Circuit Breakers

Wohner EQUES power rail adapter, busbar copper connection standardized busbar copper, carrier rail equipment 1-carrier rail, connection round cable cores 4mm², electrical connection version 3x conduit more→AWG 12, adapter width 45mm, width rail 10mm, diameter connection terminal 4mm, center distance rail 60mm.

SV OM adaptor, 25 A, 690 V, 3-pole, connection cable AWG 12, WH: 45x208 mm, support rail TS 45C.

System pro M compact S200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electrome more→chanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200 comply with IEC/EN 60898-1, IEC/EN 60947-2, UL1077 allowing the use for residential, commercial and industrial applications.

System pro M compact S200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electrome more→chanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200 comply with IEC/EN 60898-1, IEC/EN 60947-2, UL1077 allowing the use for residential, commercial and industrial applications.

Eaton Systeem 55 LV systems Final Distribution Boards. MCB 6kA 1P+N 20A B-kar FLEX.

Rittal SV current rail adapter, rail copper mini-pls rail 250A connection, version electrical connection other, adapter width 45mm, rail center distance 60mm, nom. (measuring) current In 25A.

Schneider Electric circuit breaker, tripping characteristic C, nom. (measuring) current 10A, voltage type DC, 1 poles (total), width in module units 1, ancillary device possible, connectable conductor more→cross-section duck 1 - 25mm², 1 protected poles, nom. (measuring) voltage 220V.

Schneider Electric Acti 9 circuit breaker, tripping characteristic C, nom. (measuring) current 16A, voltage type DC, 1 poles (total), width in module units 1, ancillary device possible, connectable co more→nductor cross-section duck 1 - 25mm², 1 protected poles, nom. (measuring) voltage 220V.

Schneider electric single phase bus bar, 18mm pitch, 24 modules - ic60 series - a9xph124. Safely distribute power to switch disconnectors in your electrical systems with this bus bar from schneider el more→ectric. It has a convenient comb-like design with tooth connectors that fit into your components' terminals. A pitch of 18mm between the adapters provides safe spacing to prevent short circuits. This busbar has 24 connectors to link as many as 24 switches, and you can easily cut it to suit your needs, making it a versatile choice.

Schneider Electric DPN Vigi comb rail L1+N, diameter 16mm², length 432mm, rated continuous current Iu 80A, suitable for devices with zero yellow, for the purpose of series(s) v/DPNa/N/Vigi, electrical more→connection design pin, 1 phase, suitable for number of devices 24, combination with ground fault circuit interrupter, 2 poles.

This Halyester power rail coupler is suitable for 3- and 4-pole switchgear with a current rating of 160 amps, where the branch strip is placed above the main rails. This coupler comes in the PEN or N more→variant and measures 13 by 3 millimeters.

This Halyester power rail coupler is suitable for 4-pole switch boxes with inverter with a current rating of 250 amps, where the branch strip is placed under the main rails. This coupler comes in the more→PEN or N variant and measures 20 by 4 millimeters.

The schneider electric ic60a miniature circuit breaker is multi-standard circuit breaker which combine circuit protection against short-circuit current and circuit protection against overload current. more→It has 1p+n pole and has 16 a of current. Its width si. Ambient air temperature for operation -25 to 70 °c. Degree of protection ip20.

Wohner CRITO power rail adapter, connection round cable cores 3x 6 - 50mm², execution electrical connection round conductor, adapter width 54mm, width rail 10mm, diameter connection terminal 6 - 50mm, more→center distance rail 60mm, max. Current rail thickness 10mm, min. Current rail thickness 5mm.

Wohner EQUES power rail adapter, busbar copper connection standardized busbar copper, carrier rail equipment 2d carrier rails, connection round cable cores 4mm², version electrical connection 3x condu more→it AWG 12, adapter width 45mm, width rail 10mm, diameter connection terminal 4mm, center distance rail 60mm.

This iC60N circuit breaker has a visi-trip window. This signaling of shutdown due to a fault by a red mechanical status indicator is on the front of the automaton. The green strip on the switch of the more→Acti 9 iC60 circuit breaker ensures that the contacts are physically open and that work can be performed on the downstream circuit in complete safety. In addition, this Schneider Electric circuit breaker features a double clip for disassembly while the comb rail is still in place.

This iC60N circuit breaker has a visi-trip window. This signaling of shutdown due to a fault by a red mechanical status indicator is on the front of the automaton. The green strip on the switch of the more→Acti 9 iC60 circuit breaker ensures that the contacts are physically open and that work can be performed on the downstream circuit in complete safety. In addition, this Schneider Electric circuit breaker features a double clip for disassembly while the comb rail is still in place.

SV OM adaptor, 25 A, 690 V, 3-pole, connection cable AWG 12, WH: 45x208 mm, support rail 2xTS 45D.

Automatic cut-out, 5sy4 series, 10 ka, b, c and d characteristic. Miniature circuit breakers from siemens, offer the highest quality and reliability. The excellent technical properties of the devices more→mean you are always on the safe side. Apart from that you benefit from the innovative mounting options which enable quick and easy installation. The miniature circuit breakers from siemens can be combined as required with a wide range of supplementary components e.g.

This Halyester power rail coupler is suitable for 3- and 4-pole switch fuse boxes with a current rating of 160 amps, where the branch strip is placed under the main rails. This coupler comes in the PE more→N or N variant and measures 20 by 4 millimeters.

This iC60N circuit breaker has a visi-trip window. This signaling of shutdown due to a fault by a red mechanical status indicator is on the front of the automaton. The green strip on the switch of the more→Acti 9 iC60 circuit breaker ensures that the contacts are physically open and that work can be performed on the downstream circuit in complete safety. In addition, this Schneider Electric circuit breaker features a double clip for disassembly while the comb rail is still in place.

Single-pole miniature circuit breaker designed for residential and commercial electrical installations. Features a C-characteristic tripping curve, 40A rated current, and 6kA breaking capacity accordi more→ng to IEC/EN 60898-1. Compact design enables easy integration into modern switchboards while providing reliable protection against overload and short circuits.

SV Connection adaptor, 125 A, 690 V, 3-pole, cable outet bottom, round conductor connection 10-35 mm², clamping area WH: 10x7,8 mm.

Eaton Moeller series xEffect - FAZ MCB. FAZ, 1-pole, tripping characteristic: C, rated current In: 1 A.
