Asus PRIME B550M-K (90MB14V0-M0EAY0)

Photos - Motherboard Asus PRIME B550M-K
Videos 8Photos 6
from £85.22 up to £227.99
add to listmy lists
Asus PRIME B550M-K
2020Primeno backlight
Towards:home / office
Form Factor:micro-ATX
Socket:AMD AM4
Chipset:AMD B550
BIOS:Ami
RAM slots:DDR4 4 sl
RAM form factor:DIMM
RAM clock:4400 MHz
Sound (channels):7.1
Connectors:HDMI, M.2
Power connector:24 pin
Processor power:8 pin

The most affordable Asus motherboard based on the 2020 AMD B550 chipset with an AM4 processor socket. Made in the microATX form factor, it is positioned as a product of the middle price category, focused on use as part of universal office, multifunctional home configurations or entry-level workstations. In addition to small overall dimensions, which allow it to be installed in small Mini Tower cases, it is distinguished by the presence of a complete set of up-to-date system and peripheral interfaces.

Fully supports 3rd generation Ryzen 3/5/7/9 processors with Matisse Refresh/Matisse cores. Equipped with a reliable 6-phase Digi+ digital power subsystem for stable operation under long-term multi-threaded loads. The design and layout of the Asus PRIME B550M-K motherboard is carefully optimized and is perfect for DIY. Four slots for installing DIMM modules allow you to install up to 128 GB of high-speed DDR4 RAM (4x32 GB). Such an impressive volume is enough for any professional applications, 4K gaming and everyday tasks. Two M.2 SSDs are supported, one of which is capable of running the ultra-fast PCI-E 4.0 x4 interface. D-sub, HDMI 2.1 and DVI-D connectors allow you to use the Radeon Vega graphics core built into some processor models.

All specifications
Specifications PRIME B550M-K
Main
Featuresfor home/office
SocketAMD AM4
Form factormicro-ATX
Power phases6
Size (HxW)244x244 mm
Chipset
ChipsetAMD B550
BIOSAmi
UEFI BIOS
RAM
DDR44 slot(s)
Memory moduleDIMM
Operation mode2 channel
Max. clock frequency4400 MHz
Max. memory128 GB
XMP
Drive interface
SATA 3 (6Gbps)4
M.2 connector2
M.22xSATA/PCI-E 4x
Integrated RAID controller / Raid 0, 1, 10 /
Expansion slots
1x PCI-E slots2
PCI-E 16x slots1
PCI Express4.0
Internal connections
TPM connector
USB 2.02
USB 3.2 gen11
Video outputs
D-Sub output (VGA)
DVI outputDVI-D
HDMI output
HDMI versionv.2.1
Integrated audio
AudiochipRealtek ALC887
Sound (channels)7.1
Network interfaces
LAN (RJ-45)1 Gbps
LAN ports1
LAN controllerRealtek RTL8111H
External connections
USB 2.02
USB 3.2 gen14
PS/21
Power connectors
Main power socket24 pin
CPU power8 pin
Fan power connectors3
Official Websiteasus.com
Added to E-Catalogmay 2020
P/N
90MB14V0-M0EAY0

Information in model description is for reference purposes.
Before buying always check characteristics and configuration of product with online store manager
