 2.87 pulgadas de ancho 3.72 pulgadas de largo y 1.06 pulgadas de alto. El paquete incluye el convertidor MC220L y nada más.
TP-Link MC220L V3 Gigabit SFP Media Converter MC220L
Complies with IEEE 802.3ab and IEEE 802.3z FX port supports hot-swappable Extends fiber distance up to 0.55km for multi-mode... morefiber and 10km for...
The MC220L is a media converter designed to convert 1000BASE-SX/LX fiber to 10/100/1000Base-T copper media or vice versa. Des... moreigned under IEEE802.3ab 1000Base-T standards. the MC220L communicates with any TP-Link standard gigabit SFP fiber module*.* TP-Link does not maintain a third party SFP module compatibility list and does not guarantee all SFP modules work with this product. TP-Link Omada Media conv. 1000BASE-SX/LX/LH
- Complies with IEEE 802.3ab and IEEE 802.3z
- FX port supports hot-swappable
- Extends fiber distance up to 0.55km for multi-mode fiber and 10km for single-mode fiber
The MC220L is a media converter designed to convert 1000BASE-SX/LX/LH fiber to 1000Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-SX/LX/LH standards the MC220L is designed for use with multi-mode/single-mode fiber cable utilizing the SC-Type connector. The MC220L supports shortwave (SX) laser specification at a full wire speed forwarding rate. It works at 850nm on both transmitting and receiving data when adopting multi-mode fiber and 1310nm on both transmitting and receiving data when adopting single-mode.
Other features of this module include the ability to be used as a stand alone device (no chassis required) or with TP-LINKs 19system chassis Auto MDI/MDI-X for TX port and front panel status LEDs. The MC220L will transmit at extended fiber optic distances utilizing multi-mode fiber up to 0.55 kilometers and 10 kilometers when utilizing single-mode fiber.
The product description is generated based on data from online stores. Before purchasing be sure to verify all information directly with the seller.
