ASRock B650D4U-2L2T/BCM AMD B650 Express Socket AM5 micro ATX
 |
 |
Close
Buy ASRock B650D4U-2L2T/BCM AMD B650 Express Socket AM5 micro ATX
When you make a purchase through links on our site, we may earn an affiliate commission.
| £519.98 |  | ||||
ASRock ASRock B650D4U-2L2T/BCM | £519.98 |  | |||
Asrock B650D4U-2L2T/BCM motherboard AMD B650 Express Socket AM5 micro ATX | £528.62 |  | |||
AccessoriesAll accessories for ASRock B650D4U-2L2T/BCM motherboard AMD B650 Express Socket AM5 micro ATX →
B650D4U-2L2T/BCM
- Micro-ATX (9.6"x 9.6")
- Support AMD Ryzen 7000 series Processors
- 4 DIMM slots (2DPC) supports DDR5 ECC/non-ECC UDIMM
- 1 PCIe5.0 x16 1 PCIe5.0 x4 1 PCIe4.0 x1
- Supports 1 M.2 (PCIe5.0 x4)
- 2 RJ45 (10GbE) by Broadcom BCM57416
- 2 RJ45 (1GbE) by Intel® i210
- 4 SATA 6Gb/s
- 1 HDMI 1 DisplayPort
- Remote management (IPMI)
System BIOS
BIOS Type: AMI UEFI BIOS; 256Mb (32MB) SPI Flash ROM
BIOS Features: Plug and Play ACPI 6.4 compliance wake up events SMBIOS 3.5
Hardware Monitor Temperature: CPU DDR MB Card Side Chipset 10G LAN M.2 slot Fan: Fan Tachometer Multi-Speed Control CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature) Voltage: VOLT_3VSB VOLT_5VSB VOLT_P0_VCORE VOLT_P0_VSOC VOLT _VMEM VOLT _VMISC VOLT_1.8V_PT21 VOLT_VSUS10 VOLT_VDD10 VOLT_V10_PHY_DIG VOLT_VDD_1P8 VOLT_MD_VDDO VOLT_BAT VOLT_3V VOLT_5V VOLT_12V
Environment
Temperature: Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C Humidity: Non operation humidity: 20% ~ 90% ( Non condensing)
- Micro-ATX (9.6"x 9.6")
- Support AMD Ryzen 7000 series Processors
- 4 DIMM slots (2DPC) supports DDR5 ECC/non-ECC UDIMM
- 1 PCIe5.0 x16 1 PCIe5.0 x4 1 PCIe4.0 x1
- Supports 1 M.2 (PCIe5.0 x4)
- 2 RJ45 (10GbE) by Broadcom BCM57416
- 2 RJ45 (1GbE) by Intel® i210
- 4 SATA 6Gb/s
- 1 HDMI 1 DisplayPort
- Remote management (IPMI)
System BIOS
BIOS Type: AMI UEFI BIOS; 256Mb (32MB) SPI Flash ROM
BIOS Features: Plug and Play ACPI 6.4 compliance wake up events SMBIOS 3.5
Hardware Monitor Temperature: CPU DDR MB Card Side Chipset 10G LAN M.2 slot Fan: Fan Tachometer Multi-Speed Control CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature) Voltage: VOLT_3VSB VOLT_5VSB VOLT_P0_VCORE VOLT_P0_VSOC VOLT _VMEM VOLT _VMISC VOLT_1.8V_PT21 VOLT_VSUS10 VOLT_VDD10 VOLT_V10_PHY_DIG VOLT_VDD_1P8 VOLT_MD_VDDO VOLT_BAT VOLT_3V VOLT_5V VOLT_12V
Environment
Temperature: Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C Humidity: Non operation humidity: 20% ~ 90% ( Non condensing)
Product description is based on database from online stores. Be sure to verify all information directly with seller before purchasing.
