Asus ROG MAXIMUS Z690 FORMULA
Towards:gaming
Form Factor:ATX
Socket:Intel LGA 1700
Chipset:Intel Z690
BIOS:Ami
RAM slots:DDR5 4 sl
RAM form factor:DIMM
RAM clock:6400 MHz
Sound (channels):7.1
Connectors:HDMI, M.2
Additional connectors:Thunderbolt 4
Power connector:24 pin
Processor power:8+8 pin
The Asus ROG MAXIMUS Z690 FORMULA belongs to the ROG MAXIMUS family of gaming boards, which are aimed at demanding gamers and overclocking enthusiasts. It will be an excellent choice for use in a powerful gaming PC with an overclocked multi-core processor, reactive SSDs, a large amount of high-speed RAM (up to 128 GB at 6400 MHz), a flagship GeForce RTX 3080/3090 graphics card and integrated air or water cooling.
For stable operation under serious computing loads, it is equipped with the most serious 21-phase power subsystem using a high-quality element base and integrated cooling of components. On the "motherboard" there are 6 SATA3 slots, 3 M.2 slots (with support for PCI-E 4/5 interfaces), plus 2 more implemented through ROG Hyper M.2 expansion cards. Special mention deserves a Marvell 10 Gigabit LAN controller, a high-end SupremeFX ALC4082 audio path, a Wi-Fi 6E (802.11ax) wireless module with Bluetooth 5.2 support, Thunderbolt 4 protocol support and an integrated Aura Sync LED lighting controller.
All specifications
