Circuit Breakers

Schneider Electric DPN Vigi comb rail L1+N, diameter 16mm², length 220mm, rated continuous current Iu 80A, suitable for devices with zero yellow, for the purpose of series(s) v/DPNa/N/Vigi, electrical more→connection design pin, 1 phase, suitable for number of devices 12, combination with ground fault circuit interrupter, 2 poles.

This iC40N circuit breaker from Schneider Electric's Acti 9 iC40 series has a rated measuring current of 16A, a rated measuring voltage of 230V and a rated breaking capacity of 10kA (EN/IEC 60947-2) a more→nd. In addition, the installation circuit breaker has tripping characteristic B. The installation circuit breaker features VisiTrip, a visible fault indicator that allows you to see at a glance when action or maintenance is required. Also, the circuit breaker has VisiSafe, which provides reinforced insulation for safely performing maintenance.

The siemens circuit breaker provides voltage of 230v with 1+n-pole/1mw configuration. In the event of an overload or short-circuit, circuit breakers safely cut off the connected circuit and reliably p more→rotect electrical installations and equipment from damage. The siemens miniature circuit breaker is the fuse for short-circuit protection. Siemens offers a comprehensive portfolio of protection, switching, measuring and monitoring devices. It is a simple distribution systems as well as switches and sockets for safe and efficient electrical infrastructure in buildings and industry.

The siemens 5sl6 series 1+n-pole miniature circuit breaker has a current rating of 16 a and 6 ka breaking capacity. The miniature circuit breaker is the fuse for short-circuit protection. Siemens offe more→rs a comprehensive portfolio of protection, switching, measuring and monitoring devices, distribution systems as well as switches and sockets for safe and efficient electrical infrastructure in buildings and industry. Protection class ip= ip20 with connected conductors. Halogen-free, sealable, silicon-free. Supply voltage= 230 vac.

This comb rail from Schneider Electric Merlin Gerin's Acti9 series is used for interconnecting the phase(s) and neutral. The insulated terminal rail features 4 poles and 12 modules. Furthermore, the c more→omb rail has a cross section of 16mm² and a rated continuous current of 100A.

This Halyester power rail coupler is suitable for 3- and 4-pole switch boxes with changeover switches with a current rating of 160 amps, where the switch is mounted at the top of the box. The correspo more→nding branch strip is placed under the main rails. This coupler comes in the PEN or N variant and measures 12 by 3 millimeters.

This comb rail from Eaton Holec's Z-SV series is for the purpose of PLN6 circuit breakers and is suitable for 13 devices. The insulated terminal rail features 3 poles and 3 modules. Furthermore, the c more→omb rail has a cross-sectional area of 10mm² and a rated continuous current of 50A. With end caps.

SV OM adaptor, 32 A, 690 V, 3-pole, tension spring clamp 1,5-6 mm², WH: 45x208 mm, support rail TS 45C.

Geyer AR comb rail L1/L2/L3+N, diameter 16mm², length 210mm, suitable for devices with zero yellow, serving series(s) of circuit breakers 36mm, execution electrical connection fork, 3 phases, suitable more→for number of devices 3, combination with ground fault circuit breaker, 4 poles, division size 210mm.

Eaton Industries DILM XRL comb rail, rated continuous current Iu 32A, serving series(s) KM DUIL (DILM17/32), electrical connection design pin, 3 phases, suitable for number of devices 2, 3 poles, insu more→lated, suitable for devices with auxiliary sch, reversing wiring kit.

Connection rail fork 3-pole+N 10 mm² 8 modules. In combination with quickbusbar components, the installation-friendly quickbusbar rails (KDN) provide a quick, secure and screwless connection. This Qui more→ckbusbar connection rail is for the purpose of 2 circuit breakers 4p, 3+N or 2 earth leakage switches 4p. The Hager Quickbusbar comb rails are available in different variants.

This flat comb rail from Eaton Holec's System 55 series is for the purpose of PLN6 circuit breakers and is suitable for 6 devices. The isolated terminal rail features 1 pole and 6 module units. Furthe more→rmore, the comb rail has a cross-sectional area of 10mm² and a rated continuous current of 63A.

Eaton Industries EVG comb rail, gray, diameter 16mm², length 33mm, rated continuous current Iu 80A, for the purpose of series(s) PLS. FAZ. PKN. PFIM, version electrical connection fork, 4 phases, suit more→able for number of devices 28, 4 poles, width in module units 12, isolated.

The double cage clamps of the SN201 L installation circuit breaker provide easy mounting of the circuit breaker. The SN201 L circuit breaker achieves maximum safety through the wide opening of the eid more→er. Here, an insulated screwdriver can be used to tighten the screws of both wire terminals. Thanks to the contact position indicators (CPI) on the circuit breaker rocker switch, you always know the status of the contacts. ABB SN L circuit breakers are available in different variants.

This easy-to-use PLS6 circuit breaker features top and bottom window and elevator terminals. Thanks to contact position indicators (CPI), you always know the status of the contacts. The 3-position DIN more→-rail clip allows removal from existing busbar. Eaton Moeller PLS circuit breakers are available in several variants.

This easy-to-use PLS6 circuit breaker features top and bottom window and elevator terminals. Thanks to contact position indicators (CPI), you always know the status of the contacts. The 3-position DIN more→-rail clip allows removal from existing busbar. Eaton Moeller PLS circuit breakers are available in several variants.

Dehn kamrail.

This right angle comb rail from Eaton Holec's System 55 series is for the purpose of PLN6 circuit breakers and is suitable for 6 devices. The isolated terminal rail features 1 pole and 6 module units. more→Furthermore, the comb rail has a cross-sectional area of 10mm² and a rated continuous current of 63A.

Geyer AR comb rail L1+N/L2+N/L3+N, diameter 16mm², length 210mm, suitable for devices with zero yellow, for series(s) of circuit breakers 36mm, execution electrical connection fork, 3 phases, suitable more→for number of devices 6, combination with earth leakage circuit breaker, 4 poles, division size 210mm.

This easy-to-use PLS6 circuit breaker features top and bottom window and elevator terminals. Thanks to contact position indicators (CPI), you always know the status of the contacts. The 3-position DIN more→-rail clip allows removal from existing busbar. Eaton Moeller PLS circuit breakers are available in several variants.

Socket rail fork 2-pole 16 mm² 12 modules. In combination with quickbusbar components, the installation-friendly quickbusbar rails (KDN) provide a quick, secure and screwless connection. This Quickbus more→bar connection rail is for the purpose of 6 circuit breakers 2p, 1+N or 6 earth leakage circuit breakers 2p or 6 earth leakage circuit breakers 2p.The Hager Quickbusbar comb rails are available in different variants.

Schneider electric 2-phase bus bar, 18mm pitch, 24 modules - ic60 series - a9xph224. Energise your switch disconnectors with this bus bar from schneider electric. Designed for two-phase electrical com more→ponents, the unit has 24 modules to link the live and neutral terminals of up to 12 devices. It has a wide connector pitch of 18mm, which means switches are spaced apart safely to prevent short circuits. This bus bar is fire-resistant in temperatures of up to +960°c for 30 seconds, so it's suitable for use in hazardous environments. You'll commonly find it in industrial automation applications.
